Camelot (JPM) (IMPACT) (CA8P C10, Protocol) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6camelta	jpm/jpmimpctsw.cpp		no	no	yes	yes	Camelot (JPM) (IMPACT) (CA8P C10, Protocol)	199?	JPM	j6camelt	j6camelt

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
20300.bin	131072	76e96f30	28e65cdc38a93652f4650b48e1c3ff689b13c8bd	maincpu	0	good	no
20299.bin	131072	740b93b2	cd4ffab8d5c229f236c4771f3d1ff6d7ea94074d	maincpu	1	good	no	20299.bin
camsound.bin	524288	70d5a16f	0e8ec67387274298637598bf1ab8c479aa108c54	upd	0	good	no	camsound.bin

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
mc68681
duart_channel
duart_channel
timer
nvram
i8255
timer
timer
timer
timer
timer
timer
speaker
upd7759
meters
bacta_datalogger
s16lf01
stepper
stepper
stepper
stepper
stepper
stepper

sound

channels
1

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		11		no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO

configuration

Jackpot / Prize Key
