Sonic The Hedgehog (JPM) (IMPACT) (SO10 C13)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6sonic	jpm/jpmimpctsw.cpp		no	no	yes	yes	Sonic The Hedgehog (JPM) (IMPACT) (SO10 C13)	199?	JPM

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
j6sonic	63771	29/12/2025 11:31:25	640	526	96	96	0	Format24bppRgb	305:MAME 0.229 (Feb 24 2021)	9a28c338c3317ed871ad23c06f588d16cd51219d

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
9440.bin	131072	384f931e	12bddb3dc2c1bc6c51c5ef4002673c6f45fa335c	maincpu	0	good	no
9441.bin	131072	cba4c367	ad926216081797b81b93eb111bf8fd50b289c9e2	maincpu	1	good	no
son_snd.bin	524288	5cd8cf21	82f875a59d678ef548173ee2c202e3963bc13116	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

tag	name
:maincpu	m68000
:main_duart	mc68681
:main_duart:cha	duart_channel
:main_duart:chb	duart_channel
:ip5wtimer	timer
:nvram	nvram
:ppi8255	i8255
:cointimer0	timer
:cointimer1	timer
:cointimer2	timer
:cointimer3	timer
:cointimer4	timer
:cointimer5	timer
:mono	speaker
:upd	upd7759
:meters	meters
:datalogger	bacta_datalogger
:vfd	s16lf01
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper
:reel4	stepper
:reel5	stepper

sound

channels
1

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		8		no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO

configuration

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	J10_0	15

setting

name	value	default
Not Fitted	15	no
0x0e	14	no
0x0d	13	no
0x0c	12	no
0x0b	11	no
0x0a	10	no
8 GBP Token	9	no
10 GBP Cash	8	yes
0x07	7	no
0x06	6	no
0x05	5	no
0x04	4	no
0x03	3	no
0x02	2	no
0x01	1	no
0x00	0	no

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	J10_0	112

setting

name	value	default
0x00	0	no
0x10	16	no
0x20	32	no
0x30	48	no
0x40	64	no
0x50	80	no
10p	96	yes
5p	112	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	J10_0	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	128	yes

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	PERCENT	15

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	15	no
70	14	no
72	13	no
74	12	no
76	11	no
78	10	no
80	9	no
82	8	no
84	7	no
86	6	no
88	5	no
90	4	no
92	3	no
94	2	no
96	1	no
98	0	yes
