Microtan 6809 System - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mt6809	tangerine/microtan.cpp		no	no	no	yes	Microtan 6809 System	1984	Tangerine	mt65	mt65

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
tanbus:2:ravdu:screen	raster	0	972	500	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
ralbug14.rom	2048	8bbc87d8	3d53a6ffd4a8d7c8edf4f2e23946011ed29146ce	maincpu	0	good	no		ralbug14

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	6000000
audio	tanbus:5:radisc:fdc:0:525qd:flopsndout	Speaker
audio	tanbus:5:radisc:fdc:0:525qd:floppysound	Floppy sound	44100
audio	tanbus:5:radisc:fdc:1:525qd:flopsndout	Speaker
audio	tanbus:5:radisc:fdc:1:525qd:floppysound	Floppy sound	44100
audio	tanbus:5:radisc:mono	Speaker
audio	tanbus:5:radisc:beeper	Beep	1000

device_ref

name
mc6809
microtan_kbd_slot
microtan_kbd_mt009
tanbus
tanbus_slot
tanbus_slot
tanbus_ra32kram
tanbus_slot
tanbus_ra32kram
tanbus_slot
tanbus_ravdu
screen
mc6845
saa5055
tanbus_slot
tanbus_slot
tanbus_slot
tanbus_radisc
ipt_merge_any_hi
fd1793
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_connector
mc146818
mos6522
speaker
beep
tanbus_slot
tanbus_slot
tanbus_ra32krom
tanbus_slot

biosset

name	description	default
ralbug14	RALBUG V1.4	no

sound

channels
3

feature

type	status	overall
graphics		imperfect
disk		imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	tanbus:5:radisc:fdc:0:525qd	floppy_5_25			floppydisk1	flop1
floppydisk	tanbus:5:radisc:fdc:1:525qd	floppy_5_25			floppydisk2	flop2

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	tanbus:5:radisc:fdc:0:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ssd, bbc, img
floppydisk	tanbus:5:radisc:fdc:1:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ssd, bbc, img

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:keyboard:mt009:BRK
:keyboard:mt009:KBD0
:keyboard:mt009:KBD1
:keyboard:mt009:KBD2
:keyboard:mt009:KBD3
:keyboard:mt009:KBD4
:keyboard:mt009:KBD5
:keyboard:mt009:KBD6
:keyboard:mt009:KBD7
:keyboard:mt009:KBD8
:tanbus:0:ra32kram:DSW1
:tanbus:0:ra32kram:DSW2
:tanbus:0:ra32kram:DSW3
:tanbus:0:ra32kram:LNK1
:tanbus:1:ra32kram:DSW1
:tanbus:1:ra32kram:DSW2
:tanbus:1:ra32kram:DSW3
:tanbus:1:ra32kram:LNK1
:tanbus:7:ra32krom:DSW1
:tanbus:7:ra32krom:DSW2
:tanbus:7:ra32krom:DSW3
:tanbus:7:ra32krom:LNK1

