MEGA ST (UK) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
megast_uk	atari/atarist.cpp		no	no	no	yes	MEGA ST (UK)	1987	Atari	st	st

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	844	258	50.052709	16042494	1024	56	900	313	34	292	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
tos102uk.bin	196608	3b5cd0c5	87900a40a890fdf03bd08be6c60cc645855cbce5	m68000	0	good	no		tos102
tos104uk.bin	196608	a50d1d43	9526ef63b9cb1d2a7109e278547ae78a5c1db6c6	m68000	0	good	no		tos104

chip

type	tag	name	clock
cpu	m68000	Motorola MC68000	8021247
cpu	ikbd:cpu	Hitachi HD6301V1	4000000
audio	ym2149	YM2149 SSG	2005311
audio	wd1772:0:35dd:flopsndout	Speaker
audio	wd1772:0:35dd:floppysound	Floppy sound	44100
audio	mono	Speaker

softwarelist

tag	name	status	filter
flop_list	st_flop	original
cart_list	st_cart	original

device_ref

name
m68000
st_mmu
ym2149
wd1772
floppy_connector
floppy_35_dd
speaker
flopsnd
floppy_connector
centronics
centronics_printer
printer_image
output_latch
mc68901
rs232
st_kbd
hd6301v1
acia6850
acia6850
ipt_merge_any_hi
midi_port
midiin_port
midiin
midi_port
midiout_port
midiout
clock
generic_cartslot
software_list
software_list
st_blitter
screen
st_video
speaker
rp5c15
ram

biosset

name	description	default
tos102	TOS 1.02 (MEGA TOS)	no
tos104	TOS 1.04 (Rainbow TOS)	yes

sound

channels
2

ramoption

name	default
2M
1M
4M	yes

device, instance

type	tag	interface	name	briefname
floppydisk	wd1772:0:35dd	floppy_3_5	floppydisk	flop
printout	centronics:printer:printer		printout	prin
midiin	mdin:midiin:midiinimg		midiin	min
midiout	mdout:midiout:midioutimg		midiout	mout
cartridge	cartslot	st_cart	cartridge	cart

device, extension

type	tag	interface	extension_names
floppydisk	wd1772:0:35dd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, st, msa, stx, ipf
printout	centronics:printer:printer		prn
midiin	mdin:midiin:midiinimg		mid, syx
midiout	mdout:midiout:midioutimg		mid
cartridge	cartslot	st_cart	bin, rom

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta
joy	1	1	8	no
mouse	1			no	0	255	10	5
keyboard	1	95		no
joy	2	1	8	no

port, analog

port_tag	analog_masks
:config
:ikbd:JOY0
:ikbd:JOY1
:ikbd:MOUSEB
:ikbd:MOUSEX	255
:ikbd:MOUSEY	255
:ikbd:P30
:ikbd:P31
:ikbd:P32
:ikbd:P33
:ikbd:P34
:ikbd:P35
:ikbd:P36
:ikbd:P37
:ikbd:P40
:ikbd:P41
:ikbd:P42
:ikbd:P43
:ikbd:P44
:ikbd:P45
:ikbd:P46
:ikbd:P47
:ikbd:config
:mdin:midiin:midiinimg:CFG
:video:config

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
wd1772:0	35dd	floppy_35_dd	yes
wd1772:1	35dd	floppy_35_dd	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes
cartslot

configuration

Monitor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Monitor	config	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Monochrome (Atari SM124)	0	no
Color (Atari SC1224)	128	yes

Input Port 0 Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Input Port 0 Device	ikbd:config	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mouse	0	yes
Joystick	1	no

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

GLUE wake state

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
GLUE wake state	video:config	15

setting

name	value	default
DL3 / WS2	12	no
DL4 / WS4	8	no
DL5 / WS3	4	yes
DL6 / WS1	0	no
