Mahjong X-Tal 7 - Crystal Mahjong / Mahjong Diamond 7 (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
majxtal7	dynax/dynax.cpp		no	no	no	yes	Mahjong X-Tal 7 - Crystal Mahjong / Mahjong Diamond 7 (Japan)	1990	Dynax	7jigen	7jigen

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	180	508	240	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
4001.1a	131072	82fc6dd5	3c6e58d4c302a0f305c67c31fce6a1d4cbfe5f78	maincpu	0	good	no
4002.3a	65536	b5fec88f	bc3a2404150edd570ea7d320b2d43735fbdce195	maincpu	30000	good	no
4011.11a	131072	63551c37	338f62125d217ab7a928476d36dd2797480ef3c1	blitter	0	good	no
4012.13a	131072	51a431d5	df2327b61154f5c8eddc7572c08e714daa1498b4	blitter	20000	good	no
4013.14a	131072	cdbb24f8	6bec3931ceaed75bfee9079e095786b088b95e70	blitter	40000	good	no
4014.15a	131072	f2677938	778ce4a6bebef934749f65acd0b6472fd314ce7a	blitter	60000	good	no
4003.1b	131072	26348ae4	3659d18608848c58ad980a79bc1c29da238a5604	blitter	200000	good	no	3704.s1b
4004.2b	131072	5b5ea036	187a7f6356ead05d8e3d9f5efa82554004429780	blitter	220000	good	no	3705.s2b
4005.3b	131072	7fdfb600	ce4485e43ee6bf63b4e8e3bb91267295995c736f	blitter	240000	good	no	3706.s3b
4006.4b	131072	67fa83ea	f8b0012aaaf125b7266dbf1ae7df23d04d484e54	blitter	260000	good	no	3707.s4b
4010.4a	131072	f1d4399d	866af46900a4b04db69c838b7ec7e347a5fadd3d	blitter	280000	good	no	3711.s4a
4009.3a	131072	0a92af7c	4383dc8f3019b3b2716d32e1c91b0ac5b1e367c3	blitter	2a0000	good	no	3710.s3a
4008.2a	131072	86f27f1c	43b829597993d3043d5bbb0a468f603910638b87	blitter	2c0000	good	no	3709.s2a
4007.1a	131072	8082d0ac	44d708f8e307b782105082092edd3ea9affd2329	blitter	2e0000	good	no	3708.s1a

chip

type	tag	name	clock
cpu	maincpu	Toshiba TMPZ84C015	5500000
audio	mono	Speaker
audio	aysnd	AY-3-8912A PSG	1375000
audio	ym2413	YM2413 OPLL	3579545
audio	msm	OKI MSM5205 ADPCM	384000

device_ref

name
tmpz84c015
z80sio
z80sio_channel
z80sio_channel
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80pio
address_map_bank
nvram
ls259
ls259
screen
tc17g032ap
palette
speaker
ay8912
ym2413
msm5205
coin_hopper

sound

channels
1

feature

type	status	overall
graphics	imperfect

input

players	coins	service	tilt
2	1	yes	no

control

type	player	buttons	reverse
mahjong	1	26	no
gambling	1	3	no
mahjong	2	26	no

port, analog

port_tag	analog_masks
:COINS
:DSW0
:DSW1
:DSW2
:DSW3
:FAKE
:KEY0
:KEY1
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9
:SW1

dipswitch

Odds Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Odds Rate	DSW0	3

location

name	number	inverted
DIP2	1	no
DIP2	2	no

value

name	value	default
1 2 4 8 12 16 24 32	3	no
1 2 3 5 8 15 30 50	0	yes
1 2 3 5 10 25 50 100	1	no
1 2 3 5 10 50 100 200	2	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW0	12

location

name	number	inverted
DIP2	3	no
DIP2	4	no

value

name	value	default
1 Coin/1 Credit	12	yes
1 Coin/2 Credits	8	no
1 Coin/5 Credits	4	no
1 Coin/10 Credits	0	no

