Gaishi Xingxiong Tebie Ban (bootleg of Knights of Valour Super Heroes Plus, V302CN, Dec 29 2010 16:31:32) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
kovgsyx	igs/pgm.cpp		no	no	no	yes	Gaishi Xingxiong Tebie Ban (bootleg of Knights of Valour Super Heroes Plus, V302CN, Dec 29 2010 16:31:32)	2010	bootleg (WDF)	kovshp	kovshp

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	448	224	59.185606	10000000	640	0	448	264	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
pgm_p02s.u20	131072	78c15fa2	885a6558e022602cc6f482ac9667ba9f61e75092	maincpu	0	good	no	pgm_p02s.u20	v2
pgm_p01s.u20	131072	e42b166e	2a9df9ec746b14b74fae48b1a438da14973702ea	maincpu	0	good	no	pgm_p01s.u20	v1
27c322.u3	4194304	4018559f	e7e97ce89e1f563e8e08501ec3c2be6d81107253	maincpu	100000	good	no
qhsg_prot.c51	16384	0f09a5c1	621b38c05f33277608d58b49822aebc930ae4870	prot	0	baddump	no	kovsh_v100_china.asic
pgm_t01s.rom	2097152	1a7123a0	cc567f577bfbf45427b54d6695b11b74f2578af3	igs023	0	good	no	pgm_t01s.rom
t01.u8	16777216	d498d97f	97a7b6d2ed1170449e7c2899448af7cbbca4c94f	igs023	180000	good	no
a01.u8	16777216	25ae3efd	083d977602ddb5ad54fbdcba000cd4287de8d463	igs023:sprcol	0	good	no
a23.u9	16777216	1f51c140	638a7449449716a2ae862a11b4333c09d369050a	igs023:sprcol	1000000	good	no
a45.u10	16777216	5e44fd82	bb7b9258a37a7fc7caf14ac5b606dd0ce6d43135	igs023:sprcol	2000000	good	no
b01.u6	16777216	779825d3	eb179111eb4f0c98d502622f094b1e5aa1f98225	igs023:sprmask	0	good	no
pgm_m01s.rom	2097152	45ae7159	d3ed3ff3464557fd0df6b069b2e431528b0ebfa8	ics	0	good	no	pgm_m01s.rom
m01.u5	16777216	af5e9be0	be9da327f2a26bf14a6bc1c0b2dd114ac13b8c74	ics	400000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	20000000
cpu	soundcpu	Zilog Z80	8467200
cpu	prot	ARM7 (little)	20000000
audio	mono	Speaker
audio	ics	ICS2115 WaveFront Synthesizer	33868800

device_ref

name
m68000
timer
z80
nvram
v3021
screen
palette
speaker
generic_latch_8
generic_latch_8
generic_latch_8
igs023
ics2115
arm7_le

biosset

name	description	default
v2	PGM BIOS V2	no
v1	PGM BIOS V1	no

sound

channels
1

feature

type	status	overall
protection	imperfect
sound	imperfect

input

players	coins	service	tilt
4	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2	4	8	no
joy	3	4	8	no
joy	4	4	8	no

port, analog

port_tag	analog_masks
:DSW
:P1P2
:P3P4
:Region
:RegionHack
:Service

configuration

Region

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Region	RegionHack	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
China	0	no
Taiwan	1	no
Japan (Alta license)	2	no
Korea	3	no
Hong Kong	4	no
World	5	no
Untouched	255	yes

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Music

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Music	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Voice

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Voice	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Free

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Stop

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop	DSW	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
