H-89 with CDR Equipment - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
h89_cdr	heathzenith/h89.cpp		no	no	no	yes	H-89 with CDR Equipment	1981	Heath Company	h89	h89

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
tlbc:heath:screen	raster	0	640	250	59.259259	12288000	768	32	672	270	0	250	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
2732_cdr8390.u518	4096	1d30fe43	170092d1b62cf88edd29338b474e799c249a0dd7	maincpu	0	good	no	2732_cdr8390.u518	cdr8390
2732_cdr80b2.u518	4096	804a6898	a58daca0baf7b5d7c1485531680bd63168eb2d7e	maincpu	0	good	no	2732_cdr80b2.u518	cdr80b2
2732_kmr100_v3_a_02.u518	4096	fd491592	3d5803f95c38b237b07cd230353cd9ddc9858c13	maincpu	0	good	no	2732_kmr100_v3_a_02.u518	kmr-100
2732_mtrhex_4k.u518	4096	e26b29a9	ba13d6c9deef682a9a8262bc910d46b577929a13	maincpu	0	good	no	2732_mtrhex_4k.u518	mtrhex_4k
2716_444-19_h17.u520	2048	26e80ae3	0c0ee95d7cb1a760f924769e10c0db1678f2435c	maincpu	1800	good	no	2716_444-19_h17.u520

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	2048000
cpu	tlbc:heath:maincpu	Zilog Z80	2048000
audio	tlbc:heath:mono	Speaker
audio	tlbc:heath:beeper	Beep	1000
audio	p504:cdr_fdc:cdr_fdc_880h:0:5_ds_qd:flopsndout	Speaker
audio	p504:cdr_fdc:cdr_fdc_880h:0:5_ds_qd:floppysound	Floppy sound	44100
audio	p504:cdr_fdc:cdr_fdc_880h:1:5_ds_qd:flopsndout	Speaker
audio	p504:cdr_fdc:cdr_fdc_880h:1:5_ds_qd:floppysound	Floppy sound	44100
audio	p504:cdr_fdc:cdr_fdc_880h:2:5_ds_qd:flopsndout	Speaker
audio	p504:cdr_fdc:cdr_fdc_880h:2:5_ds_qd:floppysound	Floppy sound	44100
audio	p504:cdr_fdc:cdr_fdc_880h:3:5_ds_qd:flopsndout	Speaker
audio	p504:cdr_fdc:cdr_fdc_880h:3:5_ds_qd:floppysound	Floppy sound	44100

device_ref

name
z80
ram
heath_intr_socket
heath_intr_cntrl
ins8250
heath_tlb_connector
heath_tlb
z80
screen
gfxdecode
palette
mc6845
ins8250
mm5740
speaker
beep
clock
h89bus
h89bus_io_decoder_socket
h89bus_io_decoder_cdr86
h89bus_lslot
h89bus_lslot
h89bus_lslot
h89bus_rslot
cdr_fdc_880h
fd1797
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
h89bus_rslot
h89ha_88_3
ins8250
rs232
serial_printer
printer_image
ins8250
rs232
rs232_loopback
ins8250
rs232
rs232_loopback
h89bus_rslot
h89_we_pullup
timer

biosset

name	description	default
cdr8390	CDR 8390	yes
cdr80b2	CDR 80B2	no
kmr-100	Kres KMR-100 V3.a.02	no
mtrhex_4k	Ultimeth 4k ROM	no

sound

channels
5

feature

type	status	overall
disk		unemulated

ramoption

name	default
16K
32K
48K
64K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	p504:cdr_fdc:cdr_fdc_880h:0:5_ds_qd	floppy_5_25	floppydisk1	flop1
floppydisk	p504:cdr_fdc:cdr_fdc_880h:1:5_ds_qd	floppy_5_25	floppydisk2	flop2
floppydisk	p504:cdr_fdc:cdr_fdc_880h:2:5_ds_qd	floppy_5_25	floppydisk3	flop3
floppydisk	p504:cdr_fdc:cdr_fdc_880h:3:5_ds_qd	floppy_5_25	floppydisk4	flop4
printout	p505:ha_88_3:dce1:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
floppydisk	p504:cdr_fdc:cdr_fdc_880h:0:5_ds_qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	p504:cdr_fdc:cdr_fdc_880h:1:5_ds_qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	p504:cdr_fdc:cdr_fdc_880h:2:5_ds_qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	p504:cdr_fdc:cdr_fdc_880h:3:5_ds_qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
printout	p505:ha_88_3:dce1:printer:printer		prn

