Intellivision Keyboard Component (Unreleased) - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
intvkbd	mattel/intv.cpp		no	no	no	yes	Intellivision Keyboard Component (Unreleased)	1981	Mattel Electronics	intv	intv

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	189	240	59.920000	2717971	189	0	189	240	0	240	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional	merge
exec.bin	8192	cbce86f7	5a65b922b562cb1f57dab51b73151283f0e20c7a	maincpu	2000	good	no	exec.bin
024.u60	4096	4f7998ec	ec006d0ae9002e9d56d83a71f5f2eddd6a456a40	maincpu	e000	good	no
4d72.u62	2048	aa57c594	741860d489d90f5882ca53daa3169b6abacdf130	maincpu	f000	good	no
4d71.u63	2048	069b2f0b	070850bb32f8474107cc52c5183cfaa32d640f9a	maincpu	f001	good	no
0104.u20	4096	5c6f1256	271931fb354dfae6a1a5697ee888924a89a15ca8	keyboard	c000	good	no
cpu2d.u21	4096	2c2dba33	0db5d177fec3f8ae89abeef2e6900ad4f3460266	keyboard	d000	good	no
4c52.u34	2048	cbeb2e96	f0e17adcd278fb376c9f90833c7fbbb60193dbe3	gfx1	0	good	no
0360.u58	32	1295528a	b35e598891f1185e02cbacb4811d2334357abd79	proms	0	good	no
0370.u74	32	19da5096	76af50e4fd29649fc4837120c245321a8fc84cd3	proms	20	good	no

type	tag	name	clock
cpu	maincpu	GI CP1610	894886
cpu	keyboard	MOS Technology 6502	894886
audio	mono	Speaker
audio	ay8914	AY-3-8914A PSG	1789772

tag	name	status	filter
cart_list	intv	original
ecs_list	intvecs	compatible

channels
1

device, instance

type	tag	interface	name	briefname
cartridge	cartslot	intv_cart	cartridge1	cart1
cartridge	ioslot1	intbasic_cart	cartridge2	cart2
cartridge	ioslot2	intbasic_cart	cartridge3	cart3

type	tag	interface	extension_names
cartridge	cartslot	intv_cart	bin, int, rom, itv
cartridge	ioslot1	intbasic_cart	bin
cartridge	ioslot2	intbasic_cart	bin

players	coins	service	tilt
2		no	no

port_tag	analog_masks
:ROW0
:ROW1
:ROW2
:ROW3
:ROW4
:ROW5
:ROW6
:ROW7
:ROW8
:ROW9
:TEST
:iopt_left_ctrl:handctrl:DISC_AN_X	255
:iopt_left_ctrl:handctrl:DISC_AN_Y	255
:iopt_left_ctrl:handctrl:DISC_DG
:iopt_left_ctrl:handctrl:KEYPAD
:iopt_left_ctrl:handctrl:OPTIONS
:iopt_right_ctrl:handctrl:DISC_AN_X	255
:iopt_right_ctrl:handctrl:DISC_AN_Y	255
:iopt_right_ctrl:handctrl:DISC_DG
:iopt_right_ctrl:handctrl:KEYPAD
:iopt_right_ctrl:handctrl:OPTIONS

slot_name	slotoption_name	slotoption_devname	slotoption_default
iopt_right_ctrl	handctrl	intv_handctrl	yes
iopt_left_ctrl	handctrl	intv_handctrl	yes
cartslot
ioslot1
ioslot2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Controller Disc Emulation	iopt_left_ctrl:handctrl:OPTIONS	1

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Digital	0	no
Analog	1	yes

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Controller Disc Emulation	iopt_right_ctrl:handctrl:OPTIONS	1

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Digital	0	no
Analog	1	yes
