Golden Axe (bootleg) - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
goldnaxeb2	sega/system16.cpp		no	no	no	yes	Golden Axe (bootleg)	1989	bootleg	goldnaxe	goldnaxe

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
ic39.1	65536	71489c9a	ec25463a2c63027d2635f0e27f5a971d68938fe3	maincpu	0	good	no
ic53.5	65536	7a98512d	f022a047d23051211e2de761b6c2289438b8f3cc	maincpu	1	good	no
ic38.2	65536	8c8c95b1	2b3897b8af587e6397dca0f3409a803432be07aa	maincpu	20000	good	no
ic52.6	65536	4f58f15b	4dcd7e8cfd8fe5fe9f9259abf53fd0d4c64b5abd	maincpu	20001	good	no
ic37.3	65536	056879fd	fc0a910c1dc4cf535ad589f482f57379798b5524	maincpu	80000	good	no
ic51.7	65536	8c77d958	f7c5abfec2a9d1724c83b1de2cd994bb4c42857c	maincpu	80001	good	no
ic36.4	65536	b69ab892	9b426058a80abb8dd3d6c0c55574fdc841889a72	maincpu	a0000	good	no
ic50.8	65536	3cf2f725	1f620fcebe8533cba50736ae1d97c095abf1bc25	maincpu	a0001	good	no
ic4.35	65536	84587263	3a88c8578a477a487a0a214a367042b9739f39eb	tiles	0	good	no
ic18.38	65536	63d72388	ba0a582b1daf3a1e316237efbad17fcc0381643f	tiles	10000	good	no
ic3.36	65536	f8b6ae4f	55132c98955107e4b247992f7917a6ce588460a7	tiles	20000	good	no
ic17.39	65536	e29baf4f	3761cb2217599fe3f2f860f9395930b96ec52f47	tiles	30000	good	no
ic2.37	65536	22f0667e	2d11b2ce105a3db9c914942cace85aff17deded9	tiles	40000	good	no
ic16.40	65536	afb1a7e4	726fded9db72a881128b43f449d2baf450131f63	tiles	50000	good	no
ic73.34	65536	28ba70c8	a6f33e1404928b6d1006943494646d6cfbd60a4b	sprites	1	good	no
ic74.33	65536	2ed96a26	edcf915243e6f92d31cdfc53965438f6b6bff51d	sprites	20001	good	no
ic79.28	65536	84dccc5b	10263d98d663f1170c3203066f391075a1d64ff5	sprites	100001	good	no
ic80.27	65536	3d41b995	913d2a0c9a2ac6d36589966d7eb5537120ea6ff0	sprites	120001	good	no
ic58.22	65536	ede51fe0	c05a2b51095a322bac5a67ee8886aecc186cbdfe	sprites	0	good	no
ic59.21	65536	30989141	f6e7ae258deedec11b1f80c19575c884aac26c56	sprites	20000	good	no
ic64.16	65536	38e4c92a	8b8a596da0726bc02c412a68e5163770fe3e62e4	sprites	100000	good	no
ic65.15	65536	9fb1f9b6	a193ff48f2bfbb4afbc322ae33cdf360afcb681e	sprites	120000	good	no
ic75.32	65536	101d2fff	1de1390c5f55f192491053c8aac31be3389aab2b	sprites	40001	good	no
ic76.31	65536	677e64a6	e3d0d31097017c6cb1a7f41292783f18ce13b41c	sprites	60001	good	no
ic81.26	65536	a34e84d1	5aa8836ef1bdf97e399899c911967840e9873bfb	sprites	140001	good	no
ic82.25	65536	ad1c1c90	155f17593cfab1a117bb755b1edd0c473d455f91	sprites	160001	good	no
ic60.20	65536	5853000d	db7adf1de74c66f667ea7ccc41702576de081ff5	sprites	40000	good	no
ic61.19	65536	697b3276	a8aeb2cfaca9368d5bfa14a67de36dbadd4a0585	sprites	60000	good	no
ic66.14	65536	753b01e8	0180cf893d63e60e14e2fb0f5836b302f08f0228	sprites	140000	good	no
ic67.13	65536	5dd6d8db	270886aebf4549c5cf456b1e90927b759a53e2e1	sprites	160000	good	no
ic77.30	65536	a9519afe	0550f596ef080db25241d88242d57edb3c7fb685	sprites	80001	good	no
ic78.29	65536	74df9232	61286c83eb6f31983c0ed24ca2151c58a95238f1	sprites	a0001	good	no
ic83.24	65536	a8c8c784	8e998019b4dbf509179d41eb2b446647db3d00a6	sprites	180001	good	no
ic84.23	65536	cc3a922c	3c96459d95961d463909b6b0e8c77916c3a018e3	sprites	1a0001	good	no
ic62.18	65536	ac6ad195	3c3fe38047698e28cae9193438fe0b85941476c5	sprites	80000	good	no
ic63.17	65536	03a905c4	c526a744021a392c860ded37afd54a78e9f47778	sprites	a0000	good	no
ic68.12	65536	cba013c7	a0658aaf7893bc9fb8f0435cab9f77ceb1fb4e1d	sprites	180000	good	no
ic69.11	65536	bea4d237	46e51e89b4ee1e2701da1004758d7da547a2e4c2	sprites	1a0000	good	no
ic45.10	65536	804dfba8	650ca61f78eb4d0aa256b554fb1570330166cc24	soundcpu	0	good	no
ic46.9	65536	634dd54e	ac4ab0ad9c1ac634ff4dfb83232b0fa5cfb26fdd	soundcpu	10000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	soundcpu	Zilog Z80	4000000
audio	mono	Speaker
audio	ym1	YM2203 OPN	4000000
audio	ym2	YM2203 OPN	4000000
audio	5205	OKI MSM5205 ADPCM	384000

device_ref

name
m68000
screen
gfxdecode
palette
sega_sys16b_sprite
generic_latch_8
z80
speaker
ym2203
ym2203
ls157
msm5205

sound

channels
1

feature

type	status	overall
sound	imperfect

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SERVICE

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit 5/3 6/4	5	no
2 Coins/1 Credit 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit 2/3	1	no
1 Coin/1 Credit 4/5	2	no
1 Coin/1 Credit 5/6	3	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit 5/3 6/4	80	no
2 Coins/1 Credit 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit 2/3	16	no
1 Coin/1 Credit 4/5	32	no
1 Coin/1 Credit 5/6	48	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Credits Needed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits Needed	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Credit To Start	1	yes
2 Credits To Start	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	60

location

name	number	inverted
SW2	3	no
SW2	4	no
SW2	5	no
SW2	6	no

value

name	value	default
Special	0	no
Easiest	20	no
Easier	52	no
Easy	28	no
Normal	60	yes
Hard	56	no
Harder	44	no
Hardest	40	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
