Harley Davidson (L-1) - mame (0288) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
hd_l1	pinball/wpc_an.cpp		no	no	yes	yes	Harley Davidson (L-1)	1991	Bally	hd_l3	hd_l3

snap

Harley Davidson (L-1) png snap

Harley Davidson (L-1) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
hd_l1	13710	20/03/2026 14:29:31	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	36cb44f09fc5642916939b2cece43c15b60ada4e

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u6-l1.rom	131072	a0bdcfbf	f906ffa2d4d04e87225bf711a07dd3bee1655a40	maincpu	10000	good	no
u18-sp1.rom	131072	708aa419	cfc2692fb3bcbacceb85021e282bfbc8dcdf8fcc	sound1	100000	good	no
hd_u15.rom	131072	e7870938	b4f28146a5e7baa8522db65b41311afaf49604c6	sound1	80000	good	no	hd_u15.rom

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
cpu	wpcsnd:bgcpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	wpcsnd	Williams WPC Sound
audio	wpcsnd:ym2151	YM2151 OPM	3580000
audio	wpcsnd:dac	AD7524 DAC
audio	wpcsnd:hc55516	HC-55516

device_ref

tag	name
:maincpu	mc6809e
:wpc	wpc
:speaker	speaker
:wpcsnd	wpcsnd
:wpcsnd:bgcpu	mc6809e
:wpcsnd:ym2151	ym2151
:wpcsnd:dac	ad7524
:wpcsnd:hc55516	hc55516

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		56		no

port, analog

port_tag	analog_masks
:COIN
:DIPS
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7

dipswitch

Switch 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 1	DIPS	1

location

name	number	inverted
SWA	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

Switch 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch 2	DIPS	2

location

name	number	inverted
SWA	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

W20

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
W20	DIPS	4

location

name	number	inverted
SWA	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

W19

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
W19	DIPS	8

location

name	number	inverted
SWA	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Country

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Country	DIPS	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
USA 1	0	yes
France 1	16	no
Germany	32	no
France 2	48	no
Unknown 1	64	no
Unknown 2	80	no
Unknown 3	96	no
Unknown 4	112	no
Export 1	128	no
France 3	144	no
Export 2	160	no
France 4	176	no
UK	192	no
Europe	208	no
Spain	224	no
USA 2	240	no
