mame (0289) • machine icm3216 • ICM-3216

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
icm3216	natsemi/icm3216.cpp		no	no	no	yes	ICM-3216	1985	National Semiconductor

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
icm3216	650	29/12/2025 11:31:24	640	240	96	96	0	Format24bppRgb	305:MAME 0.260.0 (Oct 25 2023)	3b0d97675d1ff6d1c7b7f3e1737fd830df9be00d

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
serial3:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
600045_003__rev_a.u29	16384	865e3e8b	c6e47d304fd67a9b384a139ef917913fc60c0b32	iop	0	good	no
610289_001__v1_283_u34.u34	32768	36296e83	f2ad1d0302befdb75ff61f85292363980031b458	eprom	0	good	no	v1283
610289_001__v1_283_u35.u35	32768	f0aff0bd	341e931f6a0ec894c0fdc9605d8e859a4dbeeb6f	eprom	1	good	no	v1283
610289_002__rev_b_u34.u34	32768	fb542bd1	39b7f1f90ffdae07ddc547eff564096bd2092d58	eprom	0	good	no	v244
610289_002__rev_b_u35.u35	32768	78cfc8dd	bb87f068a6ab7ef82d8865154856064b9e8a99a6	eprom	1	good	no	v244

chip

type	tag	name	clock
cpu	cpu	National Semiconductor NS32016	10000000
cpu	iop	Zilog Z80	5000000
audio	serial3:terminal:bell	Speaker
audio	serial3:terminal:beeper	Beep	2000

device_ref

tag	name
:cpu	ns32016
:fpu	ns32081
:mmu	ns32082
:icu	ns32202
:rtc	mm58274c
:duart0	scn2681
:duart0:cha	duart_channel
:duart0:chb	duart_channel
:duart1	scn2681
:duart1:cha	duart_channel
:duart1:chb	duart_channel
:serial0	rs232
:serial1	rs232
:serial2	rs232
:serial3	rs232
:serial3:terminal	serial_terminal
:serial3:terminal:terminal_screen	screen
:serial3:terminal:keyboard	generic_keyboard
:serial3:terminal:bell	speaker
:serial3:terminal:beeper	beep
:iop	z80
:scsi	nscsi_bus
:scsi:1	nscsi_connector
:scsi:1:harddisk	scsi_harddisk
:scsi:1:harddisk:image	harddisk_image
:scsi:2	nscsi_connector
:scsi:3	nscsi_connector
:scsi:4	nscsi_connector
:scsi:5	nscsi_connector
:scsi:6	nscsi_connector
:scsi:7	nscsi_connector
:scsi:7:tape	scsi_tape
:scsi:7:tape:image	simh_tape_image
:ncr5385	ncr5385

biosset

name	description	default
v244	ICM-3216 Rom Monitor V2.44	no
v1283	ICM-3216 Rom Monitor V1.283	yes

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	scsi:1:harddisk:image	scsi_hdd,hdd			harddisk	hard
tape	scsi:7:tape:image	tape			tape	tap

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	scsi:1:harddisk:image	scsi_hdd,hdd			chd, hd, hdv, 2mg, hdi
tape	scsi:7:tape:image	tape			tap

