15IE-00-013 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ie15	ussr/ie15.cpp		no	no	no	yes	15IE-00-013	1980	USSR

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
ie15:screen	raster	0	800	275	50.000000	15400000	1000	200	1000	308	22	297	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

chip

type	tag	name	clock
cpu	ie15:maincpu	ie15 CPU	3080000
audio	ie15:mono	Speaker
audio	ie15:beeper	Beep	2400

device_ref

name
ie15_device
screen
ie15_cpu
ie15kbd
speaker
beep
gfxdecode
palette
rs232

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		91		no

port, analog

port_tag	analog_masks
:ie15:RS232_DATABITS
:ie15:RS232_PARITY
:ie15:RS232_RXBAUD
:ie15:RS232_STOPBITS
:ie15:RS232_TXBAUD
:ie15:io_keyboard
:ie15:keyboard:TERM_LINE0
:ie15:keyboard:TERM_LINE1
:ie15:keyboard:TERM_LINE2
:ie15:keyboard:TERM_LINE3
:ie15:keyboard:TERM_LINEC

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	ie15:RS232_DATABITS	15

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
7	7	no
8	8	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	ie15:RS232_PARITY	7

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	ie15:RS232_RXBAUD	65535

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
300	300	no
600	600	no
1200	1200	no
2400	2400	no
4800	4800	no
9600	9600	yes
19200	19200	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	ie15:RS232_STOPBITS	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	1	yes
2	2	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	ie15:RS232_TXBAUD	65535

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
300	300	no
600	600	no
1200	1200	no
2400	2400	no
4800	4800	no
9600	9600	yes
19200	19200	no

dipswitch

RED (Interpret controls)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RED (Interpret controls)	ie15:io_keyboard	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

DUP (Full duplex)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DUP (Full duplex)	ie15:io_keyboard	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

LIN (Online)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LIN (Online)	ie15:io_keyboard	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	16	yes
