Monopoly Classic (JPM) (Version 5, Protocol) (SYSTEM5 VIDEO) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
monoplcld	jpm/jpmsys5.cpp		no	no	no	yes	Monopoly Classic (JPM) (Version 5, Protocol) (SYSTEM5 VIDEO)	1995	JPM	monopoly	monopoly

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	508	254	57.784763	10000000	676	80	588	256	0	254	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
7401.bin	524288	eec11426	b732a5a64d3fba676134942768b823d088792a1f	maincpu	0	good	no
7403.bin	524288	95dbacb6	bd551ccad95440a669a547092ab126178b0d0bf9	maincpu	1	good	no
6668.bin	524288	30bf082a	29ba67a86e82f0eb4feb816a2031d62028eb11b0	maincpu	100000	good	no	6668.bin
6669.bin	524288	85d38c2d	2f1a394df243e5fbbad31507b9074c997c473106	maincpu	100001	good	no	6669.bin
6670.bin	524288	66e2a5e1	04d4b55d6ad121cdc3592d33e9d953affa24f01a	maincpu	200000	good	no	6670.bin
6671.bin	524288	b2a3cedd	e3a5dd028b0769e08a796a96665b31491c3b18ca	maincpu	200001	good	no	6671.bin
6538.bin	262144	ccdd4ce3	dbb24682cea8081a447ca2c53395964fc46e7f56	upd7759	0	good	no	6538.bin

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd7759	NEC uPD7759	640000
audio	ym2413	YM2413 OPLL	4000000

device_ref

name
m68000
ipt_merge_any_hi
bacta_datalogger
acia6850
acia6850
acia6850
clock
clock
nvram
s16lf01
pia6821
ptm6840
speaker
upd7759
ym2413
screen
tms34061
palette

sound

channels
1

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
lightgun		1		no	0	255	45	15

port, analog

port_tag	analog_masks
:COINS
:DIRECT
:DSW
:TOUCH_PUSH
:TOUCH_X	255
:TOUCH_Y	255

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Reset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reset	DIRECT	64

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Change state to enter test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Change state to enter test	DSW	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Alarm

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Alarm	DSW	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Discontinue alarm when jam is cleared	4	yes
Continue alarm until back door open	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Payout Percentage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Percentage	DSW	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50%	0	yes
45%	128	no
40%	64	no
30%	192	no
