mame (0289) • machine iris3130 • IRIS 3130

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
iris3130	sgi/iris.cpp		no	no	no	yes	IRIS 3130	1985	Silicon Graphics

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
iris3130	6375	29/12/2025 11:31:24	640	240	96	96	0	Format24bppRgb	305:MAME 0.180 (Nov 30 2016)	bed1cc11091e5c979be333e33240bb6e5444c2d3

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
slot2:ip2:port2:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	yes	no

chip

type	tag	name	clock
cpu	slot2:ip2:cpu	Motorola MC68020	16000000
cpu	slot3:nex:cpu	Intel 80186	16000000
cpu	slot4:dsd:mpu	Intel 8085A	5000000
cpu	slot4:dsd:dma	AM9517A	5000000
audio	slot2:ip2:port2:terminal:bell	Speaker
audio	slot2:ip2:port2:terminal:beeper	Beep	2000
audio	slot4:dsd:fdc0:525qd:flopsndout	Speaker
audio	slot4:dsd:fdc0:525qd:flopsnd	Floppy sound	44100

device_ref

tag	name
:bus	multibus
:slot1	multibus_slot
:slot2	multibus_slot
:slot2:ip2	sgi_ip2
:slot2:ip2:cpu	m68020
:slot2:ip2:irq1	ipt_merge_any_lo
:slot2:ip2:irq6	ipt_merge_any_lo
:slot2:ip2:irq7	ipt_merge_any_lo
:slot2:ip2:duart0	mc68681
:slot2:ip2:duart0:cha	duart_channel
:slot2:ip2:duart0:chb	duart_channel
:slot2:ip2:duart1	mc68681
:slot2:ip2:duart1:cha	duart_channel
:slot2:ip2:duart1:chb	duart_channel
:slot2:ip2:port1	rs232
:slot2:ip2:port2	rs232
:slot2:ip2:port2:terminal	serial_terminal
:slot2:ip2:port2:terminal:terminal_screen	screen
:slot2:ip2:port2:terminal:keyboard	generic_keyboard
:slot2:ip2:port2:terminal:bell	speaker
:slot2:ip2:port2:terminal:beeper	beep
:slot2:ip2:port3	rs232
:slot2:ip2:port4	rs232
:slot2:ip2:rtc	mc146818
:slot2:ip2:nvram	nvram
:slot3	multibus_slot
:slot3:nex	exos201
:slot3:nex:cpu	i80186
:slot3:nex:net	i82586
:slot4	multibus_slot
:slot4:dsd	dsd5217
:slot4:dsd:mpu	i8085a
:slot4:dsd:rwc	am2910
:slot4:dsd:rio	i8155
:slot4:dsd:dma	am9517a
:slot4:dsd:fdc0	floppy_connector
:slot4:dsd:fdc0:525qd	floppy_525_qd
:slot4:dsd:fdc0:525qd:flopsndout	speaker
:slot4:dsd:fdc0:525qd:flopsnd	flopsnd
:slot4:dsd:fdc1	floppy_connector
:slot4:dsd:hdd0	harddisk_image
:slot4:dsd:hdd1	harddisk_image
:slot4:dsd:qic	qic02_connector
:slot4:dsd:xfr	ipt_merge_any_hi
:slot5	multibus_slot
:slot6	multibus_slot
:slot7	multibus_slot
:slot8	multibus_slot
:slot9	multibus_slot
:slot10	multibus_slot
:slot11	multibus_slot
:slot12	multibus_slot
:slot13	multibus_slot
:slot14	multibus_slot
:slot15	multibus_slot
:slot16	multibus_slot
:slot17	multibus_slot
:slot18	multibus_slot
:slot19	multibus_slot
:slot20	multibus_slot

sound

channels
2

device, instance

type	tag	interface	name	briefname
floppydisk	slot4:dsd:fdc0:525qd	floppy_5_25	floppydisk	flop
harddisk	slot4:dsd:hdd0		harddisk1	hard1
harddisk	slot4:dsd:hdd1		harddisk2	hard2

device, extension

type	tag	interface	extension_names
floppydisk	slot4:dsd:fdc0:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
harddisk	slot4:dsd:hdd0		chd, hd, hdv, 2mg, hdi
harddisk	slot4:dsd:hdd1		chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		73		no

