Kimble Double HI-LO - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
kimbldhl	misc/norautp.cpp		no	no	no	yes	Kimble Double HI-LO	198?	Kimble Ireland

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	464	248	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
jpc525611.bin	32768	4a3f1aef	570ef733989da6e89f0387f1e80b934cec7a7663	maincpu	0	good	no
quizcharll.bin	2048	4edb4717	466556595abfbc11e31f2b0d9ca0213bd649253c	gfx	800	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8080	2000000
audio	mono	Speaker
audio	discrete	Discrete Sound

device_ref

name
i8080
nvram
i8255
i8255
i8255
screen
gfxdecode
palette
coin_hopper
speaker
discrete

sound

channels
1

feature

type	status	overall
protection	imperfect

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
gambling		13		no

port, analog

port_tag	analog_masks
:DSW1
:IN0
:IN1
:IN2

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	1

location

name	number	inverted
DSW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	2

location

name	number	inverted
DSW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	4

location

name	number	inverted
DSW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Random Raise Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Random Raise Bet	DSW1	8

location

name	number	inverted
DSW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	16

location

name	number	inverted
DSW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	32

location

name	number	inverted
DSW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
A=5; B=25; C=1	32	yes
A=50; B=25; C=5	0	no

Hopper Payment

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper Payment	DSW1	64

location

name	number	inverted
DSW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	64	yes
Yes	0	no

Set Value

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Set Value	DSW1	128

location

name	number	inverted
DSW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Pence	128	yes
10 Pence	0	no
