Super Breakout (JPM) (IMPACT) (set 1)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6supbrk	jpm/jpmimpctsw.cpp		no	no	yes	yes	Super Breakout (JPM) (IMPACT) (set 1)	199?	JPM

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
subr-2_1.bin	131072	85222c75	1fbed0f474a7ccfb523270b913a8adb41c8be388	maincpu	0	good	no
subr-2_2.bin	131072	bd0c6f72	df0daea8c89b1f1c7a12fd7e4e54ad6a562bb1df	maincpu	1	good	no
subr-snd.bin	524288	d2439c80	8c80927e0d0c139293bd588fad15941bfb54674d	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

tag	name
:maincpu	m68000
:main_duart	mc68681
:main_duart:cha	duart_channel
:main_duart:chb	duart_channel
:ip5wtimer	timer
:nvram	nvram
:ppi8255	i8255
:cointimer0	timer
:cointimer1	timer
:cointimer2	timer
:cointimer3	timer
:cointimer4	timer
:cointimer5	timer
:mono	speaker
:upd	upd7759
:meters	meters
:datalogger	bacta_datalogger
:vfd	s16lf01
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper
:reel4	stepper
:reel5	stepper

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		11		no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO

configuration

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	J10_0	15

setting

name	value	default
Not Fitted	15	no
0x0e	14	no
0x0d	13	no
0x0c	12	no
0x0b	11	no
0x0a	10	no
0x09	9	no
0x08	8	no
0x07	7	no
15 GBP	6	yes
0x05	5	no
0x04	4	no
0x03	3	no
0x02	2	no
0x01	1	no
0x00	0	no

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	J10_0	112

setting

name	value	default
0x00	0	no
0x10	16	no
0x20	32	no
0x30	48	no
25p	64	yes
0x50	80	no
0x60	96	no
0x70	112	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	J10_0	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	128	yes

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	PERCENT	15

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	15	no
70	14	no
72	13	no
74	12	no
76	11	no
78	10	no
80	9	no
82	8	no
84	7	no
86	6	no
88	5	no
90	4	no
92	3	no
94	2	no
96	1	no
98	0	yes
