Pinnacle (JPM) (MPS) - mame (0288) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j2pinac	jpm/jpmmps.cpp		no	no	yes	yes	Pinnacle (JPM) (MPS)	198?	JPM

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
pinnacle4.1	32768	1c24a9e9	da9e7555f405d2506e8cb2fad7595c5e6c08f659	maincpu	0	good	no
pinnacle4.2	32768	ca86ee0c	8857961f14ec7822985938a7758037c39f6540bd	maincpu	8000	good	no
pinnacle_3_1.bin	32768	e41c6510	ae2ae4c1c614e31f30269c85e4bef529a44f0529	altrevs	0	good	no
pinnacle_3_2.bin	32768	2dcc17d4	9193b91d64cbcf44da7df0bf3ddb80c25408ac84	altrevs	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS9995	6000000
audio	mono	Speaker
audio	sn	SN76489	1500000

device_ref

tag	name
:maincpu	tms9995
:mainlatch	ls259
:ppi8255_ic26	i8255
:ppi8255_ic21	i8255
:ppi8255_ic22	i8255
:ppi8255_ic25	i8255
:tms9902_ic10	tms9902
:tms9902_ic5	tms9902
:mono	speaker
:sn	sn76489
:meters	meters

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
0		no	no
