Indian Dreaming (0101340V, Queensland) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
indrema5q	acorn/aristmk5.cpp		no	no	no	yes	Indian Dreaming (0101340V, Queensland)	2000	Aristocrat	indrema5	indrema5

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	735	292	50.080128	16000000	1024	0	735	312	0	292	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
a562837.u36	343	1f269234	29940dd50fb55c632935f62ff44ca724379c7a43	gals	0	good	no	a562837.u36
a562838.u65	343	f2f3c40a	b795dfa5cc4e8127c3f3a0906664910d1325ec92	gals	200	good	no	a562838.u65
a562840.u22	343	941d4cdb	1ca091fba69e92f262dbb3d40f515703c8981793	gals	400	good	no	a562840.u22
0101340v.u7	524288	60b93091	6d4953b8312866f952b9658a680e8827bf2b5e57	game_prg	0	good	no
0101340v.u11	524288	34125c7d	c6e57346f2c53a04e858b01132abcb4d91403822	game_prg	2	good	no
0101340v.u8	524288	de715129	30c15bdfc9ee5c45e04b9f9eb614be89a911260b	game_prg	100000	good	no
0101340v.u12	524288	48d7b043	835d148db1e2ce7747a4410e3ceea4468355a164	game_prg	100002	good	no
0101340v.u9	524288	77c94665	48d786a323603d1315f94fef97de6f9d1311c688	game_prg	200000	good	no
0101340v.u13	524288	7ec9557e	8f143c1ee1c82d822ff66ec5b3dac03b0c911223	game_prg	200002	good	no

chip

type	tag	name	clock
cpu	maincpu	ARM	12000000
audio	vidc:speaker	Speaker
audio	vidc:dac0	16-Bit R-2R Twos Complement DAC
audio	vidc:dac1	16-Bit R-2R Twos Complement DAC
audio	vidc:dac2	16-Bit R-2R Twos Complement DAC
audio	vidc:dac3	16-Bit R-2R Twos Complement DAC
audio	vidc:dac4	16-Bit R-2R Twos Complement DAC
audio	vidc:dac5	16-Bit R-2R Twos Complement DAC
audio	vidc:dac6	16-Bit R-2R Twos Complement DAC
audio	vidc:dac7	16-Bit R-2R Twos Complement DAC

device_ref

name
arm_cpu
watchdog
memc
ioc
screen
acorn_vidc1a
speaker
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
93c56_16
93c56_16
nvram
ns16450
ns16450
ns16450
ns16450
ns16450
ns16450
ns16450
ns16450
ipt_merge_any_hi
ds1302
coin_hopper
rs232

sound

channels
1

feature

type	status	overall
timing	imperfect
graphics	imperfect
sound	imperfect

input

players	coins	service	tilt
1	1	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		15		no
gambling		8		no

port, analog

port_tag	analog_masks
:EXTRA
:P1
:P2
:P3
:P6

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
kart	terminal	serial_terminal	no
kart	sunkbd	sunkbd_adaptor	no
kart	dec_loopback	dec_rs232_loopback	no
kart	ie15	ie15_terminal	no
kart	null_modem	null_modem	no
kart	keyboard	serial_keyboard	no
kart	patch	rs232_patch_box	no
kart	swtpc8212	swtpc8212_terminal	no
kart	printer	serial_printer	no
kart	scorpion	scorpion_ic	no
kart	loopback	rs232_loopback	no
kart	mockingboard	mockingboardd	no
kart	msystems_mouse	rs232_mouse_hle_msystems	no
kart	nss_tvi	nss_tvinterface	no
kart	rs232_sync_io	rs232_sync_io	no
kart	pty	pseudo_terminal	no
kart	votraxtnt	serial_votraxtnt	no
kart	rs_printer	rs_serial_printer	no