port, analog

port_tag	analog_masks
:slot2:ip2:SWITCH
:slot2:ip2:port2:terminal:RS232_DATABITS
:slot2:ip2:port2:terminal:RS232_PARITY
:slot2:ip2:port2:terminal:RS232_RXBAUD
:slot2:ip2:port2:terminal:RS232_STOPBITS
:slot2:ip2:port2:terminal:RS232_TXBAUD
:slot2:ip2:port2:terminal:TERM_CONF
:slot2:ip2:port2:terminal:keyboard:GENKBD_CFG
:slot2:ip2:port2:terminal:keyboard:GENKBD_MOD
:slot2:ip2:port2:terminal:keyboard:GENKBD_ROW0
:slot2:ip2:port2:terminal:keyboard:GENKBD_ROW1
:slot2:ip2:port2:terminal:keyboard:GENKBD_ROW2
:slot2:ip2:port2:terminal:keyboard:GENKBD_ROW3
:slot3:nex:J4-J7
:slot3:nex:J52
:slot3:nex:J53
:slot3:nex:J54
:slot3:nex:J9-J12
:slot4:dsd:W10
:slot4:dsd:W6
:slot4:dsd:W7
:slot4:dsd:W9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
slot1	nex	exos201	no
slot1	dsd	dsd5217	no
slot1	pm2	sgi_pm2	no
slot1	ip2	sgi_ip2	no
slot2	nex	exos201	no
slot2	dsd	dsd5217	no
slot2	pm2	sgi_pm2	no
slot2	ip2	sgi_ip2	yes
slot2:ip2:port1	kbd	iris_kbd	no
slot2:ip2:port2	terminal	serial_terminal	yes
slot2:ip2:port2	swtpc8212	swtpc8212_terminal	no
slot2:ip2:port2	sunkbd	sunkbd_adaptor	no
slot2:ip2:port2	rs_printer	rs_serial_printer	no
slot2:ip2:port2	rs232_sync_io	rs232_sync_io	no
slot2:ip2:port2	printer	serial_printer	no
slot2:ip2:port2	patch	rs232_patch_box	no
slot2:ip2:port2	s97801	s97801_terminal	no
slot2:ip2:port2	msystems_mouse	rs232_mouse_hle_msystems	no
slot2:ip2:port2	scorpion	scorpion_ic	no
slot2:ip2:port2	nss_tvi	nss_tvinterface	no
slot2:ip2:port2	mockingboard	mockingboardd	no
slot2:ip2:port2	loopback	rs232_loopback	no
slot2:ip2:port2	keyboard	serial_keyboard	no
slot2:ip2:port2	ie15	ie15_terminal	no
slot2:ip2:port2	null_modem	null_modem	no
slot2:ip2:port2	votraxtnt	serial_votraxtnt	no
slot2:ip2:port2	h19	serial_heath_h19	no
slot2:ip2:port2	dec_loopback	dec_rs232_loopback	no
slot2:ip2:port2	pty	pseudo_terminal	no
slot2:ip2:port2	auto3a	auto3a_terminal	no
slot2:ip2:port3	terminal	serial_terminal	no
slot2:ip2:port3	swtpc8212	swtpc8212_terminal	no
slot2:ip2:port3	sunkbd	sunkbd_adaptor	no
slot2:ip2:port3	rs_printer	rs_serial_printer	no
slot2:ip2:port3	rs232_sync_io	rs232_sync_io	no
slot2:ip2:port3	printer	serial_printer	no
slot2:ip2:port3	patch	rs232_patch_box	no
slot2:ip2:port3	s97801	s97801_terminal	no
slot2:ip2:port3	msystems_mouse	rs232_mouse_hle_msystems	no
slot2:ip2:port3	scorpion	scorpion_ic	no
slot2:ip2:port3	nss_tvi	nss_tvinterface	no
