Mega Drive Play TV 1 (Japan) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mdtvp1j	sega/megadriv_rad.cpp		no	no	no	yes	Mega Drive Play TV 1 (Japan)	2004	Sega Toys	rad_gen1	rad_gen1

snap

Mega Drive Play TV 1 (Japan) png snap

Mega Drive Play TV 1 (Japan) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
mdtvp1j	22713	29/12/2025 11:31:34	320	224	96	96	0	Format24bppRgb	305:MAME 0.270.0 (Sep 26 2024)	149ef1100e5a222176d17b2d479166ada2f474ff

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
megadriv	raster	0	256	224	59.922743								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
l08y6_i_32m.u2	4194304	740a8859	cf1212ef28e75e2cea752cf10a06ea715a30ae07	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	7670453
cpu	genesis_snd_z80	Zilog Z80	3579545
audio	gen_vdp	Sega 315-5313 Megadrive VDP	53693175
audio	gen_vdp:snsnd	Sega VDP PSG	3579545
audio	speaker	Speaker
audio	ymsnd	YM2612 OPN2	7670453

device_ref

tag	name
:maincpu	m68000
:md_scan_timer	timer
:gen_vdp	sega315_5313
:gen_vdp:palette_lut	palette
:gen_vdp:snsnd	segapsg
:gen_vdp:gfx_palette	palette
:gen_vdp:gfx_palette_shadow	palette
:gen_vdp:gfx_palette_hilight	palette
:megadriv	screen
:genesis_snd_z80	z80
:hl	ipt_merge_any_hi
:ioport1	megadrive_io_port
:ioport2	megadrive_io_port
:ioport3	megadrive_io_port
:speaker	speaker
:ymsnd	ym2612

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
joy		3	8	no

port, analog

port_tag	analog_masks
:PAD1
:PAD2
