Mahou no Lamp (v. JAA02) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mjmaglmp	bmc/bmcpokr.cpp		no	no	no	yes	Mahou no Lamp (v. JAA02)	2000	BMC

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	480	240	58.935788	10500000	680	0	480	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
ja-a-602.u10	131072	b69e235c	04e5d0d667de29680e4a35d0d98b587447e54ce3	maincpu	0	good	no
ja-a-502.u11	131072	bb609da3	ffadc20912e0a9ebe0d1a1f7f94dfaccb48be5c1	maincpu	1	good	no
ja-a-101.u41	524288	7878b9a1	7efacb063b47e518c4d3856e90d7532f478e54dd	gfx1	0	good	no
ja-a-201.u42	524288	b74f3b2b	09724909a14aebc135029d97fafcd215a84f05e3	gfx1	1	good	no
ja-a-301.u43	524288	2bbaf65e	d792054671671a2e479b89ad29bc7b3f935804f9	gfx1	100000	good	no
ja-a-401.u44	524288	9292acb1	01ce7997305dd5fdc5dc2b801046303a4d8a89c0	gfx1	100001	good	no
ja-a-901.u6	262144	25f36d00	c182348340ca67ad69d1a67c58b47d6371a725c9	oki	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10500000
audio	mono	Speaker
audio	ymsnd	YM2413 OPLL	3500000
audio	oki	OKI MSM6295 ADPCM	1050000

device_ref

name
m68000
timer
screen
palette
ramdac
gfxdecode
nvram
ticket_dispenser
speaker
ym2413
okim6295

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy		1	8	no
mahjong		24		no
gambling		3		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:DSW4
:INPUTS
:KEY1
:KEY2
:KEY3
:KEY4
:KEY5

dipswitch

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	1

location

name	number	inverted
DIP1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Double Up Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Up Game	DSW1	2

location

name	number	inverted
DIP1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Coin Sw. Function

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Sw. Function	DSW1	4

location

name	number	inverted
DIP1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin	0	no
Note	4	yes

Pay Sw. Function

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Pay Sw. Function	DSW1	8

location

name	number	inverted
DIP1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Pay-Out	0	no
Key-Out	8	yes

Game Hint

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Hint	DSW1	16

location

name	number	inverted
DIP1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	16	yes
Yes	0	no

Direct Double Up

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Direct Double Up	DSW1	32

location

name	number	inverted
DIP1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Coin Acceptor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Acceptor	DSW1	64

location

name	number	inverted
DIP1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mechanical	0	no
Electronic	64	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	128

location

name	number	inverted
DIP1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Controls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Controls	DSW2	1

location

name	number	inverted
DIP2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Keyboard	1	yes
Joystick	0	no

Key-In Limit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key-In Limit	DSW2	2

location

name	number	inverted
DIP2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1000	0	no
5000	2	yes

Double Lose Pool

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Lose Pool	DSW2	4

location

name	number	inverted
DIP2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50	0	no
100	4	yes

Double Over / Round Bonus

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Over / Round Bonus	DSW2	24

location

name	number	inverted
DIP2	4	no
DIP2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
100 / 10	16	no
200 / 10	24	yes
300 / 15	8	no
500 / 25	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	32

location

name	number	inverted
DIP2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	64

location

name	number	inverted
DIP2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	128

location

name	number	inverted
DIP2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Payout Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Rate	DSW3	3

location

name	number	inverted
DIP3	1	no
DIP3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
75%	2	no
82%	1	no
85%	3	yes
88%	0	no

Double Up Game Payout Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Up Game Payout Rate	DSW3	12

location

name	number	inverted
DIP3	3	no
DIP3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
95%	8	no
96%	4	no
97%	0	no
98%	12	yes

Game Enhance Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Enhance Type	DSW3	48

location

name	number	inverted
DIP3	5	no
DIP3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Small	16	no
Big	0	no
Normal	48	yes
Bonus	32	no

Credit Limit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credit Limit	DSW3	192

location

name	number	inverted
DIP3	7	no
DIP3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
300	0	no
500	128	no
1000	64	no
2000	192	yes

Maximum Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Maximum Bet	DSW4	1

location

name	number	inverted
DIP4	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10	1	yes
20	0	no

Minimum Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Minimum Bet	DSW4	6

location

name	number	inverted
DIP4	2	no
DIP4	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	0	no
3	6	yes
6	4	no
9	2	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW4	24

location

name	number	inverted
DIP4	4	no
DIP4	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	0	no
1 Coin/1 Credit	24	yes
1 Coin/2 Credits	16	no
1 Coin/3 Credits	8	no

Credits Per Key-In

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits Per Key-In	DSW4	96

location

name	number	inverted
DIP4	6	no
DIP4	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	64	no
10	96	yes
50	32	no
100	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	128

location

name	number	inverted
DIP4	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
