Mahjong Clinic (Japan, set 2) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mjclinica	misc/homedata.cpp		no	no	no	yes	Mahjong Clinic (Japan, set 2)	1988	Home Data	mjclinic	mjclinic

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	432	224	59.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
x80_f01.6g	32768	cd814ec0	55b2c9519fc98f71a2731c3851ce56ee8e57bd66	maincpu	0	good	no
x80_a10.11k	131072	afedbadf	e2f101b59c0d23f9dc9b057c41d496fc3223cbb8	audiocpu	0	good	no	x80_a10.11k
x80_a03.1g	131072	34b63c89	98383ce8e464ecc53677c060338cc03aa6238a0e	gfx1	0	good	no	x80_a03.1g
x80_a040.bin	131072	6f18a8cf	af8de2bd8b2157ceaa8192ead51ac4489c464ab2	gfx2	0	good	no	x80_a040.bin
x80_a050.bin	131072	6b1ec3a9	dc7a857bb102325ebf2522369a231260c2e02c89	gfx2	20000	good	no	x80_a050.bin
x80_a041.bin	131072	f70bb001	3b29bb0bd155e97d3ccc72a8a07046c676c8452d	gfx2	40000	good	no	x80_a041.bin
x80_a051.bin	131072	c7469cb8	bcf7021667e943991865fdbc9620f00b09e1db3e	gfx2	60000	good	no	x80_a051.bin
x80_a06.1l	32768	c1f9b2fb	abe17e2b3b880f91564e32c246116c33e2884889	proms	0	good	no	x80_a06.1l
x80_a07.1m	32768	e3120152	b4a778a9b91e204e2c068dff9a40bd29eccf04a5	proms	1	good	no	x80_a07.1m
x80_a08.13a	131072	174e8ec0	a5075fe4bba9403ef9e0636d5f3f66aad8b2bc54	blit_rom	0	good	no	x80_a08.13a

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
cpu	audiocpu	Zilog Z80	4000000
audio	speaker	Speaker
audio	snsnd	SN76489A	4000000
audio	dac	8-Bit R-2R DAC

device_ref

name
mc6809e
z80
screen
gfxdecode
palette
speaker
generic_latch_8
sn76489a
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
2	1	yes	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mahjong	1	20		no
mahjong	2	20		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:IN0
:KEY0
:KEY1
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9

dipswitch

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	12

location

name	number	inverted
SW1	6	no
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	0	no
2 Coins/1 Credit	4	no
1 Coin/1 Credit	12	yes
1 Coin/2 Credits	8	no

Initial Score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Initial Score	DSW1	16

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1000	16	yes
2000	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	224

location

name	number	inverted
SW1	3	no
SW1	2	no
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 (easiest)	224	no
2	192	no
3	160	no
4	128	yes
5	96	no
6	64	no
7	32	no
8 (hardest)	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW2	1

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Girl Voice

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Girl Voice	DSW2	2

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	4

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	8

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	16

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	32

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	64

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	128

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Freeze?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Freeze?	IN0	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no