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		86		no

port, analog

port_tag	analog_masks
:CONFIG
:SW501
:p505:ha_88_3:CFG_AUX
:p505:ha_88_3:CFG_LP
:p505:ha_88_3:CFG_MODEM
:p505:ha_88_3:dce1:printer:RS232_DATABITS
:p505:ha_88_3:dce1:printer:RS232_PARITY
:p505:ha_88_3:dce1:printer:RS232_RXBAUD
:p505:ha_88_3:dce1:printer:RS232_STOPBITS
:tlbc:heath:CONFIG
:tlbc:heath:MODIFIERS
:tlbc:heath:SW401
:tlbc:heath:SW402
:tlbc:heath:X1
:tlbc:heath:X2
:tlbc:heath:X3
:tlbc:heath:X4
:tlbc:heath:X5
:tlbc:heath:X6
:tlbc:heath:X7
:tlbc:heath:X8
:tlbc:heath:X9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
tlbc	igc_super19	heath_igc_super19_tlb_device	no
tlbc	igc	heath_igc_tlb_device	no
tlbc	watzman	heath_watz_tlb	no
tlbc	ultrarom	heath_ultra_tlb	no
tlbc	superset	heath_superset_tlb	no
tlbc	igc_watzman	heath_igc_watz_tlb_device	no
tlbc	super19	heath_super19_tlb	no
tlbc	imaginator	heath_imaginator_tlb	no
tlbc	igc_ultrarom	heath_igc_ultra_tlb_device	no
tlbc	gp19	heath_gp19_tlb	no
tlbc	heath	heath_tlb	yes
h89bus:io_decoder	cdr86	h89bus_io_decoder_cdr86	yes
h89bus:io_decoder	mms_61c	h89bus_io_decoder_mms_61c	no
h89bus:io_decoder	444_61	h89bus_io_decoder_444_61	no
h89bus:io_decoder	444_43	h89bus_io_decoder_444_43	no
p501	ss_parallel_igc	sigmasoft_parallel_port_igc	no
p501	ss_parallel	sigmasoft_parallel_port	no
p502	ss_parallel_igc	sigmasoft_parallel_port_igc	no
p502	ss_parallel	sigmasoft_parallel_port	no
p503	ss_parallel_igc	sigmasoft_parallel_port_igc	no
p503	ss_parallel	sigmasoft_parallel_port	no
p504	z37fdc	h89_z37	no
p504	z_89_11	z_89_11	no
p504	ss_snd	h89_sigma_snd	no
p504	h_88_5	h89h_88_5	no
p504	h_88_3	h89h_88_3	no
p504	ha_88_3	h89ha_88_3	no
p504	cdr_fdc	cdr_fdc_880h	yes
p504:cdr_fdc:cdr_fdc_880h:0	8_ds_dd	floppy_8_dsdd	no
p504:cdr_fdc:cdr_fdc_880h:0	8_ds_sd	floppy_8_dssd	no
p504:cdr_fdc:cdr_fdc_880h:0	8_ss_sd	floppy_8_sssd	no
p504:cdr_fdc:cdr_fdc_880h:0	5_ds_qd	floppy_525_qd	yes
p504:cdr_fdc:cdr_fdc_880h:0	8_ss_dd	floppy_8_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:0	5_ds_dd	floppy_525_dd	no
p504:cdr_fdc:cdr_fdc_880h:0	5_ss_qd	floppy_525_ssqd	no