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
keyboard	spinveti	microtan_kbd_spinveti	no
keyboard	mt009	microtan_kbd_mt009	yes
keyboard	mt006	microtan_kbd_mt006	no
tanbus:tanex	tanex	tanbus_tanex	no
tanbus:0	ravdu	tanbus_ravdu	no
tanbus:0	tanram	tanbus_tanram	no
tanbus:0	radisc	tanbus_radisc	no
tanbus:0	ra32krom	tanbus_ra32krom	no
tanbus:0	ra32kram	tanbus_ra32kram	yes
tanbus:1	ravdu	tanbus_ravdu	no
tanbus:1	tanram	tanbus_tanram	no
tanbus:1	radisc	tanbus_radisc	no
tanbus:1	ra32krom	tanbus_ra32krom	no
tanbus:1	ra32kram	tanbus_ra32kram	yes
tanbus:2	ravdu	tanbus_ravdu	yes
tanbus:2	tanram	tanbus_tanram	no
tanbus:2	radisc	tanbus_radisc	no
tanbus:2	ra32krom	tanbus_ra32krom	no
tanbus:2	ra32kram	tanbus_ra32kram	no
tanbus:3	ravdu	tanbus_ravdu	no
tanbus:3	tanram	tanbus_tanram	no
tanbus:3	radisc	tanbus_radisc	no
tanbus:3	ra32krom	tanbus_ra32krom	no
tanbus:3	ra32kram	tanbus_ra32kram	no
tanbus:4	ravdu	tanbus_ravdu	no
tanbus:4	tanram	tanbus_tanram	no
tanbus:4	radisc	tanbus_radisc	no
tanbus:4	ra32krom	tanbus_ra32krom	no
tanbus:4	ra32kram	tanbus_ra32kram	no
tanbus:5	ravdu	tanbus_ravdu	no
tanbus:5	tanram	tanbus_tanram	no
tanbus:5	radisc	tanbus_radisc	yes
tanbus:5	ra32krom	tanbus_ra32krom	no
tanbus:5	ra32kram	tanbus_ra32kram	no
tanbus:5:radisc:fdc:0	525qd	floppy_525_qd	yes
tanbus:5:radisc:fdc:0	525sd	floppy_525_sd	no
tanbus:5:radisc:fdc:0	525sssd	floppy_525_sssd	no
tanbus:5:radisc:fdc:1	525qd	floppy_525_qd	yes
tanbus:5:radisc:fdc:1	525sd	floppy_525_sd	no
tanbus:5:radisc:fdc:1	525sssd	floppy_525_sssd	no
tanbus:5:radisc:fdc:2	525qd	floppy_525_qd	no
tanbus:5:radisc:fdc:2	525sd	floppy_525_sd	no
tanbus:5:radisc:fdc:2	525sssd	floppy_525_sssd	no
tanbus:5:radisc:fdc:3	525qd	floppy_525_qd	no
tanbus:5:radisc:fdc:3	525sd	floppy_525_sd	no
tanbus:5:radisc:fdc:3	525sssd	floppy_525_sssd	no
tanbus:6	ravdu	tanbus_ravdu	no
tanbus:6	tanram	tanbus_tanram	no
tanbus:6	radisc	tanbus_radisc	no
tanbus:6	ra32krom	tanbus_ra32krom	no
tanbus:6	ra32kram	tanbus_ra32kram	no
tanbus:7	ravdu	tanbus_ravdu	no
tanbus:7	tanram	tanbus_tanram	no
tanbus:7	radisc	tanbus_radisc	no
tanbus:7	ra32krom	tanbus_ra32krom	yes
tanbus:7	ra32kram	tanbus_ra32kram	no
tanbus:exp	ravdu	tanbus_ravdu	no
tanbus:exp	tanram	tanbus_tanram	no
tanbus:exp	radisc	tanbus_radisc	no
tanbus:exp	ra32krom	tanbus_ra32krom	no
tanbus:exp	ra32kram	tanbus_ra32kram	no

configuration

Block Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Block Enable	tanbus:0:ra32kram:LNK1	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Permanent	0	no
Page selectable	1	yes

Block Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Block Enable	tanbus:1:ra32kram:LNK1	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Permanent	0	yes
Page selectable	1	no

Block Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Block Enable	tanbus:7:ra32krom:LNK1	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Permanent	0	no
Page selectable	1	yes

dipswitch

2K block $0800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0800	tanbus:0:ra32kram:DSW1	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1800	tanbus:0:ra32kram:DSW1	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2800	tanbus:0:ra32kram:DSW1	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3800	tanbus:0:ra32kram:DSW1	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4800	tanbus:0:ra32kram:DSW1	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5800	tanbus:0:ra32kram:DSW1	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6800	tanbus:0:ra32kram:DSW1	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7800	tanbus:0:ra32kram:DSW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	128	yes

2K block $0000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0000	tanbus:0:ra32kram:DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1000	tanbus:0:ra32kram:DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2000	tanbus:0:ra32kram:DSW2	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3000	tanbus:0:ra32kram:DSW2	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4000	tanbus:0:ra32kram:DSW2	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5000	tanbus:0:ra32kram:DSW2	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6000	tanbus:0:ra32kram:DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7000	tanbus:0:ra32kram:DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	128	yes

