68000 Educational Computer Board - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mex68kecb	motorola/mex68kecb.cpp		no	no	no	yes	68000 Educational Computer Board	1981	Motorola

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
terminal:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
tutor13u.bin	8192	7d11a0e9	18ec8899651e78301b406f4fe6d4141c853e9e30	roms	0	good	no		tutor13
tutor13l.bin	8192	2bb3a4e2	3dac64ec5af4f46a367959ec80677103e3822f20	roms	1	good	no		tutor13

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	4000000
audio	terminal:terminal:bell	Speaker
audio	terminal:terminal:beeper	Beep	2000

device_ref

name
m68000
mc14411
pit68230
acia6850
acia6850
rs232
serial_terminal
screen
generic_keyboard
speaker
beep
rs232

biosset

name	description	default
tutor13	Motorola TUTOR 1.3	yes

sound

channels
1

feature

type	status	overall
tape	unemulated

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		74		no

port, analog

port_tag	analog_masks
:ABORT
:ACIA1_BAUD
:ACIA2_BAUD
:terminal:terminal:RS232_DATABITS
:terminal:terminal:RS232_PARITY
:terminal:terminal:RS232_RXBAUD
:terminal:terminal:RS232_STOPBITS
:terminal:terminal:RS232_TXBAUD
:terminal:terminal:TERM_CONF
:terminal:terminal:keyboard:GENKBD_CFG
:terminal:terminal:keyboard:GENKBD_MOD
:terminal:terminal:keyboard:GENKBD_ROW0
:terminal:terminal:keyboard:GENKBD_ROW1
:terminal:terminal:keyboard:GENKBD_ROW2
:terminal:terminal:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
terminal	terminal	serial_terminal	yes
terminal	sunkbd	sunkbd_adaptor	no
terminal	dec_loopback	dec_rs232_loopback	no
terminal	ie15	ie15_terminal	no
terminal	null_modem	null_modem	no
terminal	keyboard	serial_keyboard	no
terminal	patch	rs232_patch_box	no
terminal	swtpc8212	swtpc8212_terminal	no
terminal	printer	serial_printer	no
terminal	scorpion	scorpion_ic	no
terminal	loopback	rs232_loopback	no
terminal	mockingboard	mockingboardd	no
terminal	msystems_mouse	rs232_mouse_hle_msystems	no
terminal	nss_tvi	nss_tvinterface	no
terminal	rs232_sync_io	rs232_sync_io	no
terminal	pty	pseudo_terminal	no
terminal	votraxtnt	serial_votraxtnt	no
terminal	rs_printer	rs_serial_printer	no
host	terminal	serial_terminal	no
host	sunkbd	sunkbd_adaptor	no
host	dec_loopback	dec_rs232_loopback	no
host	ie15	ie15_terminal	no
host	null_modem	null_modem	no
host	keyboard	serial_keyboard	no
host	patch	rs232_patch_box	no
host	swtpc8212	swtpc8212_terminal	no
host	printer	serial_printer	no
host	scorpion	scorpion_ic	no
host	loopback	rs232_loopback	no
host	mockingboard	mockingboardd	no
host	msystems_mouse	rs232_mouse_hle_msystems	no
host	nss_tvi	nss_tvinterface	no
host	rs232_sync_io	rs232_sync_io	no
host	pty	pseudo_terminal	no
host	votraxtnt	serial_votraxtnt	no
host	rs_printer	rs_serial_printer	no

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	terminal:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	terminal:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	terminal:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	terminal:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	terminal:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	terminal:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	terminal:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	terminal:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	terminal:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	terminal:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	terminal:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	terminal:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	terminal:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	terminal:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	terminal:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	terminal:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

dipswitch

Terminal Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Terminal Baud Rate	ACIA1_BAUD	255

location

name	number	inverted
J10	8	no
J10	7	no
J10	6	no
J10	5	no
J10	4	no
J10	3	no
J10	2	no
J10	1	no

value

name	value	default
9600	128	yes
4800	64	no
2400	32	no
1200	16	no
600	8	no
300	4	no
150	2	no
110	1	no

Host Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Host Baud Rate	ACIA2_BAUD	255

location

name	number	inverted
J9	8	no
J9	7	no
J9	6	no
J9	5	no
J9	4	no
J9	3	no
J9	2	no
J9	1	no

value

name	value	default
9600	128	yes
4800	64	no
2400	32	no
1200	16	no
600	8	no
300	4	no
150	2	no
110	1	no