p504:cdr_fdc:cdr_fdc_880h:0	5_ss_dd	floppy_525_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:1	8_ds_dd	floppy_8_dsdd	no
p504:cdr_fdc:cdr_fdc_880h:1	8_ds_sd	floppy_8_dssd	no
p504:cdr_fdc:cdr_fdc_880h:1	8_ss_sd	floppy_8_sssd	no
p504:cdr_fdc:cdr_fdc_880h:1	5_ds_qd	floppy_525_qd	yes
p504:cdr_fdc:cdr_fdc_880h:1	8_ss_dd	floppy_8_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:1	5_ds_dd	floppy_525_dd	no
p504:cdr_fdc:cdr_fdc_880h:1	5_ss_qd	floppy_525_ssqd	no
p504:cdr_fdc:cdr_fdc_880h:1	5_ss_dd	floppy_525_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:2	8_ds_dd	floppy_8_dsdd	no
p504:cdr_fdc:cdr_fdc_880h:2	8_ds_sd	floppy_8_dssd	no
p504:cdr_fdc:cdr_fdc_880h:2	8_ss_sd	floppy_8_sssd	no
p504:cdr_fdc:cdr_fdc_880h:2	5_ds_qd	floppy_525_qd	yes
p504:cdr_fdc:cdr_fdc_880h:2	8_ss_dd	floppy_8_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:2	5_ds_dd	floppy_525_dd	no
p504:cdr_fdc:cdr_fdc_880h:2	5_ss_qd	floppy_525_ssqd	no
p504:cdr_fdc:cdr_fdc_880h:2	5_ss_dd	floppy_525_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:3	8_ds_dd	floppy_8_dsdd	no
p504:cdr_fdc:cdr_fdc_880h:3	8_ds_sd	floppy_8_dssd	no
p504:cdr_fdc:cdr_fdc_880h:3	8_ss_sd	floppy_8_sssd	no
p504:cdr_fdc:cdr_fdc_880h:3	5_ds_qd	floppy_525_qd	yes
p504:cdr_fdc:cdr_fdc_880h:3	8_ss_dd	floppy_8_ssdd	no
p504:cdr_fdc:cdr_fdc_880h:3	5_ds_dd	floppy_525_dd	no
p504:cdr_fdc:cdr_fdc_880h:3	5_ss_qd	floppy_525_ssqd	no
p504:cdr_fdc:cdr_fdc_880h:3	5_ss_dd	floppy_525_ssdd	no
p505	z37fdc	h89_z37	no
p505	z_89_11	z_89_11	no
p505	ss_snd	h89_sigma_snd	no
p505	h_88_5	h89h_88_5	no
p505	h_88_3	h89h_88_3	no
p505	ha_88_3	h89ha_88_3	yes
p505	cdr_fdc	cdr_fdc_880h	no
p505:ha_88_3:dce1	terminal	serial_terminal	no
p505:ha_88_3:dce1	sunkbd	sunkbd_adaptor	no
p505:ha_88_3:dce1	dec_loopback	dec_rs232_loopback	no
p505:ha_88_3:dce1	ie15	ie15_terminal	no
p505:ha_88_3:dce1	null_modem	null_modem	no
p505:ha_88_3:dce1	keyboard	serial_keyboard	no
p505:ha_88_3:dce1	patch	rs232_patch_box	no
p505:ha_88_3:dce1	swtpc8212	swtpc8212_terminal	no
p505:ha_88_3:dce1	printer	serial_printer	yes
p505:ha_88_3:dce1	scorpion	scorpion_ic	no
p505:ha_88_3:dce1	loopback	rs232_loopback	no
