Hard Dunk (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
harddunkj	sega/segas32.cpp		no	no	no	yes	Hard Dunk (Japan)	1994	Sega	harddunk	harddunk

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
mainpcb:screen	raster	0	416	224	60.000000	6539520	416	0	416	262	0	224	no
mainpcb:screen2	raster	0	416	224	60.000000	6539520	416	0	416	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
epr-16508.ic37	262144	b3713be5	8123638a838e41fcc0d32e14382421b521eff94f	mainpcb:maincpu	0	good	no
epr-16509.ic40	262144	603dee75	32ae964a4b57d470b4900cca6e06329f1a75a6e6	mainpcb:maincpu	2	good	no	epr-16513.ic40
epr-16505.ic31	131072	eeb90a07	d1c2132897994b2e85fd5a97222b9fcd61bc421e	mainpcb:soundcpu	0	good	no	epr-16505.ic31
mpr-16503.ic3	524288	ac1b6f1a	56482931adf7fe551acf796b74cd8af3773d4fef	mainpcb:gfx1	0	good	no	mpr-16503.ic3
mpr-16504.ic11	524288	7c61fcd8	ca4354f90fada752bf11ee22a7798a8aa22b1c61	mainpcb:gfx1	1	good	no	mpr-16504.ic11
mpr-16495.ic14	2097152	6e5f26be	146761072bbed08f4a9df8a474b34fab61afaa4f	mainpcb:sprites	0	good	no	mpr-16495.ic14
mpr-16497.ic15	2097152	42ab5859	f50c51eb81186aec5f747ecab4c5c928f8701afc	mainpcb:sprites	2	good	no	mpr-16497.ic15
mpr-16499.ic10	2097152	a290ea36	2503b44174f23a9d323caab86553977d1d6d9c94	mainpcb:sprites	4	good	no	mpr-16499.ic10
mpr-16501.ic38	2097152	f1566620	bcf31d11ee669d5afc7dc22c42fa59f4e48c1f50	mainpcb:sprites	6	good	no	mpr-16501.ic38
mpr-16496.ic22	2097152	d9d27247	d211623478516ed1b89ab16a7fc7969954c5e353	mainpcb:sprites	800000	good	no	mpr-16496.ic22
mpr-16498.ic23	2097152	c022a991	a660a20692f4d9ba7be73577328f69f109be5e47	mainpcb:sprites	800002	good	no	mpr-16498.ic23
mpr-16500.ic18	2097152	452c0be3	af87ce4618bae2d791c1baed34ba7f853af664ff	mainpcb:sprites	800004	good	no	mpr-16500.ic18
mpr-16502.ic41	2097152	ffc3147e	12d882dec3098674d27058a8009e8778555f477a	mainpcb:sprites	800006	good	no	mpr-16502.ic41
mpr-16506.ic1	2097152	e779f5ed	462d1bbe8bb12a0c5a6d6c613c720b26ec21cb25	mainpcb:sega	0	good	no	mpr-16506.1
mpr-16507.ic2	2097152	31e068d3	9ac88b15af441fb3b31ce759c565b60a09039571	mainpcb:sega	200000	good	no	mpr-16507.2

chip

type	tag	name	clock
cpu	mainpcb:maincpu	NEC V70	20000000
cpu	mainpcb:soundcpu	Zilog Z80	8000000
audio	mainpcb:sleft	Speaker
audio	mainpcb:sright	Speaker
audio	mainpcb:ymsnd	YM3438 OPN2C	8000000
audio	mainpcb:sega	Yamaha YMW-258-F	10000000

device_ref

name
segas32_pcb_multi_6player
v70
z80
315_5296
315_5296
93c46_16
timer
timer
gfxdecode
palette
screen
screen
speaker
speaker
ym3438
ymw258f
s32comm
i8255

sound

channels
2

feature

type	status	overall
graphics	imperfect
sound		imperfect

input

players	coins	service	tilt
6	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2	4	8	no
joy	3	4	8	no
joy	4	4	8	no
joy	5	4	8	no
joy	6	4	8	no

port, analog

port_tag	analog_masks
:mainpcb:EXTRA1
:mainpcb:EXTRA2
:mainpcb:EXTRA3
:mainpcb:P1_A
:mainpcb:P1_B
:mainpcb:P2_A
:mainpcb:P2_B
:mainpcb:PORTC_A
:mainpcb:PORTC_B
:mainpcb:SERVICE12_A
:mainpcb:SERVICE12_B
:mainpcb:SERVICE34_A
:mainpcb:SERVICE34_B

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	mainpcb:SERVICE34_A	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	mainpcb:SERVICE34_A	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	mainpcb:SERVICE34_A	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	mainpcb:SERVICE34_A	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no
