name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
megaste	atari/atarist.cpp		no	no	no	yes	MEGA STe (USA)	1991	Atari	ste	ste

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	312	49.664704	8021247	516	0	512	313	0	312	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional	merge	bios
atari mega ste 205 018 tms27c010.bin	131072	befac3ab	5b49f101f15a4d1c89cfd1d7ce3fec84a5ca36d0	m68000	0	good	no		tos205
atari mega ste 205 019 tms27c010.bin	131072	ea2a136d	c3c259293de562d2a0fac4d41f95cf3d42ad6df4	m68000	1	good	no		tos205
tos206.bin	262144	3f2f840f	ee58768bdfc602c9b14942ce5481e97dd24e7c83	m68000	0	good	no	tos206.bin	tos206
tos206.bin	262144	3f2f840f	ee58768bdfc602c9b14942ce5481e97dd24e7c83	m68000	0	good	no	tos206.bin	tos206

type	tag	name	clock
cpu	m68000	Motorola MC68000	8021247
cpu	ikbd:cpu	Hitachi HD6301V1	4000000
audio	ym2149	YM2149 SSG	2005311
audio	wd1772:0:35dd:flopsndout	Speaker
audio	wd1772:0:35dd:floppysound	Floppy sound	44100
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	lmc1992	LMC1992 Stereo Tone and Volume

tag	name	status	filter
flop_list	st_flop	original
cart_list	st_cart	original

name	description	default
tos205	TOS 2.05 (Mega STE TOS)	no
tos206	TOS 2.06 (ST/STE TOS)	yes

channels
3

type	tag	interface	name	briefname
floppydisk	wd1772:0:35dd	floppy_3_5	floppydisk	flop
printout	centronics:printer:printer		printout	prin
midiin	mdin:midiin:midiinimg		midiin	min
midiout	mdout:midiout:midioutimg		midiout	mout
cartridge	cartslot	st_cart	cartridge	cart

type	tag	interface	extension_names
floppydisk	wd1772:0:35dd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, st, msa, stx, ipf
printout	centronics:printer:printer		prn
midiin	mdin:midiin:midiinimg		mid, syx
midiout	mdout:midiout:midioutimg		mid
cartridge	cartslot	st_cart	bin, rom

players	coins	service	tilt
2		no	no

slot_name	slotoption_name	slotoption_devname	slotoption_default
wd1772:0	35dd	floppy_35_dd	yes
wd1772:1	35dd	floppy_35_dd	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes
cartslot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Monitor	config	128

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Monochrome (Atari SM124)	0	no
Color (Atari SC1224)	128	yes

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Input Port 0 Device	ikbd:config	1

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mouse	0	yes
Joystick	1	no

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255
