Funhouse (L-2, prototype PA-1 System 11 sound) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
fh_pa1	pinball/wpc_an.cpp		no	no	yes	yes	Funhouse (L-2, prototype PA-1 System 11 sound)	1990	Williams	fh_l9	fh_l9

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u6-l2.rom	131072	7a8a3278	b35c1149862724ea70cc810f14141e51b365e950	maincpu	10000	good	no
fh_u4.pa1	131072	9f0a716d	3d3ec250b0b4344844ad8ce5bcbb326f934b22d3	bg:cpu	0	good	no
fh_u19.pa1	131072	b0fb5ddf	138c2aa283f7ced90637e981063f520bf46c57df	bg:cpu	20000	good	no
fh_u20.pa1	131072	bb864f78	ed861bd5df382e7efac103a1acb3d810ee4b15dc	bg:cpu	40000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
cpu	bg:cpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	bg	Williams System 11C Background Audio Board
audio	bg:dac	MC1408 DAC
audio	bg:ym2151	YM2151 OPM	3579545
audio	bg:cvsd_filter2	Biquad Filter
audio	bg:cvsd_filter	Biquad Filter
audio	bg:hc55516	HC-55516

device_ref

name
mc6809e
wpc
speaker
s11c_bg
mc6809e
mc1408
pia6821
ym2151
filter_biquad
filter_biquad
hc55516

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		56		no

port, analog

port_tag	analog_masks
:COIN
:DIPS
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7

dipswitch

Switch 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 1	DIPS	1

location

name	number	inverted
SWA	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

Switch 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 2	DIPS	2

location

name	number	inverted
SWA	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

W20

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
W20	DIPS	4

location

name	number	inverted
SWA	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

W19

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
W19	DIPS	8

location

name	number	inverted
SWA	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Country

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Country	DIPS	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
USA 1	0	yes
France 1	16	no
Germany	32	no
France 2	48	no
Unknown 1	64	no
Unknown 2	80	no
Unknown 3	96	no
Unknown 4	112	no
Export 1	128	no
France 3	144	no
Export 2	160	no
France 4	176	no
UK	192	no
Europe	208	no
Spain	224	no
USA 2	240	no
