Kajot Card (Version 1.01, Wien Euro) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
kajotcrd	misc/magicard.cpp		no	no	no	yes	Kajot Card (Version 1.01, Wien Euro)	1993	Amatic

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	768	280	50.080128	15000000	960	0	768	312	32	312	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
01.ic21	524288	674aa36e	483eb09950ff7c43a7147378f2e68d113c856905	maincpu	0	good	no
02.ic22	524288	ae52803e	27f917b0f8b302bdab930e304b4977a4b8192cd5	maincpu	80000	good	no
x24c02.ic26	256	0f143d6f	c293728a997cd0868705dced55955072c6ebf5c0	sereeprom	0	good	no
ds2401	8	3f87b999	29649749d521ced9dc7ef1d0d6ddb9a8beea360f	serial_id	0	baddump	no

chip

type	tag	name	clock
cpu	maincpu	Philips SCC68070	19660800
audio	mono	Speaker
audio	ssg	YMZ284 SSGL	4000000

device_ref

name
scc68070
screen
scc66470
palette
ramdac
speaker
nvram
ymz284
rtc72421
ds2401
ds1207
24c02

sound

channels
1

input

players	coins	service	tilt
1	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
gambling		10		no

port, analog

port_tag	analog_masks
:IN0
:IN1

dipswitch

Keyboard Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Keyboard Test	IN1	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Remote/Keyboard

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remote/Keyboard	IN1	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Remote Switch	2	yes
Keyboard	0	no

Swap Coin Inputs

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Swap Coin Inputs	IN1	4

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	yes
Yes	0	no

Setting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Setting	IN1	56

location

name	number	inverted
SW1	5	no
SW1	4	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Austria 1	56	yes
Austria 2	48	no
CSFR 1	24	no
CSFR 2	16	no
Germany 1	40	no
Germany 2	32	no
Hungary 1	8	no
Hungary 2	0	no

Hopper

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper	IN1	64

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin B	64	yes
Coin A	0	no

Hopper

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper	IN1	128

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
