Galaxy Force 2 (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
gforce2j	sega/segaybd.cpp		no	no	no	yes	Galaxy Force 2 (Japan)	1988	Sega	gforce2	gforce2

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000	5376240	342	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-11511.25	131072	d80a86d6	e1beecb2af2d9960514639f30dbf923c9d5d5a89	maincpu	0	good	no
epr-11510.24	131072	d2b1bef4	191c0387f4e47c2d675a6d6984907ca3a9d4156a	maincpu	1	good	no
epr-11515.81	131072	d85875cf	11fe1e008b2ced564aa5f82130cc7872fefeaf8d	subx	0	good	no
epr-11514.80	131072	3dcc6919	0f701854734880aa98e890d8e2d13c62216dfb53	subx	1	good	no
epr-11513.54	131072	e18bc177	3fb179c9074954fc9b64da1463f542d60a99ec84	suby	0	good	no
epr-11512.53	131072	6010e63e	00aa5e8516f094409a407744b84ef183393b8b19	suby	1	good	no
epr-11707.ic37	32768			drive_board	0	nodump	no
epr-11707a.ic37	32768			drive_board	0	nodump	no
mpr-11467.16	131072	6e60e736	73086744cb2fe1ce162f851cb879755c21819b33	bsprites	0	good	no	mpr-11467.16
mpr-11468.14	131072	74ca9ca5	c6f27ce43ef270088e6155c8240fd15afa5729fd	bsprites	1	good	no	mpr-11468.14
epr-11694.17	131072	7e297b84	bbf1aa2b0b6b1f9fdaf9bea77d24b7f4f9320696	bsprites	40000	good	no	epr-11694.17
epr-11695.15	131072	38a864be	ef7d89511713d695f6a454c42f079d3507d9690d	bsprites	40001	good	no	epr-11695.15
mpr-11469.67	131072	ed7a2299	1aecf9ccba1fed0b7908008e798c522251a08b0f	ysprites	0	good	no	mpr-11469.67
mpr-11470.75	131072	34dea550	da95b8346c3530573461553629af4cc493bbb4af	ysprites	1	good	no	mpr-11470.75
mpr-11477.63	131072	a2784653	00a123d1fc8116ca678d6d8dbf1a5450feee014d	ysprites	2	good	no	mpr-11477.63
mpr-11478.71	131072	8b778993	015ae757d26cd6e69bdf79e237f62743a8f41e0c	ysprites	3	good	no	mpr-11478.71
mpr-11471.86	131072	f1974069	c8beb1a2ce430e3e6478c87c7053a58f8f31a140	ysprites	4	good	no	mpr-11471.86
mpr-11472.114	131072	0d24409a	ee00e23b0c548918b89dd48ed3f8b0370388659e	ysprites	5	good	no	mpr-11472.114
mpr-11479.82	131072	ecd6138a	bbc157a1f9b7e24d16e6f126d95c448736e83791	ysprites	6	good	no	mpr-11479.82
mpr-11480.110	131072	64ad66c5	aaab6999aa88b3340b16ee1188a8432477e16625	ysprites	7	good	no	mpr-11480.110
mpr-11473.66	131072	0538c6ec	9397db188f12cf8cd91841794134760f30f83893	ysprites	100000	good	no	mpr-11473.66
mpr-11474.74	131072	eb923c50	f997d2bc7f674eae4243eaf640d8faffa41d9521	ysprites	100001	good	no	mpr-11474.74
mpr-11481.62	131072	78e652b6	8c70609172908131fef8cbe05f810dbd3d120eba	ysprites	100002	good	no	mpr-11481.62
mpr-11482.70	131072	2f879766	ca5835d0bb77fe7de83ad336a82111cb2f96cd41	ysprites	100003	good	no	mpr-11482.70
mpr-11475.85	131072	69cfec89	db2a9b03fff727f198fb5cbfb9c281ac3bbc5623	ysprites	100004	good	no	mpr-11475.85
mpr-11476.113	131072	a60b9b79	6e9aa51923c12f5658bd17deb6c032e08c91dade	ysprites	100005	good	no	mpr-11476.113
mpr-11483.81	131072	d5d3a505	fa7662346b954d3faf0e8fcf138004231676845c	ysprites	100006	good	no	mpr-11483.81
mpr-11484.109	131072	b8a56a50	ccbc391d6f60b88630d7a93b8bb6e365a8d59ed8	ysprites	100007	good	no	mpr-11484.109
epr-11696.65	131072	99e8e49e	ab6e1d74af412ec2f939043d7dc26f4b2e34a528	ysprites	200000	good	no	epr-11696.65
epr-11697.73	131072	7545c52e	bdb0ccf233e10e9449aa367db5a5b5f209bee969	ysprites	200001	good	no	epr-11697.73
epr-11700.61	131072	e13839c1	4975b5314797d11c782b0478eaa84eaf9980b1cd	ysprites	200002	good	no	epr-11700.61
epr-11701.69	131072	9fb3d365	bfcf4abfa91aa41b16f01b7bafe97cd865167fbc	ysprites	200003	good	no	epr-11701.69
epr-11698.84	131072	cfeba3e2	826b73858ca5ea05688246d36b1f607356974ca9	ysprites	200004	good	no	epr-11698.84
epr-11699.112	131072	4a00534a	9a637b45b140420937b232bf690ef8bc3d43f5ad	ysprites	200005	good	no	epr-11699.112
epr-11702.80	131072	2a09c627	c6b0a618b4ddd9d227d3472544b62ebef966b041	ysprites	200006	good	no	epr-11702.80
epr-11703.108	131072	43bb7d9f	e36d208937f56f0af14292184c80ca939c32c378	ysprites	200007	good	no	epr-11703.108
epr-11524.64	131072	5d35849f	b86fb230ed0901dfdb525e7a47d9c9ad8031a3f6	ysprites	300000	good	no	epr-11524.64
epr-11525.72	131072	9ae47552	43268dd5f79282aabd8972994437de1b2d2acc40	ysprites	300001	good	no	epr-11525.72
epr-11532.60	131072	b3565ddb	3208744d43a11f4de8a6b626cc9113ad63d36807	ysprites	300002	good	no	epr-11532.60
epr-11533.68	131072	f5d16e8a	3b5c1582794a0e69707264879b544ac48afd9337	ysprites	300003	good	no	epr-11533.68
epr-11526.83	131072	094cb3f0	4b30e24dfd33c9922ffd5665cd9631b1f24243da	ysprites	300004	good	no	epr-11526.83
epr-11527.111	131072	e821a144	eeec0e51798645cce8f9a7e686178268398977fb	ysprites	300005	good	no	epr-11527.111
epr-11534.79	131072	b7f0ad7c	987b198692db365f3a81e88e5eec526775c318c6	ysprites	300006	good	no	epr-11534.79
epr-11535.107	131072	95da7a46	ffe6cd80eecc7c53a1155396ede0720d975d2c3b	ysprites	300007	good	no	epr-11535.107
epr-11693.102	65536	0497785c	f077e71efdc96d6eb3f1a1f989650466554fb13a	soundcpu	0	good	no	epr-11693.102
mpr-11465.107	524288	e1436dab	363f4c111de38cb1d82b245e4fcc65308f506e6a	pcm	0	good	no	mpr-11465.107
epr-11516.106	131072	19d0e17f	7171131226cf1fe260a2db310fad2ec264adca26	pcm	80000	good	no	epr-11516.106
epr-11814.105	131072	0b05d376	8d0c0be2fd9dbc714c82c7cd1c439d5ff65e1317	pcm	100000	good	no	epr-11814.105

