Pocket Checkers - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pcheckers	saitek/electrio.cpp		no	no	no	yes	Pocket Checkers	1988	Saitek / Heuristic Software	electrio	electrio

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1988_cx1_saitek_44868a16.u1	16384	0b9fd694	8f3c13f65786c1d1f414665b459724a674226d06	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi HD44868	600000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

name
hd44868
sensorboard
pwm_display
speaker
dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		8		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:board0:BS_CHECK
:board0:CONF
:board0:RANK.1
:board0:RANK.10
:board0:RANK.2
:board0:RANK.3
:board0:RANK.4
:board0:RANK.5
:board0:RANK.6
:board0:RANK.7
:board0:RANK.8
:board0:RANK.9
:board0:SPAWN
:board0:SS_CHECK
:board0:UI
:board0:UI_CHECK

configuration

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board0:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board0:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes
