Ghox (joystick, older) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ghoxjo	toaplan/ghox.cpp		no	no	no	yes	Ghox (joystick, older)	1991	Toaplan	ghox	ghox

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	240	59.637405	6750000	432	0	320	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
tp021-01.ghoxsticker.u10	131072	ad3a8817	317267e0c00934a86bf05c5afd6c69a7944a2ed3	maincpu	0	good	no
tp021-02.ghoxsticker.u11	131072	2340e981	d8e3f55e67fe6500f9e6c7eed1388dc895c5f574	maincpu	1	good	no
hd647180.021	32768	6ab59e5b	d814dd3a8f1ee638794e2bd422eed4247ba4a15e	audiocpu	0	good	no	hd647180.021
tp021-03.u36	524288	a15d8e9d	640a33997bdce8e84bea6a944139716379839037	gp9001	0	good	no	tp021-03.u36
tp021-04.u37	524288	26ed1c9a	37da8af86ea24327444c2d4ad3dfbd936208d43d	gp9001	80000	good	no	tp021-04.u37

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	audiocpu	Hitachi HD647180X MCU	10000000
audio	mono	Speaker
audio	ymsnd	YM2151 OPM	3375000

device_ref

name
m68000
hd647180x
z180asci_channel_0
z180asci_channel_1
z180csio
toaplan_coincounter
screen
palette
gp9001vdp
buffered_spriteram16
speaker
ym2151

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
dial	1			no	0	65280	25	15
joy	2	2	8	no
dial	2			no	0	255	25	15

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:IN1
:IN2
:JMPR
:PAD1	255
:PAD2	255
:SYS

configuration

Region

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Region	JMPR	524303

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Europe	524290	yes
USA	1	no
Japan	0	no
Hong Kong (Honest Trading Co.)	3	no
Korea	4	no
Taiwan	5	no
Spain & Portugal (APM Electronics S.A.)	524294	no
Italy (Star Electronica SRL)	524295	no
UK (JP Leisure Limited)	524296	no
USA (Romstar, Inc.)	9	no
Europe (Nova Apparate GMBH & Co.)	524298	no
Japan (Unused) [b]	11	no
Japan (Unused) [c]	12	no
Japan (Unused) [d]	13	no
Japan (Unused) [e]	14	no
Japan (Unused) [f]	15	no

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWA	1

location

name	number	inverted
SW1	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWA	2

location

name	number	inverted
SW1	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSWA	4

location

name	number	inverted
SW1	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	8

location

name	number	inverted
SW1	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSWA	48

location

name	number	inverted
SW1	5	yes
SW1	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	48	no	JMPR	524288	eq	524288
3 Coins/1 Credit	32	no	JMPR	524288	eq	524288
2 Coins/1 Credit	32	no	JMPR	524288	ne	524288
2 Coins/1 Credit	16	no	JMPR	524288	eq	524288
1 Coin/1 Credit	0	yes
2 Coins/3 Credits	48	no	JMPR	524288	ne	524288
1 Coin/2 Credits	16	no	JMPR	524288	ne	524288

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSWA	192

location

name	number	inverted
SW1	7	yes
SW1	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	128	no	JMPR	524288	ne	524288
1 Coin/1 Credit	0	yes	JMPR	524288	ne	524288
2 Coins/3 Credits	192	no	JMPR	524288	ne	524288
1 Coin/2 Credits	64	no	JMPR	524288	ne	524288
1 Coin/2 Credits	0	yes	JMPR	524288	eq	524288
1 Coin/3 Credits	64	no	JMPR	524288	eq	524288
1 Coin/4 Credits	128	no	JMPR	524288	eq	524288
1 Coin/6 Credits	192	no	JMPR	524288	eq	524288

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWB	3

location

name	number	inverted
SW2	1	yes
SW2	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	1	no
Normal	0	yes
Hard	2	no
Very Hard	3	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSWB	12

location

name	number	inverted
SW2	3	yes
SW2	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	12	no
100k only	8	no
100k and 300k	4	no
100k and every 200k	0	yes

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSWB	48

location

name	number	inverted
SW2	5	yes
SW2	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	48	no
2	32	no
3	0	yes
5	16	no

Debug Mode (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug Mode (Cheat)	DSWB	64

location

name	number	inverted
SW2	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	128

location

name	number	inverted
SW2	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
