Grind Stormer - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
grindstm	toaplan/vfive.cpp		no	no	no	yes	Grind Stormer	1992	Toaplan

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	240	59.637405	6750000	432	0	320	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
01.bin	524288	4923f790	1c2d66b432d190d0fb6ac7ca0ec0687aea3ccbf4	maincpu	0	good	no
tp027_02.bin	1048576	877b45e8	b3ed8d8dbbe51a1919afc55d619d2b6771971493	gp9001	0	good	no
tp027_03.bin	1048576	b1fc6362	5e97e3cce31be57689d394a50178cda4d80cce5f	gp9001	100000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	audiocpu	NEC V25	10000000
audio	mono	Speaker
audio	ymsnd	YM2151 OPM	3375000

device_ref

name
m68000
v25
toaplan_coincounter
screen
palette
gp9001vdp
buffered_spriteram16
speaker
ym2151

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:IN1
:IN2
:JMPR
:SYS

configuration

Region

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Region	JMPR	240

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Europe	144	yes
USA	176	no
USA (American Sammy Corporation)	160	no
Southeast Asia	112	no
Southeast Asia (Charterfield)	96	no
Taiwan	80	no
Taiwan (Anomoto International Inc.)	64	no
Hong Kong	48	no
Hong Kong (Charterfield)	32	no
Korea	16	no
Korea (Unite Trading)	0	no
USA; different?	208	no
USA (American Sammy Corporation); different?	192	no
Korea; different?	224	no

dipswitch

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSWA	1

location

name	number	inverted
SW1	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	0	yes
Cocktail	1	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWA	2

location

name	number	inverted
SW1	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSWA	4

location

name	number	inverted
SW1	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	8

location

name	number	inverted
SW1	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSWA	48

location

name	number	inverted
SW1	5	yes
SW1	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	48	no	JMPR	224	eq	128
3 Coins/1 Credit	32	no	JMPR	224	eq	128
2 Coins/1 Credit	32	no	JMPR	224	ne	128
2 Coins/1 Credit	16	no	JMPR	224	eq	128
1 Coin/1 Credit	0	yes
2 Coins/3 Credits	48	no	JMPR	224	ne	128
1 Coin/2 Credits	16	no	JMPR	224	ne	128

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSWA	192

location

name	number	inverted
SW1	7	yes
SW1	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	128	no	JMPR	224	ne	128
1 Coin/1 Credit	0	yes	JMPR	224	ne	128
2 Coins/3 Credits	192	no	JMPR	224	ne	128
1 Coin/2 Credits	64	no	JMPR	224	ne	128
1 Coin/2 Credits	0	yes	JMPR	224	eq	128
1 Coin/3 Credits	64	no	JMPR	224	eq	128
1 Coin/4 Credits	128	no	JMPR	224	eq	128
1 Coin/6 Credits	192	no	JMPR	224	eq	128

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWB	3

location

name	number	inverted
SW2	1	yes
SW2	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	1	no
Normal	0	yes
Hard	2	no
Very Hard	3	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSWB	12

location

name	number	inverted
SW2	3	yes
SW2	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	12	no
200k only	8	no
300k and 800k	0	yes
300k and every 800k	4	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSWB	48

location

name	number	inverted
SW2	5	yes
SW2	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	48	no
2	32	no
3	0	yes
5	16	no

Invulnerability (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invulnerability (Cheat)	DSWB	64

location

name	number	inverted
SW2	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSWB	128

location

name	number	inverted
SW2	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	128	no
Yes	0	yes
