Ivan The Terrible (H8/3256 version) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ivanto	excalibur/ivanto.cpp		no	no	no	yes	Ivan The Terrible (H8/3256 version)	1996	Excalibur Electronics	ivant	ivant

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	svg	0	384	139	60.000000	3202560	384	0	384	139	0	139	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
at27c256r.ic11	32768	51a97959	ea595001fd5eaa07ade96307a8d89d5fb44682ab	maincpu	0	good	no
1996_701e_excalibur_ivan_t.ic2	1048576	f7c386a1	357ca0b0c0b1409d33876b6fa00c5ad74b2643fc	rombank	0	good	no
regency.svg	109652	6840c49e	a9c91143c5bea5ab41fe323e719da4a46ab9d631	screen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi H8/3256	20000000
audio	speaker	Speaker
audio	dac	8-Bit R-2R DAC

device_ref

name
h83256
h8325_intc
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_timer8_channel
h8_timer8_channel
h8_timer16
h8325_timer16_channel
h8_sci
h8_sci
sensorboard
pwm_display
screen
speaker
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		16		no

port, analog

port_tag	analog_masks
:BATT
:IN.0
:IN.1
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

Battery Status

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Battery Status	BATT	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Low	8	no
Normal	0	yes

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes
