Meta Fox - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
metafox	seta/downtown.cpp		no	no	no	yes	Meta Fox	1989	Jordan I.S. / Seta

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	384	224	59.184500								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
p1003161	262144	4fd6e6a1	11a830d76ef737bcfac73d0958425fe4329f0dcd	maincpu	0	good	no
p1004162	262144	b6356c9a	182a1ea9f0643b05b14ad2a2cd820f5ca2086c4c	maincpu	1	good	no
up001002	65536	ce91c987	63546fa1342371a7080ac3cf59b41a01ac313c8c	maincpu	80000	good	no
up001001	65536	0db7a505	d593da2f7d8b54724cae017cbabc3c0909893da1	maincpu	80001	good	no
up001005	8192	2ac5e3e3	b794554cd25bdd48a21a0a2861daf8369e798ce8	sub	6000	good	no
p1006163	262144	80f69c7c	df323e801ebec6316ba17fe0371f7c87fad19295	sprites	0	good	no
p1007164	262144	d137e1a3	0e0234f1d0adb7db6d0508263e3b0b31fe7071b9	sprites	1	good	no
p1008165	262144	57494f2b	28d620254e81d7e63dfed07b29b252b975a81248	sprites	80000	good	no
p1009166	262144	8344afd2	7348b423405ad00b9240d152b119cf5341754815	sprites	80001	good	no
up001010	524288	bfbab472	d3e7b20d14de48134c4fbe3da31feb928c1c655b	tiles	0	good	no
up001011	524288	26cea381	b4bfd2a13ef6051376fe3ed57e2331a072970f86	tiles	100000	good	no
up001012	524288	fed2c5f9	81f0f19a500b665c937f5431000ebde7abd97c30	tiles	1	good	no
up001013	524288	adabf9ea	db28e4e565e567a97a6b05a4803a55a403e24a0e	tiles	100001	good	no
up001015	524288	2e20e39f	6f8bd4a76ed5c2150015698e7a98044d060157be	x1snd	0	good	no
up001014	524288	fca6315e	cef2385ec43f8b7a2d655b42c18ef44e46ff7364	x1snd	80000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
cpu	sub	WDC W65C02	2000000
audio	mono	Speaker
audio	x1snd	Seta X1-010	16000000

device_ref

name
m68000
w65c02
timer
x1_001
screen
x1_012
palette
speaker
generic_latch_8
generic_latch_8
x1_010

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:COINS
:DSW
:P1
:P2

dipswitch

Copyright / License

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Copyright / License	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Seta USA / Taito America	0	no	DSW	16384	ne	16384
Seta / Jordan I.S.	1	yes	DSW	16384	ne	16384
Seta / Taito	0	no	DSW	16384	eq	16384
Seta USA / Romstar	1	yes	DSW	16384	eq	16384

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	16	no	DSW	32768	eq	32768
1 Coin/1 Credit	48	yes	DSW	32768	eq	32768
2 Coins/3 Credits	0	no	DSW	32768	eq	32768
1 Coin/2 Credits	32	no	DSW	32768	eq	32768
4 Coins/1 Credit	0	no	DSW	32768	ne	32768
3 Coins/1 Credit	16	no	DSW	32768	ne	32768
2 Coins/1 Credit	32	no	DSW	32768	ne	32768
1 Coin/1 Credit	48	yes	DSW	32768	ne	32768

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	192

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	64	no	DSW	32768	eq	32768
1 Coin/1 Credit	192	yes	DSW	32768	eq	32768
2 Coins/3 Credits	0	no	DSW	32768	eq	32768
1 Coin/2 Credits	128	no	DSW	32768	eq	32768
1 Coin/2 Credits	192	yes	DSW	32768	ne	32768
1 Coin/3 Credits	128	no	DSW	32768	ne	32768
1 Coin/4 Credits	64	no	DSW	32768	ne	32768
1 Coin/6 Credits	0	no	DSW	32768	ne	32768

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	768

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	768	no
Easy	512	no
Hard	256	yes
Hardest	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW	3072

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	3072	no
600K Only	2048	no
600k & 900k	0	yes
900K Only	1024	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	12288

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	4096	no
2	0	no
3	12288	yes
5	8192	no

Licensor Option

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Licensor Option	DSW	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Option 1	16384	yes
Option 2	0	no

Coinage Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Type	DSW	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode 1	32768	yes
Coin Mode 2	0	no