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000 (Musashi)	12500000
cpu	subx	Motorola MC68000 (Musashi)	12500000
cpu	suby	Motorola MC68000 (Musashi)	12500000
cpu	soundcpu	Zilog Z80	4026987
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	4026987
audio	pcm	Sega PCM	4026987

device_ref

name
m68000msh
m68000msh
m68000msh
z80
nvram
mb3773
315_5296
msm6253
sega_315_5248
sega_315_5248
sega_315_5248
sega_315_5249
sega_315_5249
sega_315_5249
screen
gfxdecode
sega_sys16b_sprite
sega_yboard_sprite
segaic16_video
palette
speaker
generic_latch_8
ym2151
segapcm

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
stick		2		yes	1	255	100	79

port, analog

port_tag	analog_masks
:ADC.0	255
:ADC.1	255
:ADC.2	255
:COINAGE
:DSW
:GENERAL
:LIMITSW
:P1

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	COINAGE	15

location

name	number	inverted
SWA	1	no
SWA	2	no
SWA	3	no
SWA	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	COINAGE	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	1

location

name	number	inverted
SWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Energy Timer

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Energy Timer	DSW	6

location

name	number	inverted
SWB	2	no
SWB	3	no

value

name	value	default
Easy	4	no
Normal	6	yes
Hard	2	no
Hardest	0	no

Shield Strength

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Shield Strength	DSW	8

location

name	number	inverted
SWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Weak	8	yes
Strong	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	48

location

name	number	inverted
SWB	5	no
SWB	6	no

value

name	value	default
Easy	32	no
Normal	48	yes
Hard	16	no
Hardest	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW	192

location

name	number	inverted
SWB	7	no
SWB	8	no

value

name	value	default
Super Deluxe	192	no
Deluxe	128	no
Upright	64	yes
City	0	no
