Hang-On - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
hangon1	sega/segahang.cpp		no	no	no	yes	Hang-On	1985	Sega	hangon	hangon

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.054389	6293700	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-6918.ic22	32768	0bf4f2ac	26c5bb6fe805644a8d427ad77814f4b0b1128b1a	maincpu	0	good	no
epr-6916.ic8	32768	06c21c8a	f06f21ff272a803c72e5041534053494f055e466	maincpu	1	good	no
epr-6917.ic20	32768	f48a6cbc	6437efaeb0e4cb727c03eb83678a9e107d244af1	maincpu	10000	good	no
epr-6915.ic6	32768	75d3b5ee	00948d0610f52b1b554cadde96227428e510e73e	maincpu	10001	good	no
epr-6920.ic63	32768	1c95013e	8344ac953477279c2c701f984d98292a21dd2f7d	subcpu	0	good	no	epr-6920.ic63
epr-6919.ic51	32768	6ca30d69	ed933351883ebf6d9ef9428a81d09749b609cd60	subcpu	1	good	no	epr-6919.ic51
epr-6841.ic38	32768	54d295dc	ad8cdb281032a2f931c2abbeb966998944683dc3	gfx1	0	good	no	epr-6841.ic38
epr-6842.ic23	32768	f677b568	636ca60bd4be9b5c2be09de8ae49db1063aa6c79	gfx1	8000	good	no	epr-6842.ic23
epr-6843.ic7	32768	a257f0da	9828f8ce4ef245ffb8dbad347f9ca74ed81aa998	gfx1	10000	good	no	epr-6843.ic7
epr-6819.ic27	32768	469dad07	6d01c0b3506e28832928ad74d518577ff5be323b	sprites	1	good	no	epr-6819.ic27
epr-6820.ic34	32768	87cbc6de	b64652e062e1b88c6f6ae8dd2ffe4533bb27ba45	sprites	0	good	no	epr-6820.ic34
epr-6821.ic28	32768	15792969	b061dbf24e8b511116446794753c8b0cc49e2149	sprites	10001	good	no	epr-6821.ic28
epr-6822.ic35	32768	e9718de5	30e3a7d5b33504da03c5780b4a946b977e46098a	sprites	10000	good	no	epr-6822.ic35
epr-6823.ic29	32768	49422691	caee2a4a3f4587ae27dec330214edaa1229012af	sprites	20001	good	no	epr-6823.ic29
epr-6824.ic36	32768	701deaa4	053032ef886b85a4cb4753d17b3c27d228695157	sprites	20000	good	no	epr-6824.ic36
epr-6825.ic30	32768	6e23c8b4	b17fd7d590ed4e6616b7b4d91a47a2820248d8c7	sprites	30001	good	no	epr-6825.ic30
epr-6826.ic37	32768	77d0de2c	83b126ed1d463504b2702391816e6e20dcd04ffc	sprites	30000	good	no	epr-6826.ic37
epr-6827.ic31	32768	7fa1bfb6	a27b54c93613372f59050f0b2182d2984a8d2efe	sprites	40001	good	no	epr-6827.ic31
epr-6828.ic38	32768	8e880c93	8c55deec065daf09a5d1c1c1f3f3f7bc1aeaf563	sprites	40000	good	no	epr-6828.ic38
epr-6829.ic32	32768	7ca0952d	617d73591158ed3fea5174f7dabf0413d28de9b3	sprites	50001	good	no	epr-6829.ic32
epr-6830.ic39	32768	b1a63aef	5db0a1cc2d13c6cfc77044f5d7f6f99d198531ed	sprites	50000	good	no	epr-6830.ic39
epr-6845.ic18	32768	ba08c9b8	65ceaefa18999c468b38576c29101674d1f63e5f	sprites	60001	good	no	epr-6845.ic18
epr-6846.ic25	32768	f21e57a3	92ce0723e722f446c0cef9e23080a008aa9752e7	sprites	60000	good	no	epr-6846.ic25
epr-6840.ic108	32768	581230e3	954eab35059322a12a197bba04bf85f816132f20	segaic16road	0	good	no	epr-6840.ic108
epr-6833.ic73	16384	3b942f5f	4384b5c090954e69de561dde0ef32104aa11399a	soundcpu	0	good	no	epr-6833.ic73
epr-6831.ic5	32768	cfef5481	c04b302fee58f0e59a097b2be2b61e5d03df7c91	pcm	0	good	no	epr-6831.ic5
epr-6832.ic6	32768	4165aea5	be05c6d295807af2f396a1ff72d5a3d2a1e6054d	pcm	8000	good	no	epr-6832.ic6
epr-6844.ic123	8192	e3ec7bd6	feec0fe664e16fac0fde61cf64b401b9b0575323	sprites:zoom	0	good	no	epr-6844.ic123
315-5118.bin	143	51d448a2	0a1018cc1d4c6dc87625d59539d257e01c9dc872	plds	0	good	no	315-5118.bin
315-5119.bin	143	a37f00e1	129b10f6cb48e1a1fefd69009380516cf2c677b5	plds	100	good	no	315-5119.bin
315-5120.bin	143	ba5f92ec	74e1fb137ac2ab6dbdad2e8111c27b836e2ff14b	plds	200	good	no	315-5120.bin

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	6293700
cpu	subcpu	Motorola MC68000	6293700
cpu	soundcpu	Zilog Z80	4000000
audio	speaker	Speaker
audio	ymsnd	YM2203 OPN	4000000
audio	pcm	Sega PCM	8000000

device_ref

name
m68000
m68000
i8255
i8255
adc0804
segaic16_video
segaic16_road
gfxdecode
palette
screen
generic_latch_8
sega_hangon_sprite
z80
speaker
ym2203
segapcm

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle				yes	32	224	100	4
pedal				no	0	255	100	40

port, analog

port_tag	analog_masks
:ADC0	255
:ADC1	255
:ADC2	255
:COINAGE
:DSW
:SERVICE
:UNKNOWN

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	COINAGE	15

location

name	number	inverted
SWA	1	no
SWA	2	no
SWA	3	no
SWA	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit	0	no
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	COINAGE	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit	0	no
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	1

location

name	number	inverted
SWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	6

location

name	number	inverted
SWB	2	no
SWB	3	no

value

name	value	default
Easy	4	no
Medium	6	yes
Hard	2	no
Hardest	0	no

Time Adj.

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time Adj.	DSW	24

location

name	number	inverted
SWB	4	no
SWB	5	no

value

name	value	default
Normal	24	yes
Medium	16	no
Hard	8	no
Hardest	0	no

Play Music

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Play Music	DSW	32

location

name	number	inverted
SWB	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	64

location

name	number	inverted
SWB	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	128

location

name	number	inverted
SWB	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
