mame (0289) • machine kn5000 • SX-KN5000

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
kn5000	matsushita/kn5000.cpp		no	no	no	yes	SX-KN5000	1998	Technics

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
kn5000	16877	29/12/2025 11:31:26	640	320	96	96	0	Format24bppRgb	305:MAME 0.269.0 (Aug 29 2024)	a32dd1c1b6836a86b5042b81ffffea984827c1db

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	lcd	0	320	240	60.012477	6666666	424	0	320	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
kn5000_custom_data_rom.ic19	1048576	5de11a6b	4709f815d3d03ce749c51f4af78c62bf4a5e3d94	custom_data	0	good	no
kn5000_rhythm_data_rom.ic14	4194304	76d11a5e	e4b572d318c9fe7ba00e5b44ea783e89da9c68bd	rhythm_data	0	good	no
kn5000_subcpu_boot.ic30	131072	a45ceb77	d29429a9a1ef7a718fa88c1aa38d0f7238ba5d94	subcpu	0	baddump	no
kn5000_subprogram_v140_compressed.rom	93124	5b182629	13098dd150c5a6083a5d15a63d5d785802d8e8ae	custom_data	e0000	good	no	v6
kn5000_subprogram_v140_compressed.rom	93124	5b182629	13098dd150c5a6083a5d15a63d5d785802d8e8ae	custom_data	e0000	good	no	v5
kn5000_subprogram_v141_compressed.rom	93181	c6d4ad98	ac9791441ceb13748a2196a0a6a400431d6aed5e	custom_data	e0000	good	no	v8
kn5000_subprogram_v141_compressed.rom	93181	c6d4ad98	ac9791441ceb13748a2196a0a6a400431d6aed5e	custom_data	e0000	good	no	v7
kn5000_subprogram_v142_compressed.rom	93203	f81e598f	13718900afd55cb2e5ff0be213ba1f5dd14bc174	custom_data	e0000	good	no	v10
kn5000_subprogram_v142_compressed.rom	93203	f81e598f	13718900afd55cb2e5ff0be213ba1f5dd14bc174	custom_data	e0000	good	no	v9
kn5000_table_data_rom_even.ic3	1048576	b6f0becd	1fd2604236b8d12ea7281fad64d72746eb00c525	table_data	0	good	no
kn5000_table_data_rom_odd.ic1	1048576	cd907eac	bedf09d606d476f3e6d03e590709715304cf7ea5	table_data	2	good	no
kn5000_v10_program.rom	2097152	00303406	1f2abc5b1b7b9e16fdf796f26d939edaceded354	program	0	good	no	v10
kn5000_v3_program.rom	2097152			program	0	nodump	no	v3
kn5000_v4_program.rom	2097152			program	0	nodump	no	v4
kn5000_v5_program.rom	2097152	fbd035e3	7b69a8aaa84ee3d337acc0c29c34154c5da2df32	program	0	good	no	v5
kn5000_v6_program.rom	2097152	0205db30	51108e2d75b180a034395e90bd40ca2bd2a0adfb	program	0	good	no	v6
kn5000_v7_program.rom	2097152	a5a25eb0	4c682cb248034a2de04c688b0a45654b8726bffb	program	0	good	no	v7
kn5000_v8_program.rom	2097152	46b4b242	a10a6f5a35175b74c3cfb42cef3bdf571c2858bb	program	0	good	no	v8
kn5000_v9_program.rom	2097152	c791d765	d9a3b462b1f9302402e8d37aacd15f069f56abd9	program	0	good	no	v9
kn5000_waveform_rom.ic304	4194304			waveform	0	nodump	no
kn5000_waveform_rom.ic305	4194304			waveform	400000	nodump	no
kn5000_waveform_rom.ic306	4194304			waveform	800000	nodump	no
kn5000_waveform_rom.ic307	4194304	20ff4629	4b511bff6625f4655cabd96a263bf548d2ef4bf7	waveform	c00000	good	no

chip

type	tag	name	clock
cpu	maincpu	Toshiba TMP94C241	16000000
cpu	subcpu	Toshiba TMP94C241	20000000
audio	fdc:0:35dd:flopsndout	Speaker
audio	fdc:0:35dd:flopsnd	Floppy sound	44100

device_ref

tag	name
:maincpu	tmp94c241
:maincpu:serial0	tmp94c241_serial
:maincpu:serial1	tmp94c241_serial
:cpanel	kn5000_cpanel
:subcpu	tmp94c241
:subcpu:serial0	tmp94c241_serial
:subcpu:serial1	tmp94c241_serial
:maincpu_latch	generic_latch_8
:subcpu_latch	generic_latch_8
:fdc	upd72067
:fdc:0	floppy_connector
:fdc:0:35dd	floppy_35_dd
:fdc:0:35dd:flopsndout	speaker
:fdc:0:35dd:flopsnd	flopsnd
:extension	kn5000_extension_connector
:screen	screen
:vga	mn89304_vga

biosset

name	description	default
v10	Version 10 - August 2nd, 1999	yes
v9	Version 9 - January 26th, 1999	no
v8	Version 8 - November 13th, 1998	no
v7	Version 7 - June 26th, 1998	no
v6	Version 6 - January 16th, 1998	no
v5	Version 5 - November 12th, 1997	no
v4	Version 4	no
v3	Version 3	no

sound

channels
1

feature

type	status	overall
sound	unemulated

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:35dd	floppy_3_5			floppydisk	flop

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:35dd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		131		no

port, analog

port_tag	analog_masks
:AREA
:CN11
:CN12
:COM_SELECT
:CPL_SEG0
:CPL_SEG1
:CPL_SEG10
:CPL_SEG2
:CPL_SEG3
:CPL_SEG4
:CPL_SEG5
:CPL_SEG6
:CPL_SEG7
:CPL_SEG8
:CPL_SEG9
:CPR_SEG0
:CPR_SEG1
:CPR_SEG10
:CPR_SEG2
:CPR_SEG3
:CPR_SEG4
:CPR_SEG5
:CPR_SEG6
:CPR_SEG7
:CPR_SEG8
:CPR_SEG9
:vga:VGA_SENSE

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	35dd	floppy_35_dd	yes
extension	hdae5000	hdae5000	no

dipswitch

Area Selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Area Selection	AREA	6

value

name	value	default
Thailand, Indonesia, Iran, U.A.E., Panama, Argentina, Peru, Brazil	2	no
USA, Mexico	4	no
Other	6	yes

Main CPU Checking Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Main CPU Checking Device	CN11	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	1	yes

Sub CPU Checking Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sub CPU Checking Device	CN12	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	1	yes

Computer Interface Selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Computer Interface Selection	COM_SELECT	240

value

name	value	default
MIDI	224	yes
PC1	208	no
PC2	176	no
Mac	112	no
