name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
magicrd1a	misc/magicard.cpp		no	no	no	yes	Magic Card (v1.5 17.12.93, set 1)	1993	Impera	magicrd1	magicrd1

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	768	280	50.080128	15000000	960	0	768	312	32	312	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
mcorigg2.bin	131072	48546aa9	23099a5e4c9f2c3386496f6d7f5bb7d435a6fb16	maincpu	0	good	no
mcorigg1.bin	131072	c9e4a38d	812e5826b27c7ad98142a0f52fbdb6b61a2e31d7	maincpu	20000	good	no
mgorigee.bin	256	f09eb2b2	2d6efcea6c0835ea754285e22354dff8f059fdf5	sereeprom	0	good	no
ds1207	77	4902b7c2	6e6fe825cfcf39bae60ecc45ab0742772f87cf80	ds1207	0	baddump	no
magicrd1a.nv	16384	4d78bbcc	943344f03a69ee25526e2b1f2e74722ae2601c11	nvram	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Philips SCC68070	19660800
audio	mono	Speaker
audio	saa	Philips SAA1099	8000000

device_ref

name
scc68070
screen
scc66470
palette
ramdac
speaker
nvram
saa1099
24c02
ds1207

sound

channels
1

input

players	coins	service	tilt
1	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
gambling		10		no

port, analog

port_tag	analog_masks
:IN0
:IN1

dipswitch

Keyboard Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Keyboard Test	IN1	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Remote/Keyboard

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remote/Keyboard	IN1	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Remote Switch	2	yes
Keyboard	0	no

Swap Coin Inputs

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Swap Coin Inputs	IN1	4

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	yes
Yes	0	no

Setting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Setting	IN1	56

location

name	number	inverted
SW1	5	no
SW1	4	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Austria 1	56	yes
Austria 2	48	no
CSFR 1	24	no
CSFR 2	16	no
Germany 1	40	no
Germany 2	32	no
Hungary 1	8	no
Hungary 2	0	no

Hopper

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper	IN1	64

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin B	64	yes
Coin A	0	no

Hopper

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper	IN1	128

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
