Spot Light (Barcrest) (MPU2) (revision 7, 10p Stake, £2 Jackpot) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
m2splitea	barcrest/mpu1.cpp	fruitsamples	no	no	yes	yes	Spot Light (Barcrest) (MPU2) (revision 7, 10p Stake, £2 Jackpot)	1981	Barcrest	m2splite	m2splite

snap

Spot Light (Barcrest) (MPU2) (revision 7, 10p Stake, £2 Jackpot) png snap

Spot Light (Barcrest) (MPU2) (revision 7, 10p Stake, £2 Jackpot) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
m2splitea	11934	29/12/2025 11:31:29	492	640	96	96	0	Format24bppRgb	305:MAME 0.258.0 (Aug 30 2023)	62b20646d18529cd3e6e05b7a7d0bc8c5fef64f2

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
scm39199.bin	2048	198d77ee	ef466e539efd6e31c82ef01b09d63b7580f068fe	maincpu	1000	good	no	scm39199.bin
spl7.p1	2048	1ebfabe1	15fc6ef1fe57eac9d74021b5eba63f3956b6a4b8	maincpu	800	good	no
spl7.p2	2048	ca2191ff	54dd6cf2c1c47795a29caf638a3f2c2bf81a011e	maincpu	1800	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6800	1000000
audio	mono	Speaker
audio	dac	1-Bit DAC
audio	samples:fruitmech	Speaker
audio	samples:samples	Samples

device_ref

tag	name
:maincpu	m6800
:nmi	timer
:pia1	pia6821
:pia2	pia6821
:mono	speaker
:dac	dac
:samples	fruit_samples
:samples:fruitmech	speaker
:samples:samples	samples
:pia3	pia6821
:pia4	pia6821
:reel0	stepper
:reel1	stepper
:reel2	stepper

sample

name
payout
meter
buzzer
em_reel_start
em_reel_stop

sound

channels
2

input

players	coins	service	tilt
1	3	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
gambling		9		no

port, analog

port_tag	analog_masks
:COIN
:IN
:IN_PIA3
:IN_PIA4

configuration

Token tube

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token tube	IN	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Full	0	yes
Empty	1	no
