name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
multiwinb	funworld/funworld.cpp		no	no	no	yes	Multi Win (EPM7032, encrypted)	2001	Amatic	multiwin	multiwin

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	232	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
win3.bin	32768	5f01d620	ddd86cba383f1e40e3821a58fc0ff7c1ac24de10	maincpu	8000	good	no
multiw1_epm7032.pof	1966	922d8d72	2ad01fd0b4ddaa1098f3ffc203b6c502d1afd73a	altera	0	good	no
win2.bin	32768	bf031e5e	1c971be5eb3e8c1a1b69ec9d00e46aa1fe26b8ee	gfx1	0	good	no
win1.bin	32768	8ea33d92	5aa439181f0751040229ce75101dbdf8b3d68b6c	gfx1	8000	good	no
291_n147.bin	2048	e09e3a77	2842875cff63650e15bf7eda3a730446c671c3ea	proms	0	good	no
m1-20v8.bin	343	b05b51da	5e43cc12cd8bcd820cb89d3008a02ea857daba6f	plds	0	good	no
m2-20v8.bin	343	11852de6	33fcf6f752a116e4df0492d17e0d5e53b31ce77d	plds	200	good	no
16v8-3.bin	279			plds	400	nodump	no
jo393-4.bin	279	6eef3e7d	2e1bb576f431743b133833c7c2f91a41a4fcbc37	plds	800	good	no

chip

type	tag	name	clock
cpu	maincpu	Rockwell R65C02	2000000
audio	mono	Speaker
audio	ay8910	AY-3-8910A PSG	2000000

device_ref

name
r65c02
nvram
pia6821
pia6821
screen
gfxdecode
palette
mc6845
speaker
ay8910

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
gambling		8		no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

State

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
State	DSW	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Keyboard Test	0	no
Play	1	yes

Remote Value

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remote Value	DSW	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10 Points/Pulse	0	yes
100 Points/Pulse	2	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	4

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5 Points/Coin	0	yes
10 Points/Coin	4	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	8

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5 Points/Coin	0	yes
10 Points/Coin	8	no

Insert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Insert	DSW	16

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dattl Insert	0	yes
TAB Insert	16	no

Joker

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Joker	DSW	32

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
With Joker	0	yes
Without Joker	32	no

Hold

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hold	DSW	64

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Auto Hold	0	yes
No Auto Hold	64	no

Payout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout	DSW	128

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Hopper	0	no
Manual Payout SW	128	yes