Address Selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Address Selection	tanbus:0:ra32kram:DSW3	15

location

name	number	inverted
SW3	1	no
SW3	2	no
SW3	3	no
SW3	4	no

value

name	value	default
$0000-$7FFF	15	yes
$1000-$8FFF	0	no
$2000-$9FFF	4	no
$3000-$AFFF	8	no
$4000-$BFFF	12	no
$5000-$CFFF	1	no
$6000-$DFFF	5	no
$7000-$EFFF	9	no
$8000-$FFFF	13	no
$9000-$0FFF	2	no
$A000-$1FFF	6	no
$B000-$2FFF	10	no
$C000-$3FFF	14	no
$D000-$4FFF	3	no
$E000-$5FFF	7	no
$F000-$6FFF	11	no

2K block $0800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0800	tanbus:1:ra32kram:DSW1	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1800	tanbus:1:ra32kram:DSW1	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2800	tanbus:1:ra32kram:DSW1	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3800	tanbus:1:ra32kram:DSW1	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4800	tanbus:1:ra32kram:DSW1	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5800	tanbus:1:ra32kram:DSW1	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6800	tanbus:1:ra32kram:DSW1	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7800	tanbus:1:ra32kram:DSW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	yes
Enable	128	no

2K block $0000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0000	tanbus:1:ra32kram:DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1000	tanbus:1:ra32kram:DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2000	tanbus:1:ra32kram:DSW2	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3000	tanbus:1:ra32kram:DSW2	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4000	tanbus:1:ra32kram:DSW2	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5000	tanbus:1:ra32kram:DSW2	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6000	tanbus:1:ra32kram:DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7000	tanbus:1:ra32kram:DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	128	yes

Address Selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Address Selection	tanbus:1:ra32kram:DSW3	15

location

name	number	inverted
SW3	1	no
SW3	2	no
SW3	3	no
SW3	4	no

value

name	value	default
$0000-$7FFF	15	no
$1000-$8FFF	0	no
$2000-$9FFF	4	no
$3000-$AFFF	8	no
$4000-$BFFF	12	no
$5000-$CFFF	1	no
$6000-$DFFF	5	no
$7000-$EFFF	9	no
$8000-$FFFF	13	yes
$9000-$0FFF	2	no
$A000-$1FFF	6	no
$B000-$2FFF	10	no
$C000-$3FFF	14	no
$D000-$4FFF	3	no
$E000-$5FFF	7	no
$F000-$6FFF	11	no

2K block $0800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0800	tanbus:7:ra32krom:DSW1	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1800	tanbus:7:ra32krom:DSW1	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2800	tanbus:7:ra32krom:DSW1	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3800	tanbus:7:ra32krom:DSW1	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4800	tanbus:7:ra32krom:DSW1	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5800	tanbus:7:ra32krom:DSW1	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6800	tanbus:7:ra32krom:DSW1	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7800

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7800	tanbus:7:ra32krom:DSW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	128	yes

2K block $0000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $0000	tanbus:7:ra32krom:DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	1	yes

2K block $1000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $1000	tanbus:7:ra32krom:DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	2	yes

2K block $2000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $2000	tanbus:7:ra32krom:DSW2	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	4	yes

2K block $3000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $3000	tanbus:7:ra32krom:DSW2	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	8	yes

2K block $4000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $4000	tanbus:7:ra32krom:DSW2	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	16	yes

2K block $5000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $5000	tanbus:7:ra32krom:DSW2	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	32	yes

2K block $6000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $6000	tanbus:7:ra32krom:DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	64	yes

2K block $7000

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2K block $7000	tanbus:7:ra32krom:DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disable	0	no
Enable	128	yes

Address Selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Address Selection	tanbus:7:ra32krom:DSW3	15

location

name	number	inverted
SW3	1	no
SW3	2	no
SW3	3	no
SW3	4	no

value

name	value	default
$0000-$7FFF	15	yes
$1000-$8FFF	0	no
$2000-$9FFF	4	no
$3000-$AFFF	8	no
$4000-$BFFF	12	no
$5000-$CFFF	1	no
$6000-$DFFF	5	no
$7000-$EFFF	9	no
$8000-$FFFF	13	no
$9000-$0FFF	2	no
$A000-$1FFF	6	no
$B000-$2FFF	10	no
$C000-$3FFF	14	no
$D000-$4FFF	3	no
$E000-$5FFF	7	no
$F000-$6FFF	11	no
