Live Action Football - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
liveafb	handheld/hh_tms1k.cpp		no	no	no	yes	Live Action Football	1980	Kenner

snap

Live Action Football png snap

Live Action Football jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
liveafb	18536	29/12/2025 11:31:26	640	377	96	96	0	Format24bppRgb	305:MAME 0.242 (Apr 1 2022)	032dc8d1ea5c42678ec0ce4aca61ce5c7d8341fd

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
mask	svg	0	1834	1080	60.000000	118843200	1834	0	1834	1080	0	1080	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
mp3489	2048	1fe05ab3	a8d7dfed61a6397b7af1d3fcf17b26d5d917b4f0	maincpu	0	good	no
tms1100_common1_micro.pla	867	62445fc9	d6297f2a4bc7a870b76cc498d19dbb0ce7d69fec	maincpu:mpla	0	good	no
tms1100_liveafb_output.pla	365	a7bc9384	fab458de394eeddbf5ba0830853a915e51f909c6	maincpu:opla	0	good	no
liveafb.svg	162058	046078d0	68a5775f4f9a1258c06b76839e1cfdab69b61920	mask	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS1100	350000
audio	mono	Speaker
audio	speaker	Filtered DAC

device_ref

tag	name
:maincpu	tms1100
:maincpu:mpla	pla
:maincpu:opla	pla
:mask	screen
:display	pwm_display
:mono	speaker
:speaker	speaker_sound_device

sound

channels
1

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
joy	1	3	vertical2	no
dial	1			no	0	127	100	10
joy	2	1	vertical2	no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
:ROLLER	127

configuration

Players

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Players	IN.3	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	8	yes
2	0	no