slot2:ip2:port3	mockingboard	mockingboardd	no
slot2:ip2:port3	loopback	rs232_loopback	no
slot2:ip2:port3	keyboard	serial_keyboard	no
slot2:ip2:port3	ie15	ie15_terminal	no
slot2:ip2:port3	null_modem	null_modem	no
slot2:ip2:port3	votraxtnt	serial_votraxtnt	no
slot2:ip2:port3	h19	serial_heath_h19	no
slot2:ip2:port3	dec_loopback	dec_rs232_loopback	no
slot2:ip2:port3	pty	pseudo_terminal	no
slot2:ip2:port3	auto3a	auto3a_terminal	no
slot2:ip2:port4	terminal	serial_terminal	no
slot2:ip2:port4	swtpc8212	swtpc8212_terminal	no
slot2:ip2:port4	sunkbd	sunkbd_adaptor	no
slot2:ip2:port4	rs_printer	rs_serial_printer	no
slot2:ip2:port4	rs232_sync_io	rs232_sync_io	no
slot2:ip2:port4	printer	serial_printer	no
slot2:ip2:port4	patch	rs232_patch_box	no
slot2:ip2:port4	s97801	s97801_terminal	no
slot2:ip2:port4	msystems_mouse	rs232_mouse_hle_msystems	no
slot2:ip2:port4	scorpion	scorpion_ic	no
slot2:ip2:port4	nss_tvi	nss_tvinterface	no
slot2:ip2:port4	mockingboard	mockingboardd	no
slot2:ip2:port4	loopback	rs232_loopback	no
slot2:ip2:port4	keyboard	serial_keyboard	no
slot2:ip2:port4	ie15	ie15_terminal	no
slot2:ip2:port4	null_modem	null_modem	no
slot2:ip2:port4	votraxtnt	serial_votraxtnt	no
slot2:ip2:port4	h19	serial_heath_h19	no
slot2:ip2:port4	dec_loopback	dec_rs232_loopback	no
slot2:ip2:port4	pty	pseudo_terminal	no
slot2:ip2:port4	auto3a	auto3a_terminal	no
slot3	nex	exos201	yes
slot3	dsd	dsd5217	no
slot3	pm2	sgi_pm2	no
slot3	ip2	sgi_ip2	no
slot4	nex	exos201	no
slot4	dsd	dsd5217	yes
slot4	pm2	sgi_pm2	no
slot4	ip2	sgi_ip2	no
slot4:dsd:fdc0	525qd	floppy_525_qd	yes
slot4:dsd:fdc1	525qd	floppy_525_qd	no
slot4:dsd:qic
slot5	nex	exos201	no
slot5	dsd	dsd5217	no
slot5	pm2	sgi_pm2	no
slot5	ip2	sgi_ip2	no
slot6	nex	exos201	no
slot6	dsd	dsd5217	no
slot6	pm2	sgi_pm2	no
slot6	ip2	sgi_ip2	no
slot7	nex	exos201	no
slot7	dsd	dsd5217	no
slot7	pm2	sgi_pm2	no
slot7	ip2	sgi_ip2	no
slot8	nex	exos201	no
slot8	dsd	dsd5217	no
slot8	pm2	sgi_pm2	no
slot8	ip2	sgi_ip2	no
slot9	nex	exos201	no
slot9	dsd	dsd5217	no
slot9	pm2	sgi_pm2	no
slot9	ip2	sgi_ip2	no
slot10	nex	exos201	no
slot10	dsd	dsd5217	no
slot10	pm2	sgi_pm2	no
slot10	ip2	sgi_ip2	no
slot11	gl1	sgi_gl1	no
slot12	gl1	sgi_gl1	no
slot13	gl1	sgi_gl1	no
slot14	gl1	sgi_gl1	no
slot15	gl1	sgi_gl1	no
slot16	gl1	sgi_gl1	no
slot17	gl1	sgi_gl1	no
slot18	gl1	sgi_gl1	no
slot19	gl1	sgi_gl1	no
slot20	gl1	sgi_gl1	no