p505:ha_88_3:dce1	mockingboard	mockingboardd	no
p505:ha_88_3:dce1	msystems_mouse	rs232_mouse_hle_msystems	no
p505:ha_88_3:dce1	nss_tvi	nss_tvinterface	no
p505:ha_88_3:dce1	rs232_sync_io	rs232_sync_io	no
p505:ha_88_3:dce1	pty	pseudo_terminal	no
p505:ha_88_3:dce1	votraxtnt	serial_votraxtnt	no
p505:ha_88_3:dce1	rs_printer	rs_serial_printer	no
p505:ha_88_3:dce2	terminal	serial_terminal	no
p505:ha_88_3:dce2	sunkbd	sunkbd_adaptor	no
p505:ha_88_3:dce2	dec_loopback	dec_rs232_loopback	no
p505:ha_88_3:dce2	ie15	ie15_terminal	no
p505:ha_88_3:dce2	null_modem	null_modem	no
p505:ha_88_3:dce2	keyboard	serial_keyboard	no
p505:ha_88_3:dce2	patch	rs232_patch_box	no
p505:ha_88_3:dce2	swtpc8212	swtpc8212_terminal	no
p505:ha_88_3:dce2	printer	serial_printer	no
p505:ha_88_3:dce2	scorpion	scorpion_ic	no
p505:ha_88_3:dce2	loopback	rs232_loopback	yes
p505:ha_88_3:dce2	mockingboard	mockingboardd	no
p505:ha_88_3:dce2	msystems_mouse	rs232_mouse_hle_msystems	no
p505:ha_88_3:dce2	nss_tvi	nss_tvinterface	no
p505:ha_88_3:dce2	rs232_sync_io	rs232_sync_io	no
p505:ha_88_3:dce2	pty	pseudo_terminal	no
p505:ha_88_3:dce2	votraxtnt	serial_votraxtnt	no
p505:ha_88_3:dce2	rs_printer	rs_serial_printer	no
p505:ha_88_3:dte	terminal	serial_terminal	no
p505:ha_88_3:dte	sunkbd	sunkbd_adaptor	no
p505:ha_88_3:dte	dec_loopback	dec_rs232_loopback	no
p505:ha_88_3:dte	ie15	ie15_terminal	no
p505:ha_88_3:dte	null_modem	null_modem	no
p505:ha_88_3:dte	keyboard	serial_keyboard	no
p505:ha_88_3:dte	patch	rs232_patch_box	no
p505:ha_88_3:dte	swtpc8212	swtpc8212_terminal	no
p505:ha_88_3:dte	printer	serial_printer	no
p505:ha_88_3:dte	scorpion	scorpion_ic	no
p505:ha_88_3:dte	loopback	rs232_loopback	yes
p505:ha_88_3:dte	mockingboard	mockingboardd	no
p505:ha_88_3:dte	msystems_mouse	rs232_mouse_hle_msystems	no
p505:ha_88_3:dte	nss_tvi	nss_tvinterface	no
p505:ha_88_3:dte	rs232_sync_io	rs232_sync_io	no
p505:ha_88_3:dte	pty	pseudo_terminal	no
p505:ha_88_3:dte	votraxtnt	serial_votraxtnt	no
p505:ha_88_3:dte	rs_printer	rs_serial_printer	no
p506	we_pullup	h89_we_pullup	yes
p506	ss_snd	h89_sigma_snd	no
p506	ha_88_3	h89ha_88_3	no
p506	h_88_3	h89h_88_3	no

configuration

CPU Clock Speed Upgrade

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CPU Clock Speed Upgrade	CONFIG	3

setting

name	value	default
None	0	yes
2 / 4 MHz	1	no
2 / 6 MHz	2	no

Switch SW501 Definitions

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch SW501 Definitions	CONFIG	60

setting

name	value	default
Generic	0	no
Heath MTR-90	4	yes
Heath MTR-89	8	no
MMS 444-84B/444-84A	12	no
Kres KMR-100	16	no
Ultimeth MTRHEX-4k	20	no
Ultimeth MTRHEX-2k	24	no
SigmaROM	28	no
CDR8390 ROM	32	no

AUX - DCE (320 octal) Enabled

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
AUX - DCE (320 octal) Enabled	p505:ha_88_3:CFG_AUX	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

AUX - DCE (320 octal) Interrupt level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
AUX - DCE (320 octal) Interrupt level	p505:ha_88_3:CFG_AUX	6

setting

name	value	default
None	0	yes
3	2	no
4	4	no
5	6	no

LP - DCE (340 octal) Enabled

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LP - DCE (340 octal) Enabled	p505:ha_88_3:CFG_LP	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

LP - DCE (340 octal) Interrupt level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LP - DCE (340 octal) Interrupt level	p505:ha_88_3:CFG_LP	6

setting

name	value	default
None	0	yes
3	2	no
4	4	no
5	6	no

MODEM - DTE (330 octal) Enabled

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MODEM - DTE (330 octal) Enabled	p505:ha_88_3:CFG_MODEM	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

MODEM - DTE (330 octal) Interrupt level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MODEM - DTE (330 octal) Interrupt level	p505:ha_88_3:CFG_MODEM	6

setting

name	value	default
None	0	yes
3	2	no
4	4	no
5	6	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	p505:ha_88_3:dce1:printer:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	p505:ha_88_3:dce1:printer:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	p505:ha_88_3:dce1:printer:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	p505:ha_88_3:dce1:printer:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

CPU Clock

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CPU Clock	tlbc:heath:CONFIG	3

setting

name	value	default
2 MHz	0	yes
3 MHz	1	no
4 MHz	2	no
6 MHz	3	no

CRT Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CRT Color	tlbc:heath:CONFIG	12

setting

name	value	default
Green	0	yes
White	4	no
Amber	8	no

dipswitch

Switch 0

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 0	SW501	1	CONFIG	60	eq	0

location

name	number	inverted
SW501	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Switch 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 1	SW501	2	CONFIG	60	eq	0

location

name	number	inverted
SW501	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Disk I/O #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	SW501	3	CONFIG	60	eq	4

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-88-1 (Not yet implemented)	0	yes
H/Z-47 (Not yet implemented)	1	no
Z-67 (Not yet implemented)	2	no
Undefined	3	no

Disk I/O #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	SW501	3	CONFIG	60	eq	8

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-88-1	0	yes
H/Z-47	1	no
Undefined	2	no
Undefined	3	no

Disk I/O #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	SW501	3	CONFIG	60	eq	12

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-88-1	0	yes
H/Z-47 (Not yet implemented)	1	no
MMS 77320 SASI or Z-67 (Not yet implemented)	2	no
MMS 77422 Network Controller	3	no

Switch 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 2	SW501	4	CONFIG	60	eq	0

location

name	number	inverted
SW501	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Switch 3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 3	SW501	8	CONFIG	60	eq	0

location

name	number	inverted
SW501	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Disk I/O #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #1	SW501	12	CONFIG	60	eq	4

location

name	number	inverted
SW501	3	no
SW501	4	no

value

name	value	default
H-89-37	0	yes
H/Z-47 (Not yet implemented)	4	no
Z-67 (Not yet implemented)	8	no
Undefined	12	no

Disk I/O #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #1	SW501	12	CONFIG	60	eq	8

location

name	number	inverted
SW501	3	no
SW501	4	no

value

name	value	default
Unused	0	yes
H/Z-47	4	no
Undefined	8	no
Undefined	12	no

Disk I/O #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #1	SW501	12	CONFIG	60	eq	12

location

name	number	inverted
SW501	3	no
SW501	4	no

value

name	value	default
H-89-37	0	yes
H/Z-47 (Not yet implemented)	4	no
MMS 77320 SASI or Z-67 (Not yet implemented)	8	no
MMS 77422 Network Controller	12	no

