Image Fight (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
imgfightj	irem/m72.cpp		no	no	no	yes	Image Fight (Japan)	1988	Irem	imgfight	imgfight

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	384	256	55.017606	8000000	512	64	448	284	0	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
if_c-h0-.ic40	65536	592d2d80	d54916a9bfe4b65a972b62202af706135e73518d	maincpu	1	good	no
if_c-l0-.ic37	65536	61f89056	3e0724dbc2b00a30193ea6cfac8b4331055d4fd4	maincpu	0	good	no
if_c-h3-.ic43	131072	ea030541	ee4c12773ecced2d755443ce0ca78fb2b2c04805	maincpu	40001	good	no	if_c-h3-.ic43
if_c-l3-.ic34	131072	c66ae348	eca5096ebd5bffc6e68f3fc9969cda9679bd921f	maincpu	40000	good	no	if_c-l3-.ic34
if_c-pr-.ic1	4096	ef0d5098	068b73937588e16a318a094dfe2fb1293b1a1711	mcu	0	good	no
if-c-00.ic53	131072	745e6638	43fb1f9da4190fea67eee3aee8caf4219becc21b	sprites	0	good	no	if-c-00.ic53
if-c-10.ic51	131072	b7108449	1f41ebe7164fab86958caaf6749b99425e682657	sprites	20000	good	no	if-c-10.ic51
if-c-20.ic49	131072	aef33cba	2d8a8458207d0c790c81b1285366463c8540d190	sprites	40000	good	no	if-c-20.ic49
if-c-30.ic47	131072	1f98e695	5fddcfb17523f8e96f4b85f0cb15d837b81f2bd4	sprites	60000	good	no	if-c-30.ic47
if_b-a0.ic21	65536	34ee2d77	38826e0318aa8da893fa4c93f217288c015df606	tiles0	0	good	no	if_b-a0.ic21
if_b-a1.ic22	65536	6bd2845b	149cf14f919590da88b9a8e254690da010709862	tiles0	10000	good	no	if_b-a1.ic22
if_b-a2.ic20	65536	090d50e5	4f2a7c76320b3f8dafae90a246187e034fe7562b	tiles0	20000	good	no	if_b-a2.ic20
if_b-a3.ic23	65536	3a8e3083	8a75d556790b6bea41ead1a5f95589dd293bdf4e	tiles0	30000	good	no	if_b-a3.ic23
if_b-b0.ic26	65536	b425c829	0ccd487dba00bb7cb0ff5d1c67f8fee3e68df5d8	tiles1	0	good	no	if_b-b0.ic26
if_b-b1.ic27	65536	e9bfe23e	f97a68dbdce7e06d07faab19acf7625cdc8eeaa8	tiles1	10000	good	no	if_b-b1.ic27
if_b-b2.ic25	65536	256e50f2	9e9fda4f1f1449548942c0da4478f61fe0d263d1	tiles1	20000	good	no	if_b-b2.ic25
if_b-b3.ic24	65536	4c682785	f61f1227e0ad629fdfca106306b17a9f6a9959e3	tiles1	30000	good	no	if_b-b3.ic24
if_c-v0.ic44	65536	cb64a194	940fad6b9147bccc8290e112f5973f8ea062b52f	samples	0	good	no	if_c-v0.ic44
if_c-v1.ic45	65536	45b68bf5	2fb28793019ca85b3b6d7c4c31eedff1d71f2d83	samples	10000	good	no	if_c-v1.ic45
m72_a-8l-.ic66	256	b460c438	00e20cf754b6fd5138ee4d2f6ec28dff9e292fe6	proms	0	good	no	m72_a-8l-.ic66
m72_a-9l-.ic75	256	a4f2c4bc	f13b0a4b52dcc6704063b676f09d83dcba170133	proms	100	good	no	m72_a-9l-.ic75
m72_a-3d-.ic11	279	8a3732ff	6e3039e7dc424cbef7156312fa1ce67d7b082d30	pals	0	good	no	m72_a-3d-.ic11
m72_a-4d-.ic19	279	56c29834	a66c589845f9995c673325f1161c687eb90d68c1	pals	200	good	no	m72_a-4d-.ic19
if-c-3f-.ic13	279	2d774e1e	373c3cbfaf983961c17ebe96b5aff850f36cb30c	pals	400	good	no	if-c-3f-.ic13

chip

type	tag	name	clock
cpu	maincpu	NEC V30	8000000
cpu	soundcpu	Zilog Z80	3579545
cpu	mcu	Intel 8751	8000000
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	3579545
audio	dac	8-Bit R-2R DAC

device_ref

name
v30
z80
pic8259
buffered_spriteram16
gfxdecode
palette
screen
speaker
generic_latch_8
rst_neg_buffer
m72_audio
ym2151
dac_8bit_r2r
mb8421_mb8431_16
generic_latch_8
generic_latch_8
i8751

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2	4	8	no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1

dipswitch

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	3

location

name	number	inverted
SW1	1	no
SW1	2	no

value

name	value	default
2	2	no
3	3	yes
4	1	no
5	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
Normal	12	yes
Hard	8	no
Hardest	4	no
Debug Mode 2 lap	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	48	DSW	1024	eq	0

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default
5 Coins/1 Credit	0	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit	32	no
1 Coin/1 Credit	48	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	192	DSW	1024	eq	0

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default
1 Coin/2 Credits	192	yes
1 Coin/3 Credits	128	no
1 Coin/5 Credits	64	no
1 Coin/6 Credits	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	240	DSW	1024	ne	0

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
6 Coins/1 Credit	160	no
5 Coins/1 Credit	176	no
4 Coins/1 Credit	192	no
3 Coins/1 Credit	208	no
8 Coins/3 Credits	16	no
2 Coins/1 Credit	224	no
5 Coins/3 Credits	32	no
3 Coins/2 Credits	48	no
1 Coin/1 Credit	240	yes
2 Coins/3 Credits	64	no
1 Coin/2 Credits	144	no
1 Coin/3 Credits	128	no
1 Coin/4 Credits	112	no
1 Coin/5 Credits	96	no
1 Coin/6 Credits	80	no
Free Play	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	256

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW	512

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	0	yes
Cocktail	512	no

Coin Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode	DSW	1024

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mode 1	1024	yes
Mode 2	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	2048

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4096

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4096	yes
On	0	no

Stop Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Mode	DSW	8192

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no
