Grand Cross (v1.02F) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
gcpinbal	excellent/gcpinbal.cpp		no	no	no	yes	Grand Cross (v1.02F)	1994	Excellent System

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no	preliminary

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
2_excellent.u43	524288	d174bd7f	0e6c17265e1400de941e3e2ca3be835aaaff6695	maincpu	0	good	no
3_excellent.u45	524288	0511ad56	e0602ece514126ce719ebc9de6649ebe907be904	maincpu	100000	good	no
4_excellent.u46	524288	e0f3a1b4	761dddf374a92c1a1e4a211ead215d5be461a082	maincpu	180000	good	no
u1	1048576	afa459bb	7a7c64bcb80d71b8cf3fdd3209ef109997b6417c	bg0	0	good	no
u6	1048576	c3f024e5	d197e2b715b154fc64ff9a61f8c6df111d6fd446	bg0	100000	good	no
1_excellent.u10	131072	79321550	61f1b772ed8cf95bfee9df8394b0c3ff727e8702	fg0	0	good	no
u13	2097152	62f3952f	7dc9ccb753d46b6aaa791bcbf6e18e6d872f6b79	spritegen	0	good	no
u55	524288	b3063351	825e63e8a824d67d235178897528e5b0b41e4485	oki	0	good	no
u56	2097152	092b2c0f	2ec1904e473ddddb50dbeaa0b561642064d45336	essnd	0	good	no
a.u72	260			plds	0	nodump	no
b.u73	260			plds	200	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16000000
audio	mono	Speaker
audio	oki	OKI MSM6295 ADPCM	1056000
audio	msm	OKI MSM6585 ADPCM	640000

device_ref

name
m68000
timer
93c46_16
mb3773
screen
gfxdecode
palette
excellent_spr
speaker
okim6295
es8712
hct157
msm6585

sound

channels
1

feature

type	status	overall
graphics	imperfect

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		8		no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	3

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	2	no
Normal	3	yes
Hard	1	no
Hardest	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
300k	4	no
500k	8	no
1000k	12	yes
None	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	64	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	1792

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	512	no
3 Coins/1 Credit	768	no
2 Coins/1 Credit	1024	no
2 Coins/1 Credit 3/2 4/3 6/5	256	no
1 Coin/1 Credit	1792	yes
1 Coin/1 Credit 2/3	1280	no
1 Coin/1 Credit 5/6	0	no
1 Coin/2 Credits	1536	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	14336

location

name	number	inverted
SW1	4	no
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	4096	no
3 Coins/1 Credit	6144	no
2 Coins/1 Credit	8192	no
2 Coins/1 Credit 3/2 4/3 6/5	2048	no
1 Coin/1 Credit	14336	yes
1 Coin/1 Credit 2/3	10240	no
1 Coin/1 Credit 5/6	0	no
1 Coin/2 Credits	12288	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	49152

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	no
3	49152	yes
4	32768	no
5	16384	no