Default Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Default Boot Device	SW501	15	CONFIG	60	eq	16

location

name	number	inverted
SW501	1	no
SW501	2	no
SW501	3	no
SW501	4	no

value

name	value	default
H-17 hard-sectored 5" floppy units 0-2	0	yes
H-37 soft-sectored 5" floppy units 0-3	1	no
Corvus hard disk/Magnolia interface, partitions 0-8	2	no
CDR 5"/8" double density floppy, units 0-3	3	no
H-47 8" floppy at port 0x78/0170, units 0-3	4	no
H-47 8" floppy at port 0x7c/0174, units 0-3	5	no
Reserved	6	no
Help - lists boot devices	7	no
Reserved	8	no
SASI controller or Z-67 at port 0x78/0170, units 0-7	9	no
SASI controller or Z-67 at port 0x7c/0174, units 0-7	10	no
Livingston 8" single density floppy, units 0-3	11	no
Magnolia 5"/8" double density floppy, units 0-3 (8"), 4-7 (5")	12	no
Reserved	13	no
Reserved	14	no
Magnolia 128K pseudo disk, banks 0-1	15	no

Default Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Default Boot Device	SW501	15	CONFIG	60	eq	20

location

name	number	inverted
SW501	1	no
SW501	2	no
SW501	3	no
SW501	4	no

value

name	value	default
H-17 hard-sectored 5" floppy	0	yes
H-37 soft-sectored 5" floppy	1	no
? Corvus hard disk/Magnolia interface	2	no
? CDR 5"/8" double density floppy	3	no
? H-47 8" floppy at port 0x78/0170	4	no
? H-47 8" floppy at port 0x7c/0174	5	no
? Reserved	6	no
? Reserved	7	no
? Reserved	8	no
? SASI controller or Z-67 at port 0x78/0170	9	no
? SASI controller or Z-67 at port 0x7c/0174	10	no
? Livingston 8" single density floppy	11	no
? Magnolia 5"/8" double density floppy	12	no
? Reserved	13	no
? Reserved	14	no
? Magnolia 128K pseudo disk	15	no

Default Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Default Boot Device	SW501	3	CONFIG	60	eq	24

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-17 hard-sectored 5" floppy	0	yes
H-47 8" floppy at port 0x78/0170	1	no
H-47 8" floppy at port 0x7c/0174	2	no
Magnolia 5"/8" double density floppy	3	no

Disk I/O #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	SW501	3	CONFIG	60	eq	28

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-88-1	0	yes
H/Z-47	1	no
WD1002 Hard Disk	2	no
WD1002 Floppy Disk	3	no

Disk I/O #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	SW501	3	CONFIG	60	eq	32

location

name	number	inverted
SW501	1	no
SW501	2	no

value

name	value	default
H-88-1	0	yes
undefined	1	no
undefined	2	no
undefined	3	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SW501	4	CONFIG	60	eq	24

location

name	number	inverted
SW501	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SW501	8	CONFIG	60	eq	24

location

name	number	inverted
SW501	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Disk I/O #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #1	SW501	12	CONFIG	60	eq	28

location

name	number	inverted
SW501	3	no
SW501	4	no

value

name	value	default
H-89-37	0	yes
H/Z-47	4	no
WD1002 Hard Disk	8	no
WD1002 Floppy Disk	12	no

Disk I/O #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #1	SW501	12	CONFIG	60	eq	32

location

name	number	inverted
SW501	3	no
SW501	4	no

value

name	value	default
undefined	0	yes
CDR FDC-880H	4	no
undefined	8	no
undefined	12	no

Switch 4

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 4	SW501	16	CONFIG	60	eq	0

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Primary Boot from

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Primary Boot from	SW501	16	CONFIG	60	eq	4

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	0	yes
Disk I/O #1	16	no

Primary Boot from

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Primary Boot from	SW501	16	CONFIG	60	eq	8

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	0	yes
Disk I/O #1	16	no

Map ROM into RAM on boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Map ROM into RAM on boot	SW501	16	CONFIG	60	eq	16

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	0	yes
No	16	no

? Map ROM into RAM on boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
? Map ROM into RAM on boot	SW501	16	CONFIG	60	eq	20

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
? Yes	0	yes
? No	16	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SW501	16	CONFIG	60	eq	24

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Primary Boot from

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Primary Boot from	SW501	16	CONFIG	60	eq	28

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	0	yes
Disk I/O #1	16	no

Primary Boot from

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Primary Boot from	SW501	16	CONFIG	60	eq	32

location

name	number	inverted
SW501	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disk I/O #2	0	yes
Disk I/O #1	16	no

Switch 5

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 5	SW501	32	CONFIG	60	eq	0

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32	yes

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	4

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	8

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Switch 6

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 6	SW501	64	CONFIG	60	eq	0

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Console Baud rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Console Baud rate	SW501	64	CONFIG	60	eq	4

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
19200	64	no

Console Baud rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Console Baud rate	SW501	64	CONFIG	60	eq	8

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
19200	64	no

Default Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Default Boot Device	SW501	112	CONFIG	60	eq	12

location

name	number	inverted
SW501	5	no
SW501	6	no
SW501	7	no

value

name	value	default
MMS 77316 Dbl Den 5"	0	yes
MMS 77316 Dbl Den 8"	16	no
Disk Device at 0x7C	32	no
Disk Device at 0x78	48	no
reserved for future use	64	no
reserved for future use	80	no
MMS Network (77422)	96	no
Use MMS I/O board Config Port	112	no

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	16

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	20

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	24

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Reserved

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reserved	SW501	32	CONFIG	60	eq	28

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Must be selected	32	yes
Must not be selected	0	no

Perform memory test at start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Perform memory test at start	SW501	32	CONFIG	60	eq	32

location

name	number	inverted
SW501	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Have a LLL controller installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Have a LLL controller installed	SW501	64	CONFIG	60	eq	16

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	64	no

? Have a LLL controller installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
? Have a LLL controller installed	SW501	64	CONFIG	60	eq	20

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
? No	0	yes
? Yes	64	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	64	CONFIG	60	eq	24

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	64	no

Console Baud rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Console Baud rate	SW501	64	CONFIG	60	eq	28

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
19200	64	no

Console Baud rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Console Baud rate	SW501	64	CONFIG	60	eq	32

location

name	number	inverted
SW501	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
19200	64	no

Switch 7

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 7	SW501	128	CONFIG	60	eq	0

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	4

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	8

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	12

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	16

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	20

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Baud Rate	SW501	128	CONFIG	60	eq	24

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
19200	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	28

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	SW501	128	CONFIG	60	eq	32

location

name	number	inverted
SW501	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Auto	128	no

Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Baud Rate	tlbc:heath:SW401	15

location

name	number	inverted
SW401	1	no
SW401	2	no
SW401	3	no
SW401	4	no

value

name	value	default
110	1	no
150	2	no
300	3	no
600	4	no
1200	5	no
1800	6	no
2000	7	no
2400	8	no
3600	9	no
4800	10	no
7200	11	no
9600	12	yes
19200	13	no

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	tlbc:heath:SW401	48

location

name	number	inverted
SW401	5	no
SW401	6	no

value

name	value	default
None	0	yes
Odd	16	no
None	32	no
Even	48	no

Parity Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity Type	tlbc:heath:SW401	64

location

name	number	inverted
SW401	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Stick	64	no

Duplex

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Duplex	tlbc:heath:SW401	128

location

name	number	inverted
SW401	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Half	0	no
Full	128	yes

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	tlbc:heath:SW402	1

location

name	number	inverted
SW402	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	yes
Block	1	no

Keyclick

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Keyclick	tlbc:heath:SW402	2

location

name	number	inverted
SW402	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	2	no
Yes	0	yes

Wrap at EOL

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wrap at EOL	tlbc:heath:SW402	4

location

name	number	inverted
SW402	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	4	no

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	tlbc:heath:SW402	8

location

name	number	inverted
SW402	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	8	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	tlbc:heath:SW402	16

location

name	number	inverted
SW402	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	16	no

Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Mode	tlbc:heath:SW402	32

location

name	number	inverted
SW402	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Heath/VT52	0	yes
ANSI	32	no

Keypad Shifted

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Keypad Shifted	tlbc:heath:SW402	64

location

name	number	inverted
SW402	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	64	no

Refresh

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Refresh	tlbc:heath:SW402	128

location

name	number	inverted
SW402	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
60Hz	0	yes
50Hz	128	no