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	slot2:ip2:port2:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	slot2:ip2:port2:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	slot2:ip2:port2:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	slot2:ip2:port2:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	slot2:ip2:port2:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	slot2:ip2:port2:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	slot2:ip2:port2:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	slot2:ip2:port2:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	slot2:ip2:port2:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	slot2:ip2:port2:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	slot2:ip2:port2:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	slot2:ip2:port2:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	slot2:ip2:port2:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	slot2:ip2:port2:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	slot2:ip2:port2:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	slot2:ip2:port2:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

dipswitch

Boot Media

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot Media	slot2:ip2:SWITCH	15

value

name	value	default
Hard Disk (IP, SD, MD)	0	no
Cartridge Tape	1	no
Floppy Disk (SF, MF)	2	no
Ethernet using XNS	3	no
Enter PROM Monitor	5	yes
Boot from PROM Board	6	no
TCP/UDP Netboot	7	no
Interphase SMD Disk Boot	9	no
Storager Tape Boot	10	no
Storager Floppy Boot	11	no
Storager Hard Disk Boot	12	no
DSD Tape Boot	13	no
DSD Floppy Boot	14	no
DSD Hard Disk Boot	15	no

Auto-Boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto-Boot	slot2:ip2:SWITCH	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Enter PROM Monitor	0	yes
Auto-Boot	16	no

Verbose Boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Verbose Boot	slot2:ip2:SWITCH	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Be Verbose	0	yes
Be Quiet	32	no

Enable Dual-Head Display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Enable Dual-Head Display	slot2:ip2:SWITCH	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Use Primary Display	0	yes
Use Secondary Display	64	no

Display Setting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display Setting	slot2:ip2:SWITCH	1792

value

name	value	default
60Hz Non-Interlaced / 60Hz Non-Interlaced	0	yes
60Hz Non-Interlaced / 30Hz Interlaced	256	no
60Hz Non-Interlaced / NTSC RS 170A	512	no
60Hz Non-Interlaced / PAL	768	no
30Hz Interlaced / 60Hz Non-Interlaced	1024	no
30Hz Interlaced / 30Hz Interlaced	1280	no
30Hz Interlaced / NTSC RS 170A	1536	no
30Hz Interlaced / PAL	1792	no

RS232 Console Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS232 Console Speed	slot2:ip2:SWITCH	6144

value

name	value	default
9600 Baud	0	yes
300 Baud	2048	no
1200 Baud	4096	no
19200 Baud	6144	no

Master/Slave

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Master/Slave	slot2:ip2:SWITCH	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Master	0	yes
Slave	32768	no

Disable Carrier Sense

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable Carrier Sense	slot3:nex:J4-J7	1

location

name	number	inverted
J5	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Boot from network

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot from network	slot3:nex:J4-J7	2

location

name	number	inverted
J6	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

256 Kbyte Memory

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
256 Kbyte Memory	slot3:nex:J4-J7	4

location

name	number	inverted
J7	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

512 Kbyte Memory

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
512 Kbyte Memory	slot3:nex:J4-J7	8

location

name	number	inverted
J4	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

I/O Port Address (A1)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A1)	slot3:nex:J52	1

location

name	number	inverted
J52	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

I/O Port Address (A2)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A2)	slot3:nex:J52	2

location

name	number	inverted
J52	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

I/O Port Address (A3)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A3)	slot3:nex:J52	4

location

name	number	inverted
J52	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

I/O Port Address (A4)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A4)	slot3:nex:J52	8

location

name	number	inverted
J52	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

I/O Port Address (A5)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A5)	slot3:nex:J52	16

location

name	number	inverted
J52	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

I/O Port Address (A6)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A6)	slot3:nex:J52	32

location

name	number	inverted
J52	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

I/O Port Address (A7)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A7)	slot3:nex:J52	64

location

name	number	inverted
J52	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

I/O Port Address (A8)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A8)	slot3:nex:J53	1

location

name	number	inverted
J53	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

I/O Port Address (A9)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A9)	slot3:nex:J53	2

location

name	number	inverted
J53	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

I/O Port Address (A10)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A10)	slot3:nex:J53	4

location

name	number	inverted
J53	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

I/O Port Address (A11)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A11)	slot3:nex:J53	8

location

name	number	inverted
J53	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

I/O Port Address (A12)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A12)	slot3:nex:J53	16

location

name	number	inverted
J53	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

I/O Port Address (A13)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A13)	slot3:nex:J53	32

location

name	number	inverted
J53	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

I/O Port Address (A14)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A14)	slot3:nex:J53	64

location

name	number	inverted
J53	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

I/O Port Address (A15)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Port Address (A15)	slot3:nex:J53	128

location

name	number	inverted
J53	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Interrupt Level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Interrupt Level	slot3:nex:J54	255

location

name	number	inverted
J54	1	no
J54	2	no
J54	3	no
J54	4	no
J54	5	no
J54	6	no
J54	7	no
J54	8	no

value

name	value	default
0	1	no
1	2	no
2	4	yes
3	8	no
4	16	no
5	32	no
6	64	no
7	128	no

DBUG

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DBUG	slot3:nex:J9-J12	1

location

name	number	inverted
J9	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

BUF DMA

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
BUF DMA	slot3:nex:J9-J12	2

location

name	number	inverted
J10	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Disable SQE (Heartbeat) check

