Golden Goal (JPM) (IMPACT) (set 1)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6goldgl	jpm/jpmimpctsw.cpp		no	no	yes	yes	Golden Goal (JPM) (IMPACT) (set 1)	199?	JPM

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
goal-11.bin	131072	124870c1	7f42ae51f342beaf0c53f46df437ea81772f1005	maincpu	0	good	no
goal-12.bin	131072	5e292400	74d6a480881b4fb5deac921517e8c07586ade4f3	maincpu	1	good	no
goldengoalsnd.bin	524288	3af9ccdb	4a911a48816bc69743ba1ba18fdd913041636ae1	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

tag	name
:maincpu	m68000
:main_duart	mc68681
:main_duart:cha	duart_channel
:main_duart:chb	duart_channel
:ip5wtimer	timer
:nvram	nvram
:ppi8255	i8255
:cointimer0	timer
:cointimer1	timer
:cointimer2	timer
:cointimer3	timer
:cointimer4	timer
:cointimer5	timer
:mono	speaker
:upd	upd7759
:meters	meters
:datalogger	bacta_datalogger
:vfd	s16lf01
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper
:reel4	stepper
:reel5	stepper

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	6	yes	no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
