Muscle Ranking Kinniku Banzuke Spray Hitter - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
musclhit	konami/konamigs.cpp		no	no	no	yes	Muscle Ranking Kinniku Banzuke Spray Hitter	2000	Konami / TBS

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	60.133295	7200000	457	0	320	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
gsan5-a.u17	65536	6ae1d1e8	3224e4b8198aa38c094088456281cbd62c085407	maincpu	0	good	no
nvram.u9	15	17614a6a	f4714659937e7dd3eedc18bbedc4b3000134df16	rtc	0	good	no

disk

name	merge	sha1	region	index	writable	status	optional
gsan6_a-213		d9e7a350428d1621fc70e81561390c01837a94c0	ata:0:cfcard	0	yes	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi SH7709	64000000
audio	mono	Speaker
audio	ymz	Yamaha YMZ280B PCMD8	16934400

device_ref

name
sh7709
ata_interface
ata_slot
atacf
harddisk_image
ata_slot
rtc4553
screen
speaker
ymz280b
coin_hopper

sound

channels
1

feature

type	status	overall
graphics	imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	ata:0:cfcard:image	ata_cf			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	ata:0:cfcard:image	ata_cf			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1	3	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		1		no

port, analog

port_tag	analog_masks
:DSW
:PORT_F
:PORT_L
:RTCR
:RTCW

dipswitch

Coin Slot 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot 1	DSW	7

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5 Coins/1 Credit	3	no
3 Coins/1 Credit	5	no
2 Coins/1 Credit	6	no
4 Coins/1 Credit	4	no
1 Coin/1 Credit	7	yes
4 Coins/3 Credits	1	no
2 Coins/3 Credits	2	no
5 Coins/2 Credits	0	no

Coin Slot 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot 2	DSW	120

location

name	number	inverted
SW1	4	no
SW1	5	no
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Medals	120	yes
3 Medals	104	no
4 Medals	96	no
5 Medals	88	no
6 Medals	80	no
7 Medals	72	no
8 Medals	64	no
9 Medals	56	no
10 Medals	48	no
11 Medals	40	no
12 Medals	32	no
13 Medals	24	no
14 Medals	16	no
15 Medals	8	no
16 Medals	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Standard of Payout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Standard of Payout	DSW	3840

location

name	number	inverted
SW2	1	no
SW2	2	no
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
15%	3840	no
20%	3584	no
25%	3328	no
30%	3072	no
35%	2816	no
40%	2560	no
45%	2304	no
50%	2048	no
55%	1792	no
60%	1536	no
65%	1280	no
70%	1024	no
75%	768	no
80%	512	no
85%	256	no
90%	0	yes

Play Timer

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Play Timer	DSW	12288

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	12288	no
2	8192	no
3	4096	no
4	0	yes

Backup Memory

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Backup Memory	DSW	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Keep	16384	yes
Clear	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	no
On	0	yes