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable SQE (Heartbeat) check	slot3:nex:J9-J12	4

location

name	number	inverted
J11	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

NON STD CON

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
NON STD CON	slot3:nex:J9-J12	8

location

name	number	inverted
J12	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	0	no

Interrupt Priority Level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Interrupt Priority Level	slot4:dsd:W10	255

location

name	number	inverted
W10	1	yes
W10	2	yes
W10	3	yes
W10	4	yes
W10	5	yes
W10	6	yes
W10	7	yes
W10	8	yes

value

name	value	default
0	254	no
1	253	yes
2	251	no
3	247	no
4	239	no
5	223	no
6	191	no
7	127	no

Diagnostic Routine

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Diagnostic Routine	slot4:dsd:W6	31	W6	32	eq	32

location

name	number	inverted
W6	1	yes
W6	2	yes
W6	3	yes
W6	4	yes
W6	5	yes

value

name	value	default
8085 Environment Self-Test	0	yes
Winchester PLL Alignment	1	no
Floppy Double-Density PLL Alignment	2	no
Floppy Single-Density PLL Alignment	3	no
R/WC Self-Test	4	no
CR1, CR2 Blinking Wakeup Address	5	no
Floppy Drive 0	6	no
Floppy Drive 1	7	no
Winchester Drive 0	8	no
Winchester Drive 1	9	no
Tape Drive	10	no
Stand Alone System	11	no
Multibus Read/Write	12	no

Floppy Drive Class

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Floppy Drive Class	slot4:dsd:W6	3	W6	32	eq	0

location

name	number	inverted
W6	1	yes
W6	2	yes

value

name	value	default
0	0	yes
1	1	no
2	2	no
3 Reserved	3	no

Winchester Drive Class

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Winchester Drive Class	slot4:dsd:W6	28	W6	32	eq	0

location

name	number	inverted
W6	3	yes
W6	4	yes
W6	5	yes

value

name	value	default
0	0	no
1	4	no
2	8	no
3	12	no
4	16	no
5	20	yes
6	24	no
7 Reserved	28	no

Diagnostics

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Diagnostics	slot4:dsd:W6	32

location

name	number	inverted
W6	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Enabled	32	no
Disabled	0	yes

Wake-up Address (A8)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A8)	slot4:dsd:W7	1

location

name	number	inverted
W7	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Wake-up Address (A9)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A9)	slot4:dsd:W7	2

location

name	number	inverted
W7	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Wake-up Address (A10)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A10)	slot4:dsd:W7	4

location

name	number	inverted
W7	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Wake-up Address (A11)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A11)	slot4:dsd:W7	8

location

name	number	inverted
W7	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Wake-up Address (A12)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A12)	slot4:dsd:W7	16

location

name	number	inverted
W7	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Wake-up Address (A13)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A13)	slot4:dsd:W7	32

location

name	number	inverted
W7	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Wake-up Address (A14)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A14)	slot4:dsd:W7	64

location

name	number	inverted
W7	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Wake-up Address (A15)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A15)	slot4:dsd:W7	128

location

name	number	inverted
W7	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Wake-up Address (A0)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A0)	slot4:dsd:W9	1

location

name	number	inverted
W9	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Wake-up Address (A1)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A1)	slot4:dsd:W9	2

location

name	number	inverted
W9	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Wake-up Address (A2)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A2)	slot4:dsd:W9	4

location

name	number	inverted
W9	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

Wake-up Address (A3)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A3)	slot4:dsd:W9	8

location

name	number	inverted
W9	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Wake-up Address (A4)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A4)	slot4:dsd:W9	16

location

name	number	inverted
W9	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

Wake-up Address (A5)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A5)	slot4:dsd:W9	32

location

name	number	inverted
W9	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

Wake-up Address (A6)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A6)	slot4:dsd:W9	64

location

name	number	inverted
W9	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Wake-up Address (A7)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Wake-up Address (A7)	slot4:dsd:W9	128

location

name	number	inverted
W9	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes