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		73		no

port, analog

port_tag	analog_masks
:serial3:terminal:RS232_DATABITS
:serial3:terminal:RS232_PARITY
:serial3:terminal:RS232_RXBAUD
:serial3:terminal:RS232_STOPBITS
:serial3:terminal:RS232_TXBAUD
:serial3:terminal:TERM_CONF
:serial3:terminal:keyboard:GENKBD_CFG
:serial3:terminal:keyboard:GENKBD_MOD
:serial3:terminal:keyboard:GENKBD_ROW0
:serial3:terminal:keyboard:GENKBD_ROW1
:serial3:terminal:keyboard:GENKBD_ROW2
:serial3:terminal:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
serial0	terminal	serial_terminal	no
serial0	swtpc8212	swtpc8212_terminal	no
serial0	sunkbd	sunkbd_adaptor	no
serial0	rs_printer	rs_serial_printer	no
serial0	rs232_sync_io	rs232_sync_io	no
serial0	printer	serial_printer	no
serial0	patch	rs232_patch_box	no
serial0	s97801	s97801_terminal	no
serial0	msystems_mouse	rs232_mouse_hle_msystems	no
serial0	scorpion	scorpion_ic	no
serial0	nss_tvi	nss_tvinterface	no
serial0	mockingboard	mockingboardd	no
serial0	loopback	rs232_loopback	no
serial0	keyboard	serial_keyboard	no
serial0	ie15	ie15_terminal	no
serial0	null_modem	null_modem	no
serial0	votraxtnt	serial_votraxtnt	no
serial0	h19	serial_heath_h19	no
serial0	dec_loopback	dec_rs232_loopback	no
serial0	pty	pseudo_terminal	no
serial0	auto3a	auto3a_terminal	no
serial1	terminal	serial_terminal	no
serial1	swtpc8212	swtpc8212_terminal	no
serial1	sunkbd	sunkbd_adaptor	no
serial1	rs_printer	rs_serial_printer	no
serial1	rs232_sync_io	rs232_sync_io	no
serial1	printer	serial_printer	no
serial1	patch	rs232_patch_box	no
serial1	s97801	s97801_terminal	no
serial1	msystems_mouse	rs232_mouse_hle_msystems	no
serial1	scorpion	scorpion_ic	no
serial1	nss_tvi	nss_tvinterface	no
serial1	mockingboard	mockingboardd	no
serial1	loopback	rs232_loopback	no
serial1	keyboard	serial_keyboard	no
serial1	ie15	ie15_terminal	no
serial1	null_modem	null_modem	no
serial1	votraxtnt	serial_votraxtnt	no
serial1	h19	serial_heath_h19	no
serial1	dec_loopback	dec_rs232_loopback	no
serial1	pty	pseudo_terminal	no
serial1	auto3a	auto3a_terminal	no
serial2	terminal	serial_terminal	no
serial2	swtpc8212	swtpc8212_terminal	no
serial2	sunkbd	sunkbd_adaptor	no
serial2	rs_printer	rs_serial_printer	no
serial2	rs232_sync_io	rs232_sync_io	no
serial2	printer	serial_printer	no
serial2	patch	rs232_patch_box	no
serial2	s97801	s97801_terminal	no
serial2	msystems_mouse	rs232_mouse_hle_msystems	no
serial2	scorpion	scorpion_ic	no
serial2	nss_tvi	nss_tvinterface	no
serial2	mockingboard	mockingboardd	no
serial2	loopback	rs232_loopback	no
serial2	keyboard	serial_keyboard	no
serial2	ie15	ie15_terminal	no
serial2	null_modem	null_modem	no
serial2	votraxtnt	serial_votraxtnt	no
serial2	h19	serial_heath_h19	no
serial2	dec_loopback	dec_rs232_loopback	no
serial2	pty	pseudo_terminal	no
serial2	auto3a	auto3a_terminal	no
serial3	terminal	serial_terminal	yes
serial3	swtpc8212	swtpc8212_terminal	no
serial3	sunkbd	sunkbd_adaptor	no
serial3	rs_printer	rs_serial_printer	no
serial3	rs232_sync_io	rs232_sync_io	no
serial3	printer	serial_printer	no
serial3	patch	rs232_patch_box	no
serial3	s97801	s97801_terminal	no
serial3	msystems_mouse	rs232_mouse_hle_msystems	no
serial3	scorpion	scorpion_ic	no
serial3	nss_tvi	nss_tvinterface	no
serial3	mockingboard	mockingboardd	no
serial3	loopback	rs232_loopback	no
serial3	keyboard	serial_keyboard	no
serial3	ie15	ie15_terminal	no
serial3	null_modem	null_modem	no
serial3	votraxtnt	serial_votraxtnt	no
serial3	h19	serial_heath_h19	no
serial3	dec_loopback	dec_rs232_loopback	no
serial3	pty	pseudo_terminal	no
serial3	auto3a	auto3a_terminal	no
scsi:1	tape	scsi_tape	no
scsi:1	harddisk	scsi_harddisk	yes
scsi:2	tape	scsi_tape	no
scsi:2	harddisk	scsi_harddisk	no
scsi:3	tape	scsi_tape	no
scsi:3	harddisk	scsi_harddisk	no
scsi:4	tape	scsi_tape	no
scsi:4	harddisk	scsi_harddisk	no
scsi:5	tape	scsi_tape	no
scsi:5	harddisk	scsi_harddisk	no
scsi:6	tape	scsi_tape	no
scsi:6	harddisk	scsi_harddisk	no
scsi:7	tape	scsi_tape	yes
scsi:7	harddisk	scsi_harddisk	no

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	serial3:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	serial3:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	serial3:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	serial3:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	serial3:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	serial3:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	serial3:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	serial3:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	serial3:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	serial3:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	serial3:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	serial3:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	serial3:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	serial3:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	serial3:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	serial3:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no
