Gold Mine (Shuffle) (L-2) - mame (0288) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
gmine_l2	pinball/wms_shuffle.cpp	genpin	no	no	yes	yes	Gold Mine (Shuffle) (L-2)	1987	Williams

snap

Gold Mine (Shuffle) (L-2) png snap

Gold Mine (Shuffle) (L-2) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
gmine_l2	15261	20/03/2026 14:08:15	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	a42b499db61dd9be613ca98dbe3528beb872211c

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u27.128	16384	99c6e049	356faec0598a54892050a28857e9eb5cdbf35833	maincpu	0	good	no
u21.256	32768	3b801570	50b50ff826dcb031a30940fa3099bd3a8d773831	s11sound:audiocpu	8000	good	no
u22.256	32768	08352101	a7437847a71cf037a80686292f9616b1e08922df	s11sound:audiocpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6802	4000000
cpu	s11sound:cpu	Motorola MC6802	4000000
audio	mechvol	Speaker
audio	samples	Samples
audio	mono	Speaker
audio	s11sound	Williams System 11 Sound Board
audio	s11sound:dac	MC1408 DAC
audio	s11sound:hc	HC-55516

device_ref

tag	name
:maincpu	m6802
:mechvol	speaker
:samples	samples
:pia24	pia6821
:pia28	pia6821
:pia30	pia6821
:nvram	nvram
:mainirq	ipt_merge_any_hi
:4020	ripple_counter
:rclock	clock
:mono	speaker
:pia21	pia6821
:pia2c	pia6821
:pia34	pia6821
:s11sound	wmss11
:s11sound:cpu	m6802
:s11sound:dac	mc1408
:s11sound:hc	hc55516
:s11sound:pia	pia6821

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

input

players	coins	service	tilt
2	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad	1	36		no
keypad	2	1		no

port, analog

port_tag	analog_masks
:DIAGS
:DS1
:DS2
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7
:s11sound:S11

dipswitch

Data tens

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data tens	DS1	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0	15	yes
1	7	no
2	11	no
3	3	no
4	13	no
5	5	no
6	9	no
7	1	no
8	14	no
9	6	no

Data units

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data units	DS1	240

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0	240	yes
1	112	no
2	176	no
3	48	no
4	208	no
5	80	no
6	144	no
7	16	no
8	224	no
9	96	no

Function

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Function	DS2	255

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0	255	yes
1	127	no
2	191	no
3	63	no
4	223	no
5	95	no
6	159	no
7	31	no
8	239	no
9	111	no
10	175	no
11	47	no
12	207	no
13	79	no
14	143	no
15	15	no
16	247	no
17	119	no
18	183	no
19	55	no
20	215	no
21	87	no
22	151	no
23	23	no
24	231	no
25	103	no
26	167	no
27	39	no
28	199	no
29	71	no
30	135	no
31	7	no
