Gunforce: Battle Fire Engulfed Terror Island (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
gunforcej	irem/m92.cpp		no	no	no	yes	Gunforce: Battle Fire Engulfed Terror Island (Japan)	1991	Irem	gunforce	gunforce

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	60.012477	6666666	424	80	400	262	8	248	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no	preliminary

rom

name	size	crc	sha1	region	offset	status	optional	merge
gf_b-h0-e.ic28	131072	43c36e0f	08c278861568f0a2fb2699b89a4170f6843bbcb7	maincpu	1	good	no
gf_b-l0-e.ic25	131072	24a558d8	89a9fb737d51798bdd5c08f448d2d8b3e161396a	maincpu	0	good	no
gf_b-h1-e.ic27	131072	d9744f5d	056d6e6e9874c33dcebe2e0ec946117d5eaa5d76	maincpu	40001	good	no
gf_b-l1-e.ic26	131072	a0f7b61b	5fc7fc3f57e82a9ae4e1f3c3e8e3e3b0bd3ff8f5	maincpu	40000	good	no
gf_b-sh0-.ic14	65536	3f8f16e0	a9f568c1b585c2cf13b21716954dac0a89936fc6	soundcpu	1	good	no	gf_b-sh0-.ic14
gf_b-sl0-.ic17	65536	db0b13a3	6723026010610b706725a5284a7b8d70fe479dae	soundcpu	0	good	no	gf_b-sl0-.ic17
gf_c0.ic9	262144	b3b74979	b5b4a4775e0b28c3f37273f93f69886c911af4aa	gfx1	0	good	no	gf_c0.ic9
gf_c1.ic10	262144	f5c8590a	a7f90f23051f8ab2b2d925e950a5ef3c260170ca	gfx1	40000	good	no	gf_c1.ic10
gf_c2.ic11	262144	30f9fb64	f86e01b0d74a1f6c19d97d6d0e0f624f050dad10	gfx1	80000	good	no	gf_c2.ic11
gf_c3.ic12	262144	87b3e621	8e2655c6e83d00c38210fdced25003793bd93d9f	gfx1	c0000	good	no	gf_c3.ic12
gf_000.ic38	262144	209e8e8d	9720be888905be709733c53da207c3406d73aeb1	gfx2	0	good	no	gf_000.ic38
gf_010.ic39	262144	6e6e7808	92c30eecf8f3669581720be6e49db87fbfac7d88	gfx2	40000	good	no	gf_010.ic39
gf_020.ic40	262144	6f5c3cb0	e41572c267489e2078f8d5605c97abe2034a091a	gfx2	80000	good	no	gf_020.ic40
gf_030.ic41	262144	18978a9f	aa484710a7c3561a9922f119a064f9205475ae64	gfx2	c0000	good	no	gf_030.ic41
gf-da.ic8	131072	933ba935	482811e01239feecf10e232566a7809d0d4f11b8	irem	0	good	no	gf-da.ic8
m92_a-3m-.ic11	279	fc718efe	d554dd74cecd95754a1e6e24c6a207d6d3428253	plds	0	good	no	m92_a-3m-.ic11
m92_a-7j-.ic41	279	5730b25a	1877b807f6a94f6d515afc940e1d615a453490fd	plds	200	good	no	m92_a-7j-.ic41
m92_a-9j-.ic51	279	92d477cf	6a1e9bfdb367384e8611f46300f378730817514b	plds	400	good	no	m92_a-9j-.ic51
m92_b-2l-.ic7	279	3bab14ee	312d19cd1a6ef636495bb9a3294261c10bab3a56	plds	600	good	no	m92_b-2l-.ic7
m92_b-7h-.ic43	279	5de0795b	fb4265f993e82d0e532a0992acd2f5d510a9c96b	plds	800	good	no	m92_b-7h-.ic43

chip

type	tag	name	clock
cpu	maincpu	NEC V33	9000000
cpu	soundcpu	NEC V35	14318181
audio	mono	Speaker
audio	ymsnd	YM2151 OPM	3579545
audio	irem	Irem GA20	3579545

device_ref

name
v33
v35
pic8259
timer
screen
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
ym2151
iremga20

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:COINS_DSW3
:DSW
:P1_P2
:P3_P4

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	256

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	512

location

name	number	inverted
SW3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	1024

location

name	number	inverted
SW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	2048

location

name	number	inverted
SW3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	4096

location

name	number	inverted
SW3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4096	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	8192

location

name	number	inverted
SW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	16384

location

name	number	inverted
SW3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	COINS_DSW3	32768

location

name	number	inverted
SW3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	3

location

name	number	inverted
SW1	1	no
SW1	2	no

value

name	value	default
2	2	no
3	3	yes
4	1	no
5	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
Very Easy	0	no
Easy	8	no
Normal	12	yes
Hard	4	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
15k 35k 75k 120k	0	no
20k 40k 90k 150k	16	yes

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	32	yes

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	256

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	512

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Coin Slots

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slots	DSW	1024

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Common	1024	yes
Separate	0	no

Coin Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode	DSW	2048

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	2048	yes
2	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	12288	DSW	2048	eq	0

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default
5 Coins/1 Credit	0	no
3 Coins/1 Credit	4096	no
2 Coins/1 Credit	8192	no
1 Coin/1 Credit	12288	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	49152	DSW	2048	eq	0

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default
1 Coin/2 Credits	49152	yes
1 Coin/3 Credits	32768	no
1 Coin/5 Credits	16384	no
1 Coin/6 Credits	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	61440	DSW	2048	ne	0

location

name	number	inverted
SW2	5	no
SW2	6	no
SW2	7	no
SW2	8	no

value

name	value	default
6 Coins/1 Credit	40960	no
5 Coins/1 Credit	45056	no
4 Coins/1 Credit	49152	no
3 Coins/1 Credit	53248	no
2 Coins/1 Credit	57344	no
2 Coins to Start/1 to Continue	4096	no
3 Coins/2 Credits	12288	no
4 Coins/3 Credits	8192	no
1 Coin/1 Credit	61440	yes
2 Coins/3 Credits	16384	no
1 Coin/2 Credits	36864	no
1 Coin/3 Credits	32768	no
1 Coin/4 Credits	28672	no
1 Coin/5 Credits	24576	no
1 Coin/6 Credits	20480	no
Free Play	0	no
