midi2cv8 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
midi2cv8	paia/midi2cv8.cpp		no	no	no	yes	midi2cv8	1997	PAiA Electronics

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
midi2cv_v2.01.ic2	8192	bae8c045	a5db57e53831b73903a0fb171e0444e6956febc3	80c31	0	good	no		v201

chip

type	tag	name	clock
cpu	80c31	Intel 80C31	12000000

device_ref

name
i80c31
midi_port
midiin_port
midiin
midi_port
midiout_port
midiout
pwm_display

biosset

name	description	default
v201	v2.01 - December 1997	yes

sound

channels
0

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdthru:midiout:midioutimg				midiout	mout

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdthru:midiout:midioutimg				mid

input

players	coins	service	tilt
1		no	no

port, analog

port_tag	analog_masks
:dsw
:mdin:midiin:midiinimg:CFG

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdthru	midiout	midiout_port	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

dipswitch

MIDI Channel

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI Channel	dsw	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	0	yes
2	1	no
3	2	no
4	3	no
5	4	no
6	5	no
7	6	no
8	7	no
9	8	no
10	9	no
11	10	no
12	11	no
13	12	no
14	13	no
15	14	no
16	15	no

Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Mode	dsw	112

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mode 1 - 1 voice	0	no
Mode 2 - 2 voice	16	no
Mode 3 - 4 voice	32	no
Mode 4 - control change	48	no
Mode 5 - analog drum	64	no
Mode 6 - din sync	80	no
Mode 7 - [unused]	96	no
Mode 8 - self-tests	112	yes

Not Connected

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Not Connected	dsw	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	128	no
