Excel 68000 Mach IV 68020 Master 2325 (set 1) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
fex68km4	fidelity/eag68k.cpp		no	no	no	yes	Excel 68000 Mach IV 68020 Master 2325 (set 1)	1989	Fidelity International	fex68k	fex68k

snap

Excel 68000 Mach IV 68020 Master 2325 (set 1) png snap

Excel 68000 Mach IV 68020 Master 2325 (set 1) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
fex68km4	53629	29/12/2025 11:31:22	640	592	96	96	0	Format24bppRgb	305:MAME 0.218 (Jan 29 2020)	e75e736a2ed59ae35afc93ed2b05fc2e0c968718

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
68020_mach_iv_v1.3a_even_11_30_88.u6	32768	ea47a712	bd853f74c83d760a4f4df0250248cbdba8f1f241	maincpu	0	good	no
68020_mach_iv_v1.3a_odd_11_30_88.u7	32768	41b5860d	935c43ef1ff511426f49e83e29014883c68e99b4	maincpu	1	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68020	20000000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

tag	name
:maincpu	m68020
:irq_clock	clock
:board	sensorboard
:display	pwm_display
:speaker	speaker
:dac	dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		8		no

port, analog

port_tag	analog_masks
:IN.0
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.11
:board:RANK.12
:board:RANK.13
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes
