Sphinx Granada - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
granada	cxg/royal.cpp		no	no	no	yes	Sphinx Granada	1988	CXG Systems / Newcrest Technology / Intelligent Chess Software	sroyal	sroyal

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1988_105_newcrest_hd614042sj02	8192	47334ac9	b4dc930e34926f1b33f6d247af45627c891202ff	maincpu	0	good	no	1988_105_newcrest_hd614042sj02

chip

type	tag	name	clock
cpu	maincpu	Hitachi HD614042	4000000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

name
hd614042
sensorboard
pwm_display
pwm_display
speaker
dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		12		no

port, analog

port_tag	analog_masks
:CPU
:IN.0
:IN.1
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

CPU Frequency

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CPU Frequency	CPU	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3.58MHz (1992 version)	0	no
4MHz (1988 version)	1	yes

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes
