Breakout (JPM) (IMPACT) (set 1) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6brkout	jpm/jpmimpctsw.cpp		no	no	yes	yes	Breakout (JPM) (IMPACT) (set 1)	199?	JPM

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
bk30cz_04_1.b8	131072	b6e8611d	c2cf0e73d4a3fb94320abe48a76e9fff692b4a9c	maincpu	0	good	no
bk30cz_04_2.b8	131072	b243e4eb	093fec6e46c1c26e73011fca1ff8b7f847d27d96	maincpu	1	good	no
bksnd.bin	524288	f72bd4f4	ef8651fe7bb5f5340e41d35ca0669cba7d9c1372	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
mc68681
duart_channel
duart_channel
timer
nvram
i8255
timer
timer
timer
timer
timer
timer
speaker
upd7759
meters
bacta_datalogger
s16lf01
stepper
stepper
stepper
stepper
stepper
stepper

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	6	yes	no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO

configuration

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	J10_0	15

setting

name	value	default
Not Fitted	15	no
0x0e	14	no
0x0d	13	no
0x0c	12	no
0x0b	11	no
8 GBP Cash	10	no
8 GBP Token	9	no
10 GBP Cash	8	yes
5 GBP	7	no
15 GBP	6	no
25 GBP	5	no
0x04	4	no
0x03	3	no
0x02	2	no
0x01	1	no
0x00	0	no

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	J10_0	112

setting

name	value	default
0x00	0	no
0x10	16	no
0x20	32	no
30p	48	no
25p	64	no
20p	80	no
10p	96	yes
5p	112	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	J10_0	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	128	yes

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	PERCENT	15

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	15	no
70	14	no
72	13	no
74	12	no
76	11	no
78	10	no
80	9	no
82	8	no
84	7	no
86	6	no
88	5	no
90	4	no
92	3	no
94	2	no
96	1	no
98	0	yes
