New Wave - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
newwave	pinball/by35.cpp	genpin	no	no	yes	yes	New Wave	1985	Bell Games	blakpyra	blakpyra

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
blkp2732.u2	4096	600535b0	33d080f4430ad9c33ee9de1bfbb5cfde50f0776e	maincpu	1000	good	no	blkp2732.u2
newwu6.532	4096	ca72a96b	efcd8b41bf0c19ebd7db492632e046b348619460	maincpu	1800	good	no
newwu4.532	4096	6f4f2a95	a7a375827c0429b8b3d2ee9e471f557152492993	cpu2	8000	good	no
bp_u3.532	4096	a5005067	bd460a20a6e8f33746880d72241d6776b85126cf	cpu2	c000	good	no	bp_u3.532

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6800	530000
audio	mechvol	Speaker
audio	samples	Samples

device_ref

name
m6800
nvram
speaker
samples
pia6821
timer
timer
pia6821
timer
timer

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		33		no

port, analog

port_tag	analog_masks
:DSW0
:DSW1
:DSW2
:DSW3
:TEST
:X0
:X1
:X2
:X3
:X4

dipswitch

Coin Slot 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot 1	DSW0	31

location

name	number	inverted
SW0	1	yes
SW0	2	yes
SW0	3	yes
SW0	4	yes
SW0	5	yes

value

name	value	default
2 Coins/3 Credits	0	no
1 Coin/1 Credit	2	yes
2 Coins/1 Credit	3	no
1 Coin/2 Credits	4	no
2 Coins/2 Credits	5	no
1 Coin/3 Credits	6	no
2 Coins/3 Credits	7	no
1 Coin/4 Credits	8	no
2 Coins/4 Credits	9	no
1 Coin/5 Credits	10	no
2 Coins/5 Credits	11	no
1 Coin/6 Credits	12	no
2 Coins/6 Credits	13	no
1 Coin/7 Credits	14	no
2 Coins/7 Credits	15	no
1 Coin/8 Credits	16	no
2 Coins/8 Credits	17	no
1 Coin/9 Credits	18	no
2 Coins/9 Credits	19	no
1 Coin/10 Credits	20	no
2 Coins/10 Credits	21	no
1 Coin/11 Credits	22	no
2 Coins/11 Credits	23	no
1 Coin/12 Credits	24	no
2 Coins/12 Credits	25	no
1 Coin/13 Credits	26	no
2 Coins/13 Credits	27	no
1 Coin/14 Credits	28	no
2 Coins/14 Credits	29	no
1 Coin/15 Credits	30	no
2 Coins/15 Credits	31	no

Award for Beating Highest Score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Award for Beating Highest Score	DSW0	96

location

name	number	inverted
SW0	6	yes
SW0	7	yes

value

name	value	default
Nothing	0	no
1 Credit	32	no
2 Credits	64	yes
3 Credits	96	no

Melody Option 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Melody Option 1	DSW0	128

location

name	number	inverted
SW0	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Coin Slot 3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot 3	DSW1	31

location

name	number	inverted
SW1	1	yes
SW1	2	yes
SW1	3	yes
SW1	4	yes
SW1	5	yes

value

name	value	default
2 Coins/3 Credits	0	no
1 Coin/1 Credit	2	yes
2 Coins/1 Credit	3	no
1 Coin/2 Credits	4	no
2 Coins/2 Credits	5	no
1 Coin/3 Credits	6	no
2 Coins/3 Credits	7	no
1 Coin/4 Credits	8	no
2 Coins/4 Credits	9	no
1 Coin/5 Credits	10	no
2 Coins/5 Credits	11	no
1 Coin/6 Credits	12	no
2 Coins/6 Credits	13	no
1 Coin/7 Credits	14	no
2 Coins/7 Credits	15	no
1 Coin/8 Credits	16	no
2 Coins/8 Credits	17	no
1 Coin/9 Credits	18	no
2 Coins/9 Credits	19	no
1 Coin/10 Credits	20	no
2 Coins/10 Credits	21	no
1 Coin/11 Credits	22	no
2 Coins/11 Credits	23	no
1 Coin/12 Credits	24	no
2 Coins/12 Credits	25	no
1 Coin/13 Credits	26	no
2 Coins/13 Credits	27	no
1 Coin/14 Credits	28	no
2 Coins/14 Credits	29	no
1 Coin/15 Credits	30	no
2 Coins/15 Credits	31	no

Score Level Award

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Score Level Award	DSW1	96

location

name	number	inverted
SW1	6	yes
SW1	7	yes

value

name	value	default
Nothing	0	no
Extra Ball	64	no
Replay	96	yes

Balls Per Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Balls Per Game	DSW1	128

location

name	number	inverted
SW1	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	0	no
5	128	yes

Maximum Credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Maximum Credits	DSW2	7

location

name	number	inverted
SW2	1	yes
SW2	2	yes
SW2	3	yes

value

name	value	default
5	0	no
10	1	yes
15	2	no
20	3	no
25	4	no
30	5	no
35	6	no
40	7	no

Credits Displayed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits Displayed	DSW2	8

location

name	number	inverted
SW2	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Match Feature

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Match Feature	DSW2	16

location

name	number	inverted
SW2	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	16	yes

S22 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S22 (game specific)	DSW2	32

location

name	number	inverted
SW2	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

S23 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S23 (game specific)	DSW2	64

location

name	number	inverted
SW2	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

S24 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S24 (game specific)	DSW2	128

location

name	number	inverted
SW2	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Coin Slot 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot 2	DSW3	15

location

name	number	inverted
SW3	1	yes
SW3	2	yes
SW3	3	yes
SW3	4	yes

value

name	value	default
Same as Slot 1	0	yes
1 Coin/1 Credit	1	no
1 Coin/2 Credits	2	no
1 Coin/3 Credits	3	no
1 Coin/4 Credits	4	no
1 Coin/5 Credits	5	no
1 Coin/6 Credits	6	no
1 Coin/7 Credits	7	no
1 Coin/8 Credits	8	no
1 Coin/9 Credits	9	no
1 Coin/10 Credits	10	no
1 Coin/11 Credits	11	no
1 Coin/12 Credits	12	no
1 Coin/13 Credits	13	no
1 Coin/14 Credits	14	no
1 Coin/15 Credits	15	no

S29 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S29 (game specific)	DSW3	16

location

name	number	inverted
SW3	5	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

S30 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S30 (game specific)	DSW3	32

location

name	number	inverted
SW3	6	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

S31 (game specific)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S31 (game specific)	DSW3	64

location

name	number	inverted
SW3	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Melody Option 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Melody Option 2	DSW3	128

location

name	number	inverted
SW3	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes
