Macross II (Korea) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
macross2k	nmk/nmk16.cpp		no	no	no	yes	Macross II (Korea)	1993	Banpresto	macross2	macross2

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	224	56.205036	8000000	512	28	412	278	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1.3	524288	1506fcfc	638ccc90effde3be20ab9b4da3a0d75af2577e51	maincpu	0	good	no
mcrs2j.2	131072	b4aa8ac7	73a6de56cbfb468450d9b39fcbae0362f242f37b	audiocpu	0	good	no	mcrs2j.2
2.1	131072	372dfa11	92934128c82191a08a359ec690576bc5888f085e	fgtile	0	good	no
bp932an.a04	2097152	c4d77ff0	aca60a3f5f89265e7e3799e5d80ea8196fb11ff3	bgtile	0	good	no	bp932an.a04
bp932an.a07	2097152	aa1b21b9	133822e3d8628aa4eb3e62fbd054956799423b98	sprites	0	good	no	bp932an.a07
bp932an.a08	2097152	67eb2901	25e0f9fda1a8c0c2b59616dd153cb6dcb459d2d9	sprites	200000	good	no	bp932an.a08
bp932an.a06	2097152	ef0ffec0	fd72cc77e02d1a00bf27e77a33d7dab5f6ba1cb4	oki1	40000	good	no	bp932an.a06
bp932an.a05	1048576	b5335abb	f4eaf4e465eeca31741d432ee46ed39ffcd92cca	oki2	40000	good	no	bp932an.a05
mcrs2bpr.9	256	435653a2	575b4a46ea65179de3042614da438d2f6d8b572e	htiming	0	good	no	mcrs2bpr.9
mcrs2bpr.10	256	e6ead349	6d81b1c0233580aa48f9718bade42d640e5ef3dd	vtiming	0	good	no	mcrs2bpr.10

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	audiocpu	Zilog Z80	4000000
audio	mono	Speaker
audio	ymsnd	YM2203 OPN	1500000
audio	oki1	OKI MSM6295 ADPCM	4000000
audio	oki2	OKI MSM6295 ADPCM	4000000

device_ref

name
m68000
timer
z80
screen
nmk16spr
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
ym2203
okim6295
okim6295
nmk112

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:IN0
:IN1

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW1	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW1	4

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Language

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Language	DSW1	8

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
English	0	yes
Japanese	8	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	48

location

name	number	inverted
SW1	4	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	16	no
Normal	48	yes
Hard	32	no
Hardest	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	64

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	128

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW2	15

location

name	number	inverted
SW2	8	no
SW2	7	no
SW2	6	no
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	4	no
3 Coins/1 Credit	10	no
2 Coins/1 Credit	1	no
5 Coins/3 Credits	0	no
3 Coins/2 Credits	2	no
4 Coins/3 Credits	8	no
1 Coin/1 Credit	15	yes
3 Coins/4 Credits	12	no
2 Coins/3 Credits	14	no
1 Coin/2 Credits	7	no
2 Coins/5 Credits	6	no
1 Coin/3 Credits	11	no
1 Coin/4 Credits	3	no
1 Coin/5 Credits	13	no
1 Coin/6 Credits	5	no
1 Coin/7 Credits	9	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW2	240

location

name	number	inverted
SW2	4	no
SW2	3	no
SW2	2	no
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	64	no
3 Coins/1 Credit	160	no
2 Coins/1 Credit	16	no
3 Coins/2 Credits	32	no
4 Coins/3 Credits	128	no
1 Coin/1 Credit	240	yes
3 Coins/4 Credits	192	no
2 Coins/3 Credits	224	no
1 Coin/2 Credits	112	no
2 Coins/5 Credits	96	no
1 Coin/3 Credits	176	no
1 Coin/4 Credits	48	no
1 Coin/5 Credits	208	no
1 Coin/6 Credits	80	no
1 Coin/7 Credits	144	no
Free Play	0	no