Minimum Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Minimum Bet	DSW0	48

location

name	number	inverted
DIP2	5	no
DIP2	6	no

value

name	value	default
1	48	yes
2	32	no
3	16	no
5	0	no

Payout Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Mode	DSW0	64

location

name	number	inverted
DIP2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Key-out	64	yes
Hopper	0	no

Hopper Polarity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hopper Polarity	DSW0	128

location

name	number	inverted
DIP2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	128	yes
Inverted	0	no

Payout Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Rate	DSW1	15

location

name	number	inverted
DIP1	1	no
DIP1	2	no
DIP1	3	no
DIP1	4	no

value

name	value	default
50%	0	no
53%	1	no
56%	2	no
59%	3	no
62%	4	no
65%	5	no
68%	6	no
71%	7	yes
75%	8	no
78%	9	no
81%	10	no
84%	11	no
87%	12	no
90%	13	no
93%	14	no
96%	15	no

Maximum Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Maximum Bet	DSW1	48

location

name	number	inverted
DIP1	5	no
DIP1	6	no

value

name	value	default
1	48	no
5	32	no
10	16	yes
20	0	no

Credits Per Note

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits Per Note	DSW1	64

location

name	number	inverted
DIP1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	64	no	DSW0	12	eq	12
10	64	no	DSW0	12	eq	8
25	64	no	DSW0	12	eq	4
50	64	no	DSW0	12	eq	0
10	0	yes	DSW0	12	eq	12
20	0	yes	DSW0	12	eq	8
50	0	yes	DSW0	12	eq	4
100	0	yes	DSW0	12	eq	0

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW1	128

location

name	number	inverted
DIP1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Yakuman Bonus Cycle

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Yakuman Bonus Cycle	DSW2	7

location

name	number	inverted
DIP3	1	no
DIP3	2	no
DIP3	3	no

value

name	value	default
None	7	no
First time only	6	no
Every 300 coins	5	no
Every 500 coins	4	yes
Every 700 coins	3	no
Every 1000 coins	2	no

Yakuman Bonuses Per Cycle

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Yakuman Bonuses Per Cycle	DSW2	8

location

name	number	inverted
DIP3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	8	yes
2	0	no

Win Rate?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Win Rate?	DSW2	16

location

name	number	inverted
DIP3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
High	16	yes
Low	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	32

location

name	number	inverted
DIP3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Don Den Button

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Don Den Button	DSW2	64

location

name	number	inverted
DIP3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
A	64	no
Flip Flop	0	yes

Game Title

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Title	DSW2	128

location

name	number	inverted
DIP3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mahjong X-tal 7	128	yes
Mahjong Diamond 7	0	no

Last Chance

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Last Chance	DSW3	1

location

name	number	inverted
DIP4	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Free	1	yes
Paid	0	no

Renchan Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Renchan Rate	DSW3	2

location

name	number	inverted
DIP4	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Auto Reach

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto Reach	DSW3	4

location

name	number	inverted
DIP4	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	8

location

name	number	inverted
DIP4	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW3	16

location

name	number	inverted
DIP4	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

In-Game Music

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
In-Game Music	DSW3	32

location

name	number	inverted
DIP4	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

Gal Select

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Gal Select	DSW3	64

location

name	number	inverted
DIP4	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	128

location

name	number	inverted
DIP4	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	FAKE	255

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	255	yes

name	value	default
50%	0	no
53%	1	no
56%	2	no
59%	3	no
62%	4	no
65%	5	no
68%	6	no
71%	7	yes
75%	8	no
78%	9	no
81%	10	no
84%	11	no
87%	12	no
90%	13	no
93%	14	no
96%	15	no

name	value	default
50%	0	no
53%	1	no
56%	2	no
59%	3	no
62%	4	no
65%	5	no
68%	6	no
71%	7	yes
75%	8	no
78%	9	no
81%	10	no
84%	11	no
87%	12	no
90%	13	no
93%	14	no
96%	15	no

name	value	default
50%	0	no
53%	1	no
56%	2	no
59%	3	no
62%	4	no
65%	5	no
68%	6	no
71%	7	yes
75%	8	no
78%	9	no
81%	10	no
84%	11	no
87%	12	no
90%	13	no
93%	14	no
96%	15	no
